- Page 1 Crestron TMK-12L & WMKT-12L Trim Ring Mount Kits Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
-
Page 3: Supplied Hardware
The TMK-12L consists of a metal trim ring that attaches to the PMK-12L or BB-12L. The WMKT-12L consists of the trim ring found in the TMK-12L as well as a mounting plate. The mounting plate is the part that provides the necessary support for post-construction applications. - Page 4 Trim Ring Mount Kits Supplied Hardware of the TMK-12L and WMKT-12L The dimensions of the TMK-12L/WMKT-12L are shown below. Dimensional Drawing 2 • Trim Ring Mount Kits: TMK-12L & WMKT-12L Crestron TMK-12L & WMKT-12L DESCRIPTION Metal Plate, Mounting (WMKT-12L only)
-
Page 5: Installation
The procedure in this section provides the necessary steps for the assembly of the TMK-12L to either the PMK-12L or BB-12L. It is assumed that the PMK-12L or BB-12L has been secured to the stud according to the procedures in the latest revisions of their respective Installation Guides (Doc. - Page 6 2. Insert the symmetrical trim ring into the opening, as shown in the following diagram. Insert Trim Ring into Opening 3. When the trim ring is in position, bend the top two flanges of the ring upward and the bottom two flanges downward. •...
- Page 7 Crestron Mud Mount Kit, MMK-12L. It and the mounting plate supplied with the WMKT-12L provide a cost-effective means of correction. Essentially, The combination of these two kits makes up the Crestron Mud Mount Kit for the Wall, WMKM-12L. Simply follow the “WMKM-12L Procedure” in the latest revision of the Mud Mount Kits Installation Guide (Doc.
- Page 8 CAUTION: Allow an air gap of at least 12 inches in the wall cavity above the touchpanel for heat dissipation. 6 • Trim Ring Mount Kits: TMK-12L & WMKT-12L Crestron TMK-12L & WMKT-12L 6. When the mounting plate is in position, bend the top two flanges of the trim ring upward (approximately 90 degrees) and the bottom two flanges downward (approximately 90 degrees).
-
Page 9: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 10: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 11 Crestron TMK-12L & WMKT-12L Trim Ring Mount Kits This page intentionally left blank. Trim Ring Mount Kits: TMK-12L & WMKT-12L • 9 Installation Guide – DOC. 6360...
- Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6360 15 Volvo Drive Rockleigh, NJ 07647 (2013443) Tel: 888.CRESTRON 07.05 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
