- Page 1 Oven HN678G4.1 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Table of contents 1 Safety Observe the following safety instructions. 1.1 General information USER MANUAL ¡ Read this instruction manual carefully. Safety .............. 2 ¡ Keep the instruction manual and the Preventing material damage ....... 6 product information safe for future refer- ence or for the next owner. -
Page 3: Safety
Safety en Hot steam may escape when you open the 1.4 Safe use appliance door. Steam may not be visible, de- Always place accessories in the cooking com- pending on the temperature. partment the right way round. ▶ Open the appliance door carefully. → "Accessories", Page 13 ▶... - Page 4 en Safety ▶ Never operate an appliance with a cracked ▶ Do not leave food unattended while it is or fractured surface. heating in containers made of plastic, pa- ▶ Never pull on the power cord to unplug the per or other combustible materials. appliance.
- Page 5 Safety en The accessible parts of the appliance become Cookware and containers made from metal or hot during operation. cookware with metal edging may lead to ▶ Never touch these hot parts. sparks being formed during simple mi- ▶ Keep children at a safe distance. crowave operation.
- Page 6 en Preventing material damage ▶ Keep children at a safe distance. Hot liquid may spill over the sides of the ac- If the door seal is damaged, a large amount cessory when it is removed from the cooking of heat is generated around the door. compartment.
-
Page 7: Preventing Material Damage
Preventing material damage en Never place cookware containing water on the Using accessories directly on top of one another ▶ cooking compartment floor. causes sparks. The prolonged presence of moisture in the cooking Do not combine the wire rack with the universal ▶... -
Page 8: Environmental Protection And Saving En- Ergy
en Environmental protection and saving energy 3 Environmental protection and saving energy 3.1 Disposing of packaging The packaging materials are environmentally compat- ible and can be recycled. Sort the individual components by type and dispose ▶ of them separately. 3.2 Saving energy If you follow these instructions, your appliance will use less power. -
Page 9: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 4 Familiarising yourself with your appliance 4.1 Control panel Buttons The buttons on the left- and right-hand side of You can use the control panel to configure all functions the control panel have a pressure point. Press of your appliance and to obtain information about the a button to execute its function. - Page 10 en Familiarising yourself with your appliance Countdown Lighting You can view the countdown time or the cooking time One or more oven lights illuminate the cooking com- for the previous operation in the top right in the status partment. bar. When you open the appliance door, the light in the If you have set a cooking time and the cooking time is cooking compartment switches on.
-
Page 11: Operating Modes
Operating modes en 5 Operating modes This is where you can find an overview of your appli- Operating ance's operating modes and main functions. mode Press to open the menu. Descaling You can use this to remove limescale from the evaporator. Operating → "Descaling", Page 32 mode... - Page 12 en Operating modes Symbol Types of heating Temperature What it's used for and how it works range Possible additional options Pizza setting 30–275 °C Cook pizza or dishes that require a lot of heat from below. The bottom heating element and the ring-shaped heating ele- ment in the back wall heat the cooking compartment.
-
Page 13: Accessories
Accessories en 6 Accessories Use original accessories. These have been made espe- cially for your appliance. Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the ac- cessory cools down, it will regain its original shape. The accessories supplied may differ depending on the appliance model. -
Page 14: 7.1 Before Using For The First Time
You will find a comprehensive range of products for your appliance in our brochures and online: www.siemens-home.bsh-group.com Accessories vary from one appliance to another. When purchasing accessories, always quote the exact Note: The pull-out rails lock in place when they are product number (E no.) of your appliance. -
Page 15: Basic Operation
If you cancel the operation completely, the settings are ‒ reset. a The Siemens logo appears in the display. A type of heating and a temperature are then displayed. To pause the operation briefly: Briefly press ... - Page 16 en Rapid heating Changing the temperature a The set type of heating, temperature and cooking time/appliance run time are shown in the display. Once the operation has started, you can change the When the food is ready, press to switch the temperature directly.
- Page 17 Time-setting options en Press . The type of heating and temperature settings are Use the rotary selector to change the timer duration. shown in the display. Press to confirm. 10.4 Setting the end time Cancelling the timer You can cancel the timer duration at any time. You can delay the time at which cooking is due to fin- ish by up to 23 hours and 59 minutes.
- Page 18 en Steam 11 Steam Food can be cooked particularly gently using steam. Fill the water tank with water up to the "max" You can use the special types of steam heating, or use mark. steam assistance with certain types of heating. WARNING ‒ Risk of scalding! Hot steam may escape when you open the appliance door.
-
Page 19: Steam
Steam en Press the cooking time. In the operating modes menu, set the "Types of Use the rotary selector to set the cooking time. heating". Press to start the operation. Use the rotary selector to set the type of heating. Press the temperature. Note: If the water tank runs dry during operation, a Use the rotary selector to set the temperature. -
Page 20: Microwave
en Microwave Clean the water tank with a soft cloth and standard ▶ Drying the cooking compartment washing-up liquid. Dry the cooking compartment after each steam opera- tion. Note: Once the appliance has been switched off, the button remains lit for a little longer to remind you to Dry the cooking compartment by hand or use the ▶... - Page 21 Microwave en ATTENTION! Cookware and ac- Information cessories Operating the appliance without food in the cooking compartment may lead to overloading. Serving dishes You do not need to transfer Do not switch on the microwave unless there is food ▶ your food. inside.
