Remote Pairing - Directed Electronics Viper 5902 Installation Manual

Remote Pairing

Prepare the vehicle system to be Paired with a new remote
1. Open a door.
2. the key to the ON position.
Turn
3. Within 5 seconds press and release the Control button on the Control Center one time.
4. Within 5 seconds,
time and the siren then chirps to confirm the vehicle is ready for remote pairing.
5. Release the Control button and proceed below.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the Responder HD 2-way remote control to be Paired with the system:
Remote Pair matches your HD remote to the system. Make sure the HD remote is set for the desired Car 1
(Default) or Car 2 operation for the system it will be paired with.
1. With the HD remote control display blank,
screen appears.
the menu wheel until Adjustments screen appears
2.
Toggle
3. in on the menu wheel to enter.
Press
Adjustments menu highlight Remote Pair and press in the Menu Wheel to go to the Remote Pair
4. In the
screen. Follow the on screen instructions:
I. Press and hold the
II. The system chirps the siren to indicate it has learned the HD remote ID and is sending its ID to the
remote.
III. Release button.
5. Successful or Failed Pair: The HD remote control indicates a successful or failed pairing on the display.
AUX
After a successful pairing, it then returns to the Adjustments menu. If pairing fails, it returns to the
Remote Pair screen, press the
Prepare the vehicle system to be Paired with the companion or a new 1-way remote as described above.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the companion 1-way remote control to be Paired with the system:
Make sure the remote is set for the desired Car 1 (Default) or Car 2 operation for the system it will be paired
with.
1. Press and hold the
Note: If Car 2 mode is on, ignore the Car Select beep after 3 seconds.
2. Wait for the Transmit LED to light solid and the remote to beep. Release the
3. Press the button for 1 second. The transmit LED will blink 3 times and beep 3 times.
AUX
4. Within 5 seconds, press the
5. The vehicle siren will chirp. You have now successfully learned the remote to the vehicle remote start and
security system.
AUX
6. Press the button two times to exit learn routine on the remote. The transmit LED will turn off and exit
tone will sound.
10
press and hold the Control button on the Control Center. The status LED will flash one
press in and hold the menu wheel for 3 seconds until
button until tones are played.
AUX
button to attempt another pairing.
AUX
AUX
button for 8 seconds.
button.
AUX
Settings
AUX
button.
© 2009 Directed Electronics. All rights reserved.
