Chauvet Q-Spot 150 Supplementary Manual

DMX Channel Values (16 Bit)
  
D
EFAULT
1 1 1
2 2 -> 3 <-
3 -> 2 <-
4 4
5 5
3
6 6
4 7 7
5 8 8
6 9 9
Q-Spot & Q-Spot 150 User Manual

V
ALUE
Pan
000  255
1
Left > Right ( 128 = center)
000  255
Tilt
2
Up > Down (128 = center)
000  255
Pan (Fine)
000  255
Tilt (Fine)
Pan/Tilt Speed & Reset
000  000
Max. Speed (tracking mode)
001  001
Max. Speed (vector mode)
002  200
Speed (vector): Max > Min
201  204
3
Fixture reset (hold 10 sec)
205  255
Max. Speed, blackout while in color change (tracking mode)
Max. Speed, blackout while in Pan/Tilt movement and or color and
gobo changes (tracking mode)
Shutter/Strobe/Dimmer
000  003
Blackout
004  063
Dimmer: Closed > Open (0-100%)
064  095
Variable strobe: Slow > Fast
096  159
4
Open
160  191
Pulse strobe in sequence: Slow > Fast
192  223
Pulse strobe in sequence: Fast > Slow
224  255
Open
Rotating Gobo Wheel
000  015
Open
016  031
Gobo 1
032  047
Gobo 2
048  063
Gobo 3
064  079
Gobo 4
080  095
Gobo 5
096  111
Gobo 6
112  127
Gobo 7
128  132
5 Open
133  144
Gobo 1 (variable bounce)
145  156
Gobo 2 (variable bounce)
157  168
Gobo 3 (variable bounce)
169  180
Gobo 4 (variable bounce)
181  192
Gobo 5 (variable bounce)
193  204
Gobo 6 (variable bounce)
205  216
Gobo 7 (variable bounce)
217  228
Open
229  255
Gobo spin: Slow > Fast
Color Wheel
000  012
White (Open)
013  024
Red
025  037
Blue
038  049
Yellow
050  062
Green
063  074
Pink
075  087
6 UV
088  099
Light Blue
100  112
Orange
113  127
Purple
128  190
Linear color change with movement of slider (color-splits)
191  220
Rainbow effect: Fast > Slow (clockwise)
221  225
Stop
226  255
Rainbow effect: Fast > Slow (counter-clockwise)
Gobo Rotation & Indexing
000  127
Gobo Index
128  189
7 Clockwise gobo rotation: Fast > Slow
190  193
No Rotation
194  255
Counter clockwise gobo rotation: Slow > Fast
