Security/Filter Defines

The Express XL/XLT can filter packets based on certain parameters within the
packet. The method used by the Express XL/XLT allows the highest flexibility
for defining filters and assigning them to a Connection List profile. The filters
are set up in two steps: (1) defining the packet types, and (2) adding them to a
list under the Connection List profile. See the section Connection List/Filters on
page 79 for examples of how to set up filter profiles. This menu is used to de-
fine the individual filter defines based on packet type.

Filter Defines /MAC Filter Defines

Write security: 2; Read security: 3
The MAC filter is applied to bridge packets only. Bridge packets which are for-
warded by the bridge functionality of the Express XL/XLT are defined here.
Up to 32 MAC defines can be specified.
Name
Src Addr
Src Mask
Dest Addr
Dest Mask
MAC Type
Type Msk
61200070L1-1
Chapter 3: Terminal Menu Operation and Structure
Identifies the filter entry
48-bit MAC source address used for comparison.
(hexadecimal format)
Bits in the MAC source address which
are compared. (hexadecimal format)
48-bit MAC destination address used
for comparison. (hexadecimal format)
Bits in the MAC destination address used
for comparison. (hexadecimal format)
16-bit MAC type field used for comparison.
(hexadecimal format)
Bits in the MAC type field used for comparison.
(hexadecimal format)
Express XL/XLT User Manual 59
