LEDrain™38
Snapshot
Ok on Dimmer
Outdoor OK
Sound Activated
DMX/Master/Slave
115V/230V Switch
Replaceable Fuse
User Serviceable
Duty Cycle
USER MANUAL
th
CHAUVET, 3000 N 29
Ct, Hollywood, FL 33020 U.S.A
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
2007-11-28/10:08

Advertisement

Table of Contents
loading

Related Manuals for Chauvet LEDrain 38

Summary of Contents for Chauvet LEDrain 38

  • Page 1 LEDrain™38 Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX/Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2007-11-28/10:08...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS BEFORE YOU BEGIN... 3 ... 3 HAT IS INCLUDED ... 3 NPACKING NSTRUCTIONS AC P ... 3 OWER ... 3 AFETY NSTRUCTIONS INTRODUCTION ... 4 ... 4 EATURES DMX C ... 4 HANNEL UMMARY ... 5 RODUCT VERVIEW SETUP ...

  • Page 3: Before You Begin

    Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET. LEDrain™38 User Manual • Secure fixture to fastening device using a safety chain.

  • Page 4: Introduction

    NTRODUCTION Features CONTROL FEATURES • 7-channel DMX-512 LED narrow beam • Blackout/static/dimmer/strobe • Selector switch for sound active or automatic mode • Static colors and RGB color mixing in master/slave mode via dip switches ADDITIONAL FEATURES • Additional power output for daisy chaining units together (max 50 units) •...

  • Page 5: Product Overview

    Product Overview Fuse Holder Power Input Connector DMX dipswitches: DMX channel addressing Min-Max rotary knob LEDrain™38 User Manual DMX Connectors Green LED Status ON - signifies the par can is set to be controlled via DMX OFF – Par can is set to either Automatic or Sound Active mode as previously selected by the Music/Auto switch...

  • Page 6: Setup

    ETUP Power This fixture has an auto-switching power supply that can accommodate a wide range of input voltages. The only thing necessary to do before powering on the unit is to make sure the line voltage you are applying is within the range of accepted voltages.

  • Page 7: Operating Instructions

    PERATING NSTRUCTIONS The LEDrain™38 is a DMX-512 controllable, full RGB color mix par can made up of highly efficient and bright LEDS measuring 10mm in diameter. All red, green and blue LEDs can be controlled separately allowing the creation of an unlimited range of colors. The LEDrain™38 can operate in Stand-Alone, Master/Slave and via DMX-512 control utilizing 6 DMX channels.

  • Page 8: Dmx Control Mode

    DMX Control Mode Operating in a DMX Control mode environment gives the user the greatest flexibility when it comes to customizing or creating a show. In this mode you will be able to control each individual trait of the fixture and each fixture independently. The LEDrain™38 uses 7 channels of control. Note: Dipswitch 10 must be turned on to activate DMX control mode.

  • Page 9: Appendix

    XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)

  • Page 10: Dmx Channel Values

    DMX Channel Values HANNEL ALUE 255 Red: ( 0% ~ 100% ) 255 Green: ( 0% ~ 100% ) 255 Blue: ( 0% ~ 100% ) Macro Colors (By LED levels) Red: 100% Green: 20% Red: 100% Green: 40% Red: 100% Green: 60% Red: 100% Green: 80% Red: 100% Green: 100% Blue: Red:...

  • Page 11: Returns Procedure

    Be prepared to provide the model for the r turn. Be sure to properly pack fixture, an packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to repair or replace product(s). As a suggestion, prop thod to use.

  • Page 12: Dmx Dipswitch Quick Reference Chart

    DMX Dipswitch Quic k Reference Chart DMX Address Quick Reference Chart DMX DIP 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0...

  • Page 13: Technical Specifications

    Technical Specifications WEIGHT & DIMENSIONS Length... 7.5 in (191 mm) Width ... 6.8 in (173 mm) Height ..Weight OWER Auto-s witc hing pow r su Power consumptio ... rush ... 18W wer output connector ... 50 units max LIGH SOURCE D...
