Call Sessions/Session1 and Call Sessions/Session2

Read security: 5
The Express XL/XLT can support up to two active connections at one time.
These two menus reflect the results of PPP negotiations, user name, time con-
nected, idle timer, and data rates for the session.
PPP Links - Reflects LCP layers active
BCP - Shows UP if PPP Bridge Control Protocol has negotiated
successfully
IPCP - Shows UP if PPP IP Control Protocol has negotiated
successfully
IPXCP - Shows UP if PPP IPX Control Protocol has negotiated
successfully
CCP - Shows UP if PPP Compression Control Protocol has negotiated
successfully
BACP - Shows UP if PPP Bandwidth Allocation Control Protocol has
negotiated successfully
User - Displays the user name of the PPP peer
Number(s) - Shows the phone number dialed if outgoing call or caller
ID if incoming call.
Connect Time - Shows the date and time when the call last connected.
Up Time - Displays how long the call has been connected.
Idle Timer - Current value of the idle timer (number of seconds since
filtered packet was passed through).
Tx Pkts - Number of packets transmitted
Rx Pkts - Number of packets received
Tx Bytes - Number of bytes transmitted
Rx Bytes - Number of bytes received
Tx Rate - Current application data transmission rate
Rx Rate - Current application data reception rate
