- Page 1 TECHNICAL M A N U A L Evolution Elite™ MODEL EEG-163 EEG-164 R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M...
-
Page 2: Section 1: Introduction
SECTION 1: INTROduCTION The instructions in this manual have been prepared to aid you in learning the proper procedures for your equipment. Where SAFETY information is of particular importance or is safety related, the words NOTICE, CAUTION, or WARNING are used. Their usage is described below. - Page 3 1-2. SAFETY (ConT.) Equipotential Ground Symbol Waste Electrical and Electronic Equipment (WEEE) Symbol Shock Hazard Symbols Hot Surface Symbols Sept. 2013...
-
Page 4: Section 2: Troubleshooting
SECTION 2: TROubLESHOOTING 2-1. TRoUBLE SHooTInG GUIDE Problem Cause Correction POWER switch ON • Open circuit • Plug fryer in but fryer completely • Check breaker or fuse at supply inoperative Control error code “E- • Oil temperature too • Let unit cool down (15-20 10”... -
Page 5: Troubleshooting Guide
2-1. TRoUBLE SHooTInG GUIDE (ConT.) Problem Cause Correction Oil foaming or boiling • Water in oil • drain and clean oil over top of vat • Improper or bad oil • use recommended oil • Improper filtering • Refer to filtering procedures • Improper rinsing after • Clean and rinse vat and then dry thor- cleaning the vat oughly... -
Page 6: Error Codes
In the event of a control system failure, the digital display shows 2-2. an error message. The message codes are shown in the DISPLAY ERRoR CoDES column below. A constant tone is heard when an error code is dis- played, and to silence this tone, press any button. DISPLAY CAUSE CORRECTION... - Page 7 2-2. ERRoR CoDES (ConT.) DISPLAY CAUSE CORRECTION • • “E-20-A” Pressure Switch failure If fan is not running, have pressure switch checked; should Wiring problem “FAN SENSOR be open circuit if no air pressure • I/O board failure • STUCK If fan is running, wiring error, or relay on I/O board closed •...
- Page 8 2-2. ERRoR CoDES (ConT.) DISPLAY CAUSE CORRECTION • • “E-83-C” Pressure too high Check filter system in Vat #3 • • “E-83-D” Pressure too high Check filter system in Vat #4 • • “E-83-E” Pressure too high Check filter system in Vat #5 •...
- Page 9 Sept. 2013...
-
Page 10: Section 3: Parts
SECTION 3: PARTS Item No. Part No. Description Quantity 152508 HANGER-BASKET-EEGXX4 ..........1/ 4-well 152793 HANGER-BASKET-EEGXX3 ..........1/ 3-well 76555 WELD ASSY-COVER FULL ..........1/vat 81980 LED-5MM BLUE ..............1/vat -------- DRAIN KNOB ASSEMBLY........... 1/vat --See DRAIN KNOB drawing for breakdown 77575 CASTER-SWIVEL W/ BRAKE (front) ........ - Page 11 Item No. Part No. Description Quantity 152634 ASSY-EEG-16X DRAIN PAN W/ CASTER......152635 --ASSY-EEG-16X DRAIN PAN COVER ......85507 --WELD ASSY-CRUMB CATCHER ........85503 --WELD ASSY-FILTER WEIGHT ......... 85519 --FILTER SECTION ............... 95842 --ASSY-DRAIN PAN .............. 19004 ----CASTER-SWIVEL 2IN ............. SC01-009 ----SCREW 1/4-20 X 1/2 THD ..........
- Page 12 Item No. Part No. Description Quantity 92717 THERMOCOUPLE- HIGH LIMIT ........1/vat 87739 ASSY-PROBE ................. 1/well EEG-164 Door Break Down 150300 93355 93355 93356 ASSY-LH DOOR ASSY-LH DOOR ASSY-LH DOOR ASSY-RH DOOR (long) (short) (short) EEG-163 Door Break Down 150300 93355 93356 ASSY-LH DOOR...
- Page 13 Item No. Part No. Description Quantity 87648-001 ASSY-GAS VALVE FULL NAT ..........1/vat 87663-003 ASSY-GAS VALVE FULL LP ..........1/vat 152899 BURNER-PILOT ..............1/ 2-well PILOT KIT (See next page for kit numbers) 152747-001 --INLET-FITTING PILOT ORIFICE (NAT) ......1/vat 152747-002 --INLET-FITTING PILOT ORIFICE (LP) ......
- Page 14 Kit Number Description 140282 KIT-EEG16X OIL TST/BOILOUT PKT 140283 KIT-EEG16X FRYER SUPPLY (Chili's) 140289 KIT-REPL FULL POT ASSY-EEG2XX 140290 KIT-NAT TO LP F UP TO 5000 FT 140291 KIT-LP TO NAT F UP TO 5000 FT 140295 KIT-EEG16X FRYER SPLY-MAGGIANO 140296 KIT-EEG16X/2XX NAT BASO PILOT 140297...
- Page 15 Item No. Part No. Description Quantity 79213 TRANSDUCER-PRESSURE 30 PSI........92963-001 BLOWER MOTOR-FLUE EXHAUST 115V ......1/well ------ FLEX TUBE (see flex tube chart for length/part number) ..152902-001 CORD-POWER ............... 151744 VALVE-120V SOLENOID 1/2NPT ........1/vat 151725 ASSY-POT CHECK VALVE ..........1/vat 73473 PUMP-OIL TOP OFF 120V ............
- Page 16 Item No. Part No. Description Quantity 151727 VALVE-DRAIN 1 1/2 NPT & CAM LOCK ......1/vat NS03-103 NUT-CASTLE 1/2-20 18-8 STEEL ........1/vat 17255 --PIN-COTTER ............... 1/vat 76948 O-RING -325 ................1/vat 151106 ARM-PIVOT ................1/vat PN01-012 CLEVIS PIN 1/4 X 1 IN. SS ........... 1/vat 151156 PIVOT BUSHING ROD LINKAGE ........
- Page 17 FLEX TUBE NUMBERS Flex Tube Length Part Number (in.) 77523-001 12.0 77523-002 18.0 77523-003 24.0 77523-004 30.0 77523-005 36.0 77523-006 42.0 77523-007 48.0 77523-008 77523-009 13.0 77523-010 54.0 77523-011 10.0 77523-012 13.0 77523-013 14.0 77523-014 28.0 77523-015 32.0 77523-016 16.0 Item No.
- Page 18 Item No. Part No. Description Quantity ME90-008 P&B T92 RELAY 12VDC COIL 30AMP ....... 84454 ASSY-EVOLUTION ELITE AIF PCB ........77992 SWITCH-PRESSURE 0.80 ............. 1/vat 77839 MODULE-IGNITION NON CE ..........2/well 60818 RELAY - 24VAC COIL ............1/well Recommend Parts: A=Truck Stock/B=Dist. Stock / *not shown/ A/R=As Required Sept.
