Using Your Documentation

Your machine includes the following documentation. This documentation has been designed so that you can
easily use your machine to suit your particular needs.
Setting up the machine......................................
Setting up paper ..............................................
Installing Printer Driver .....................................
Document and paper handling .............................
Making copies ................................................
Maintenance ..................................................
Troubleshooting feed and copy issues ....................
Sending and receiving faxes ...............................
Speed dialing .................................................
Troubleshooting fax issues .................................
Printing with CAPT (Canon Advanced Printing Technology) ..
Checking the status of a print job..........................
Troubleshooting CAPT issues...............................
• Guides with this symbol are PDF manuals included on the accompanying CD-ROM.
• To view the manual in PDF format, Adobe Reader/Acrobat Reader/Acrobat is required. If Adobe
NOTE
Reader/Acrobat Reader/Acrobat is not installed on your system, please download it from the Adobe
Systems Incorporated website (http://www.adobe.com).
Copyright
Copyright ©2004 by Canon, Inc. All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or computer language in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise, without the prior written
permission of Canon, Inc.
Trademarks
Canon is a registered trademark and UHQ (Ultra High Quality) is a trademark of Canon, Inc.
Set-up Instructions
Basic Guide
Fax Guide
Only for the imageCLASS D880 model
Printer Guide
