- Page 1 FC Wireless iFlex Calibration Manual August 2014 © 2014 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................1 Contact Fluke ..................... 1 Safety Information ....................2 Symbols ......................3 Specifications ..................... 4 Required Equipment ..................5 Performance Tests ..................... 5 Test the Display ..................... 5 Backlight ......................6 Keypad Test ....................6 AC Current Test ..................... - Page 4 FC Calibration Manual...
- Page 5 List of Tables Table Title Page Symbols ........................3 Required Equipment ....................5 Performance Tests ....................7 Calibration Adjustment ................... 11 User-Replaceable Parts ..................13...
- Page 6 FC Calibration Manual...
- Page 7 List of Figures Figure Title Page All Segments of the Display ................... 5 Performance Test Connections for Simulated Voltages ........7 Performance Test Connections for Applied Current ..........8 Calibration Password Reset ................... 10 Battery Replacement ....................13...
- Page 8 FC Calibration Manual...
-
Page 9: Introduction
Warning Read "Safety Information" before you use the Product. This manual has the verification and calibration adjustment procedures for the a3001 FC Wireless iFlex (the Product). Please see the a3001 FC Quick Reference Guide for usage information. Contact Fluke To contact Fluke, call one of the following telephone numbers: •... -
Page 10: Safety Information
FC Calibration Manual Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. Warning To prevent possible electrical shock, fire, or personal injury: •... -
Page 11: Symbols
Product Category: With reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation” product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. -
Page 12: Specifications
FC Calibration Manual Specifications Range ..............2500 A ac Resolution ............. 0.1 A for 0 A to 1000 A; 1 A for 1000 A to 2500 A Accuracy ..............3 % ±5 digits (45 Hz to 500 Hz) Crest Factor (50 Hz/60 Hz)........3.0 at 1100 A, 2.5 at 1400 A, 1.42 at 2500 A, add 2 % for C.F. >2 Frequency .............. -
Page 13: Required Equipment
2. Push while you keep pushed until all of the display segments are shown. See Figure 1. hby002.eps Figure 1. All Segments of the Display If segments of the display are missing, repair is necessary. See “Contact Fluke”. -
Page 14: Backlight
FC Calibration Manual Backlight To verify that the backlight functions: 1. With the Product on, push . 2. The backlight will come on. If it does not, repair is necessary. See “Contact Fluke”. Keypad Test To verify that the keypad functions, turn on the Product and push each button separately. - Page 15 750 mV,500 Hz 2420 2580 50-Turn Coil 45 Hz,0.4 A 44.3 45.7 0.5% ±5 digits 50-Turn Coil 500 Hz,0.325 A 497.0 503.0 a3001 FC 5522A NORMAL SCO PE V, , A, -SENSE, 150V PK AUX V 1000V TRIG 1V PK 20V PK •...
- Page 16 FC Calibration Manual 50-Turn Current Coil Conductor 5522A NORMAL SCO PE V, , A, -SENSE, 150V PK AUX V 1000V TRIG 1V PK 20V PK • 20V PK a3001 FC hca009.eps Figure 3. Performance Test Connections for Applied Current...
-
Page 17: Before Calibration Adjustment
Wireless iFlex Before Calibration Adjustment Before Calibration Adjustment Before the Product calibration can be adjusted, you must go through the maintenance mode menu and enter your password. Maintenance Mode The Product maintenance mode can be used to set different parameters on the Product that include auto power off, backlight adjustment, and calibration. -
Page 18: Restore The Default Password
FC Calibration Manual Restore the Default Password If the calibration password is lost, the default password (1234) can be manually restored with the subsequent steps: Warning To prevent electric shock or personal injury, remove all input signals before you open the Product. -
Page 19: Calibration Adjustment
Wireless iFlex Calibration Adjustment Calibration Adjustment The Product features closed-case calibration adjustment and uses known reference sources. The Product measures the applied reference source, calculates correction factors, and stores the correction factors in nonvolatile memory. Should the Product fail any of the performance tests, do the calibration adjustment procedure. -
Page 20: Maintenance
FC Calibration Manual Maintenance Clean the Product Caution To prevent possible damage to the Product or to equipment under test, do not use abrasive cleaners. They will damage the case. To clean the Product, use a cloth with a mild cleaning solution. -
Page 21: User-Replaceable Parts
User-replaceable parts are shown in Table 5. Table 5. User-Replaceable Parts Fluke Part Number Description 4130305 FLK-3000-2003, DOOR, BATTERY 3676410 FLUKE-I2500-10, IFLEX 2500A PROBE 10IN 1881997 TPAK, meter hanging kit 4466358 INFORMATION PACK,FLK-A3001 FC 376756 Battery, AA 1.5 V, NEDA 15 A, IEC LR6... - Page 22 FC Calibration Manual...
