Cleveland SET-15 Specifications

™
Cleveland
BRAISING PANS /
TILTING SKILLETS
"SPLASH PROOF"
ELECTRIC TABLE TYPE, ROUND,
15 GALLON (56 LITER)
Cleveland Standard Features
I High Efficiency Heating System with even heat distribution
via Heating Elements cast into Aluminum, covering entire
pan bottom
I Cooking Surface Guaranteed against warping
I Splash Proof
I Bead Blasted Cooking Surface resists sticking
I Adjustable, Thermostat Controlled Temperature from 175°F
to 425°F
I Fast Heat-Up and Recovery Time
I Balanced Design Permits Easy Tilting; with left or right
mounted Tilt Handle
I All Stainless Steel Construction for durability and easy
cleaning
I Lift-Off Cover with Adjustable Vent
I Sanitary Base Mounting for Table Top Installation
I Standard 208 or 240 Volts, 60 Hz, 3 Phase, 3 Wire
I Self-Locking Marine Type Tilt Mechanism:
Prevents accidental tilting
I Typical approvals include UL, CSA, CE and NSF
Options & Accessories
Ë Double or Single Pantry with Swing Spout
(DPS) or (SPS
Ë Faucet Bracket (FBSL)
Ë Poaching Pan (PPR)
Ë Vegetable Steamer (VS)
Ë 4" Stainless Steel Legs with adjustable feet (LTKS)
Ë Voltages other than standard (VOS)
Ë Stainless Steel Support Stands (ST28) with Sliding Drain
Drawer and Splash Screen
Ë Food Strainer (FS-15-5)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900 Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782 Email: Steam@ClevelandRange.com
MODEL: SET-15
Shown with optional Support Stand (ST28)
Short Form Specifications
Shall be CLEVELAND, Round Tilting Skillet, Model SET-15; _____ KW _____
Volts, 15 Gallon Capacity (56 liters). Complete with: Thermostatic and Safety
Controls; Bead Blasted Cooking Surface; Lift-Off Cover with adjustable Vent.
All Stainless Steel Construction.
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
XII
SECT. PAGE
0707
3
