Henny Penny Evolution Elite™ Open Fryer: Drain Pan Assembly

Standards

The Drain Pan Assembly consists of:

•

Drain Pan

•

Metal Screen

•

Filter Pad

•

Retaining Ring

•

Crumb Catcher

•

Drain Pan Lid

Drain Pan Assembly

•

Start with a clean drain pan assembly every morning. Make sure all the parts are dry

to prevent dampening filter pad and break down oil.

•

Put the metal screen on the bottom of the drain pan.

•

Put the filter paper (when using Magnesol) or filter pad - smooth side facing down (if

not using Magnesol), on top of the metal screen

•

Put the retaining ring on top of the filter pad to prevent crumbs from being sucked

through the hole in the bottom of the drain pan and blocking the pump.

Page 1 Henny Penny Evolution Elite™ Open Fryer: Drain Pan Assembly Standards The Drain Pan Assembly consists of: • Drain Pan • Metal Screen • Filter Pad • Retaining Ring • Crumb Catcher • Drain Pan Lid Drain Pan Assembly • Start with a clean drain pan assembly every morning. Make sure all the parts are dry to prevent dampening filter pad and break down oil.
Page 2 Add Magnesol (Skip this step if your restaurant doesn’t use Magnesol) • Using the Magnesol® Measuring Cup measure out 90 g (PER VAT) against the mark on the cup. • Tap the Magnesol® Measuring Cup until the contents are level, ensure you have the correct dosage in the container (90 g per vat) Spread the Magnesol ®...
Page 3 • Check the drain pan o-rings daily for nicks and tears to prevent oil leaking. • To replace o-ring, use o-ring tool (same as for Taylor machine). Push underneath the o-ring. Pull up and off the end of the tube. Roll new o-ring into notch on tube. Have a set of replacement o-rings available to replace every Key Point 3 to 4 months due to wear.
