Page 1: User Manual
SX Mix™ Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
... 7 OUNTING Orientation ... 7 Rigging ... 7 4. OPERATING INSTRUCTIONS... 7 ... 8 ENERAL ROUBLESHOOTING ... 9 ECHNICAL UPPORT 5. APPENDIX... 9 ... 9 ENERAL AINTENANCE ... 9 ETURNS ROCEDURE ...10 LAIMS ...10 ECHNICAL PECIFICATIONS SX Mix Manual 2006-12-11/15:22... -
Page 3: Before You Begin
1. B EFORE What is included 1 x SX Mix™ ELC3 24V 250W Lamp Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
In the unlikely event your unit may require service, please contact CHAUVET. Duty Cycle This fixture has a 15/15 duty cycle, meaning it can be run for fifteen minutes, and then must be left off for 15 minutes before it is turned on again. SX Mix Manual 2006-12-11/15:22... -
Page 5: Introduction
Dual function switches: Color wheel: select sound active or continuous rotation Moonflower: select sound active or continuous rotation Electronic transformer Fan cooled Product Overview Hanging Bracket Focusing Lens Moonflower Mode Switch Microphone SX Mix Manual Gobo Mode Switch Fuse Power Cord 2006-12-11/15:22... -
Page 6: Setup
Remove the lamp from the socket. Hold the new lamp with a lint-free c Insert the lamp into the socket. Reinsert the lamp into the fixture. Replace the top cover. SX Mix Manual Figure A loth. Figure B 2006-12-11/15:22... -
Page 7: Fuse Replacement
Use the gobo mode switch to set the mode of rotation (up = continuous rotation mode, down = sound-active mode). Turn the focusing lens to focus the beam onto your projection surface. SX Mix Manual The fuse is located inside this compartment. -
Page 8: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. -
Page 9: Technical Support
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 10: Claims
Power Consumption ...228W Max Inrush Power ... 252W LIGHT SOURCE Lamp...ELC3 24V 250W Lamp PHOTO OPTIC Beam Angle ... 35° THERMAL Maximum ambient temperature...95°F (35°C) ORDERING INFORMATION SX Mix ... SX-MIX WARRANTY INFORMATION Warranty ... 1-year limited warranty SX Mix Manual 2006-12-11/15:22...
