- Page 1 Electric Drives Linear Motion and and Controls Hydraulics Assembly Technologies Pneumatics Service Rexroth IndraControl R911337305 Edition 02 VCH 05.1 Hand-Held Terminal Operating Instructions...
- Page 2 © Bosch Rexroth AG 2014 This document, as well as the data, specifications and other information set forth in it, are the exclusive property of Bosch Rexroth AG. It may not be repro- duced or given to third parties without its consent.
-
Page 3: Table Of Contents
VCH 05.1 Bosch Rexroth AG Table of Contents Table of Contents Page About this Documentation..............1 Product Identification and Scope of Delivery........2 Product Identification................2 Scope of Delivery................... 3 Using the Safety Instructions..............3 Safety Instructions – Structure.............. 3 Explaining Signal Words and Safety Alert Symbol......... - Page 4 Bosch Rexroth AG VCH 05.1 Table of Contents Page 10.3 Connecting to the Connection Module VAC........15 10.4 Software-Specific Settings..............15 Commissioning..................15 Device Description................16 12.1 General Information................16 12.1.1 View Hand-Held Terminal..............16 12.1.2 Connection to the Control, Selecting the Connection Modules..16 12.2...
-
Page 5: About This Documentation
VCH 05.1 Bosch Rexroth AG About this Documentation 1 About this Documentation Overview – target groups and product phases The activities, product phases and target groups that refer to the present docu- mentation are marked in red color in the following figure. -
Page 6: Product Identification And Scope Of Delivery
Please email your feedback on the documentations to Feed- back.Documentation@boschrexroth.de. Directly insert comments in the elec- tronic PDF document and send the PDF file to Bosch Rexroth. 2 Product Identification and Scope of Delivery 2.1 Product Identification The type plate is located at the rear side of the device. -
Page 7: Scope Of Delivery
VCH 05.1 Bosch Rexroth AG Using the Safety Instructions Type plate ① ⑧ Company address State of revision ② ⑨ Division or plant number Serial number as barcode ③ ⑩ Designation of origin Serial number ④ ⑪ Underwriters Laboratories Inc. mark Part number as bar code ⑤... -
Page 8: Explaining Signal Words And Safety Alert Symbol
Bosch Rexroth AG VCH 05.1 Using the Safety Instructions Consequences and Safety alert symbol source of danger Signal word Burns and chemical burns due to wrong CAUTION battery treatment! Do not open the batteries and do not heat them over 80 °C. -
Page 9: Symbols Used
This is a note. Tips are displayed as follows: This is a tip. 4 Intended Use Bosch Rexroth hand-held terminals are PC-based machine operator terminals. Danger of destruction of the device if not ex- NOTICE pressly stated accessories, mounting parts and other components, cables, lines, software and firmware are used. -
Page 10: Spare Parts, Accessories And Wear Parts
Bosch Rexroth AG VCH 05.1 Ambient Conditions Risk of destroying the touch screen or the front NOTICE panel by using inappropriate items. Operate the touch screen only with your finger or with a special touch pen (parts number 1070923266). 5 Spare Parts, Accessories and Wear Parts... -
Page 11: Technical Data
VCH 05.1 Bosch Rexroth AG Technical Data 7 Technical Data 7.1 Hand-Held Terminal Processor Texas Instruments OMAP3503 600MHz (ARMCortex A8 ar- chitecture) LPDDRAM: 128 MB Flash memory 128 MB Interfaces Ethernet: 10/100 MBit Housing material ABS, resistant to grease, oil, lubricants, alcohol etc. -
Page 12: Stop And Emergency Stop Pushbutton
Bosch Rexroth AG VCH 05.1 Technical Data Enclosure rating IP 65 (entire device) Dimensions Width: 162 mm ● Height: 226 mm ● Depth: 55 mm ● Fire resistance UL94-V0 Standard operating elements A 3-stage enabling button, two-circuit, externally wired Stop button/EMERGENCY STOP pushbutton, two-circuit,... -
Page 13: Connection Modules
VCH 05.1 Bosch Rexroth AG Standards Enable B10d Switch position 2: 1 000 000 Switch position 3: 100 000 Tab. 7-5: Enabling button, specifications acc. to EN ISO 13849-1:2008 7.5 Connection Modules The technical data about the connection modules can be found in the respective operating instructions (see tab. -
Page 14: Ec-Type Examination Certificate
Bosch Rexroth AG VCH 05.1 Standards Standard Meaning EN ISO 13849-1:2008 Safety of machinery – safety-related parts of control systems – part 1: General principles for design EN 60204-1:2006 (chapter 9, chapter Safety of machinery – electrical equipment of machines –... -
Page 15: Ce Marking
VCH 05.1 Bosch Rexroth AG Standards The type-examination certificate No. is 1069/1. Safety specifications EN ISO 13849-1:2008 Category 3 PL d The safety function "enabling button" for the special operation mode control and the stop button meet the requirements of category 3 and PL according to EN ISO 13849-1 and the requirements of EN 60204-1 provided that the safety in- structions in this document are complied with. -
Page 16: Interfaces
Bosch Rexroth AG VCH 05.1 Interfaces C22.2 No. 142-M1987 (CSA) ● However, there can be combinations or extension stages with limited or missing certification. Thus, verify the registration according to the UL marking on the de- vice. Loss of UL/CSA conformity due to modifications to the device. -
Page 17: Assembly, Disassembly And Electrical Installation
VCH 05.1 Bosch Rexroth AG Assembly, Disassembly and Electrical Installation 10 Assembly, Disassembly and Electrical Installation 10.1 Housing Dimensions 161.5 65.9 Fig. 10-1: Dimensions (in mm) of the hand-held terminal VCH 05.1 10.2 Cable Installation Opening the cable chamber 1. Place the hand-held terminal on an even and clean surface with the display facing downwards (e.g. - Page 18 Bosch Rexroth AG VCH 05.1 Assembly, Disassembly and Electrical Installation Modifications in the cable chamber: Manually remove the main connector (S1). Do not use any sharp ● or pointed objects When disconnecting the RJ-45 connectors (S2), make sure that ●...
