Lorex C883DA Series Quick Start Manual

Package Contents
• 4K Ultra HD Active Deterrence Security Camera
• Mounting Kit*
• BNC / Power Extension Cable*
• Power Adapter**
* Per camera in multi-camera packs.
** A multi-camera power adapter that provides power to multiple cameras
or individual power adapters may be provided depending on product
configuration.
ATTENTION:
A REGULATED UL / CSA APPROVED power supply is REQUIRED for use with this
camera (included). Use of a non-regulated, non-conforming power supply can
damage this product and voids the warranty.
Using Deterrence Features
Use your Lorex app to manually activate the camera's white light and siren
features when connected to a compatible Lorex recorder.
PREREQUISITE: Connect to your Lorex system using the app
specified in your recorder documentation.
To activate deterrence features manually:
1. Launch the app and tap your recorder to view connected channels.
2. Tap a connected deterrence camera to open it in single-channel view.
(A) to activate the white light, or tap
3. Tap
Lorex Home
B A
NOTE: You can also set schedules and active areas of the camera image where the
white light will be triggered automatically when motion is detected. For full instructions,
refer to the app manual on your product page at lorex.com.
C883DA_QSG_EN_R1.indd 1 C883DA_QSG_EN_R1.indd 1
Resources
1
Visit lorex.com
Search for the model
2
number of your product
Click on your product
3
in the search results
4
Click on the Downloads tab
Dimensions
2.85"
72.5mm
(B) to activate the siren.
Lorex Cloud
Safety Precautions
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle with care.
• Use the camera within given temperature, humidity and voltage levels noted in the
camera's specifications.
• Do not disassemble the camera.
• Do not point the camera directly towards the sun or a source of intense light.
A
• Use only the supplied regulated power supply provided with the product. Use of a
non-regulated, non-conforming power supply can damage the product and void the
B
warranty.
• Periodic cleaning may be required. Use a damp cloth only. Do not use any harsh,
chemical-based cleaners.
• The supplied cable is rated for surface and in-wall mounting only. Cables for floor-
to-floor installations are sold separately (CMR type). These and other cables are
available at lorex.com.
Disclaimers
• For a full list of compatible recorders, visit lorex.com/compatibility.
• To ensure that you are viewing camera video in full 4K resolution (4K monitor
required), check the video output resolution of your recorder. For full instructions, see
your recorder's documentation at lorex.com.
• Not intended for submersion in water. Installation in a sheltered location
recommended.
• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes
between Day/Night viewing modes, an audible clicking noise may be heard from the
camera. This clicking is normal, and indicates that the camera filter is working.
Copyright © 2020 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to
modify product design, specifications and prices, without notice and without incurring
any obligation. E&OE. All rights reserved.
Need Help?
Visit us online for up-to-date software
and complete instruction manuals
6.46" / 164mm
3.27"
83mm
C883DA_QSG_EN_R1
4K Ultra HD Active Deterrence
Security Camera
Quick Start Guide
English Version 1.0
C883DA Series
lorex.com
2020-04-15 11:24:57 AM 2020-04-15 11:24:57 AM
