- Page 1 User Manual Remote Control R13 F Receiver www.danfoss.com...
- Page 2 User Manual R13 F Receiver Revision history Table of revisions Date Changed January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | January 2019 BC292382016572en-000101...
-
Page 3: Table Of Contents
User Manual R13 F Receiver Contents Safety instructions General safety....................................4 Safety warnings....................................4 Technical description Dimensions......................................6 Hardware description..................................7 Installation Receiver installation..................................8 Troubleshooting Receiver icon troubleshooting..............................9 © Danfoss | January 2019 BC292382016572en-000101 | 3... -
Page 4: Safety Instructions
• Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. © Danfoss | January 2019 BC292382016572en-000101... - Page 5 User Manual R13 F Receiver Safety instructions Quick reference precautions © Danfoss | January 2019 BC292382016572en-000101 | 5...
-
Page 6: Technical Description
User Manual R13 F Receiver Technical description R13 F dimensions Dimensions in mm 232.00 216.00 R 2.60 R 2.60 81.55 60.69 219.73 37.50 248.93 Fixing slots (fixed assembly or anti-vibration) M32 cable gland © Danfoss | January 2019 BC292382016572en-000101... -
Page 7: Hardware Description
User Manual R13 F Receiver Technical description R13 F hardware description 12 13 External antenna A60 (433) or A70 (870) RS232 / RS485 socket Power supply LR13 logic board Data logger connection INXX card socket External EEPROM LCD connection TR800-CE MCX radio... -
Page 8: Installation
User Manual R13 F Receiver Installation R13 F receiver installation The below information describes hazards to be aware of during installation and steps to locate the receiver. Risk of shock Completely shut down the machine when installing the receiver. Check the power supply and shut off the main switch to disconnect the interface cable between the receiver and the machine's electrical box. -
Page 9: Troubleshooting
User Manual R13 F Receiver Troubleshooting Receiver icon troubleshooting Icon Description Action Power failure Check the receiver power supply Hardware error Contact distributor; replace receiver CAN error Contact your distributor Repose state due to active stop Release stop button and turn transmitter on... - Page 10 User Manual R13 F Receiver 10 | © Danfoss | January 2019 BC292382016572en-000101...
- Page 11 User Manual R13 F Receiver © Danfoss | January 2019 BC292382016572en-000101 | 11...
- Page 12 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