-
Page 19: Connecting To The Connection Module Vac
VCH 05.1 Bosch Rexroth AG Commissioning 10.3 Connecting to the Connection Module VAC Refer to the documentation about the connection modules. 10.4 Software-Specific Settings The software settings are described in the project planning manual "Rexroth IndraControl V Devices Operating Systems" (see tab. -
Page 20: Device Description
Bosch Rexroth AG VCH 05.1 Device Description 12 Device Description 12.1 General Information 12.1.1 View Hand-Held Terminal ① ⑦ Stop button (two-circuit) Protective cover of the USB interface ② Stylus with holder and for the micro SD card ③ ⑧... -
Page 21: Operating System
VCH 05.1 Bosch Rexroth AG Device Description comfortable connection of a hand-held terminal. All clamps for fixed wiring to the control are located at the rear side of the connection module in the control cabinet. VAC 30.2 and VAC 05.1: The connection module VAC 30.2 and VAC 05.1 for hand-held terminals with stop button is equipped with a... -
Page 22: Error Causes And Elimination
NOTICE sible by skilled staff! If hardware or software components have to be exchanged, please contact the Bosch Rexroth Service or ensure that only skilled staff changes the respective components. Dissolution of the foil surface as well as the NOTICE... -
Page 23: Display
A fading backlight causes a progressive deterioration display readability, so that a replacement is required. For further information, please contact the Bosch Rexroth Service, see chapter 17 "Service and Support" on page 14.4 Maintenance... -
Page 24: Ordering Information
Bosch Rexroth AG VCH 05.1 Ordering Information Damage to the device due to failed update NOTICE Do not disconnect the device from the power supply during the update. 15 Ordering Information 15.1 Accessories and Spare Parts For ordering information about accessories and spare parts, please refer to chapter 5 "Spare Parts, Accessories and Wear Parts"... -
Page 25: Type Code
VCH 05.1 Bosch Rexroth AG Disposal 15.2 Type Code Short text column 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 Example: V C H 0 5 . -
Page 26: Take-Back
Bosch Rexroth AG VCH 05.1 Service and Support 16.2 Take-Back Our products can be returned to our premises free of charge for disposal. How- ever, the products must be free of impurities like oil, grease or other impurities. Furthermore, the products returned for disposal must not contain any undue foreign material or foreign components. - Page 27 VCH 05.1 Bosch Rexroth AG Service and Support Contact the Service Helpdesk & Hotline under: Phone: +49 9352 40 5060 Fax: +49 9352 18 4941 E-mail: service.svc@boschrexroth.de Internet: http://www.boschrexroth.com Additional information on service, repair (e.g. delivery addresses) and training can be found on our internet sites.
- Page 28 Bosch Rexroth AG VCH 05.1 24/27 DOK-SUPPL*-VCH*05*****-IT02-EN-P...
-
Page 29: Index
VCH 05.1 Bosch Rexroth AG Index Index Interfaces........12 Accessories........6 Accumulators........ 22 Ambient conditions......6 Maintenance......... 18 Assembly........13 Operating system......17 Batteries........22 Order information......6 Ordering information....20 Cable installation......13 CE marking........11 Product identification..... 2 Complaints........ - Page 30 Bosch Rexroth AG VCH 05.1 Index Use, intended......... 5 View hand-held terminal....16 Wear parts........6 26/27 DOK-SUPPL*-VCH*05*****-IT02-EN-P...
- Page 31 VCH 05.1 Bosch Rexroth AG Notes...