- Page 22 en Microwave ¡ → "Preventing material damage", Page 6 a The microwave starts and the cooking time counts down. ¡ ¡ → "Cookware and accessories with microwave", a Once the cooking time has elapsed, an audible sig- Page 20 nal sounds. The time shown in the display is zero. Once the cooking time has elapsed: Press ...
- Page 23 Meat probe en 13 Meat probe Cook with precision by inserting the meat probe into Thick Insert the meat probe diagonally into the the food and setting a core temperature on the appli- pieces meat from above, pushing it in as far as ance.
- Page 24 en Meat probe Changing the type of heating 13.3 Setting the meat thermometer When you change the type of heating, the other set- The roasting sensor measures the temperature inside tings are also reset. the food between 30 °C and 99 °C. Press to pause operation. Requirements Press the type of heating.
-
Page 25: Meat Probe
Dishes en Other Core temperature Other Core temperature in °C in °C Meat loaf, all kinds of meat 80 - 90 Heating food, reheating 65 - 75 14 Dishes The "Dishes" operating mode helps you to use your ap- Meat probe pliance to prepare different meals by selecting the op- You can use the meat probe for several dishes. - Page 26 en Dishes 14.5 Adjusting the dish Category Foods Poultry Chicken Note: Once it has started, you can no longer change or Duck, goose interrupt the dish or the settings. Turkey Requirement: To start the operation, the cooking com- Meat Pork partment must be cooled down. Beef Press ...
-
Page 27: Childproof Lock
Childproof lock en 15 Childproof lock You can secure your appliance to prevent children a A confirmation notification appears on the display. from accidentally switching it on or changing the set- a The appears in the status bar when the appliance tings. -
Page 28: Sabbath Mode
en Cleaning and servicing 17.2 Changing the basic settings Basic setting Selection After switch-on Main menu Press . Types of heating Press . Microwave a The operating modes menu opens. Microwave combination Select the "Settings" operating mode. Steam a The first basic setting appears. Dishes Press to switch between the different settings. -
Page 29: Cleaning And Servicing
Cleaning and servicing en Appliance front Surface Suitable cleaning agents Information Stainless steel ¡ Hot soapy water To prevent corrosion, remove any limescale, grease, starch or albu- min (e.g. egg white) stains on stainless steel fronts immediately. ¡ Special stainless steel cleaning products Apply a thin layer of the stainless steel cleaning product with a soft cloth. - Page 30 en Self-cleaning Area Suitable cleaning agents Information Water tank ¡ Hot soapy water To remove residual detergent after cleaning, rinse thoroughly with clean water. To dry the water tank after cleaning, leave the water tank to dry with the lid open. Dry the seal on the lid. Do not clean in the dishwasher.
- Page 31 Cleaning assistance en a The cleaning function starts and the duration counts WARNING ‒ Risk of burns! down. The heating line does not appear. The cooking compartment gets very hot when the a For your safety, the appliance door locks once a cleaning function is in progress. certain temperature is reached in the cooking com- Never open the appliance door.
-
Page 32: Drying
en Descaling Clean the smooth surfaces in the cooking compart- Remove limescale with a cloth soaked in vinegar. ment with a dish cloth or a soft brush. Remove stub- Then wipe with clean water and rub dry with a soft born food remnants using a stainless steel scouring cloth (including under the door seal). - Page 33 Appliance door en Remove coarse dirt from the cooking compartment Press to start the drying function. and wipe away moisture from the cooking compart- a The appliance starts to dry and the duration counts ment floor. down. Press . Once the duration has elapsed: In the operating mode menu, press the drying oper- A message appears in the display.
- Page 34 en Appliance door Push the left- and right-hand retainer downwards WARNING ‒ Risk of serious harm to health! until the intermediate pane is clamped . If the screws are undone, the safety of the appliance can no longer be guaranteed. Microwave energy may escape.
- Page 35 Rails en 24 Rails To thoroughly clean the rails and the cooking compart- Hook the front retainers in at the bottom and ment, or to replace the rails, you can remove the rails. straighten them . 24.1 Detaching the rails WARNING ‒ Risk of burns! The shelf supports get very hot Never touch the shelf supports when hot.
- Page 36 en Troubleshooting 25 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after- sales service. This will avoid unnecessary costs. WARNING ‒ Risk of injury! WARNING ‒ Risk of electric shock! Improper repairs are dangerous. Incorrect repairs are dangerous. Repairs to the appliance should only be carried out Repairs to the appliance should only be carried out ▶...
-
Page 37: Troubleshooting
Troubleshooting en Fault Cause and troubleshooting The control panel There has been a power cut. cannot be opened. Check whether the lighting in your kitchen or other appliances are working. ▶ Malfunction Call the after-sales service. → "Customer Service", Page 38 If there is water in the water tank, empty the water tank: Open the appliance door. -
Page 38: Disposal
Next time, set lower or higher values. ▶ Tip: A lot of information about the food preparation and corresponding setting values can be found on our website www.siemens-home.bsh-group.com . 26 Disposal Find out here how to dispose of old appliances cor- This appliance is labelled in accord- rectly. -
Page 39: How It Works
How it works en 28 How it works Here, you can find the ideal settings for various types Baking on two or more levels Shelf position of food as well as the best accessories and cookware. 3 levels We have perfectly tailored these recommendations to ¡... - Page 40 en How it works ¡ Follow the manufacturer's instructions for your roast- ¡ The food transfers heat to the cookware. The cook- ing dishes. ware can become very hot. ¡ In the main part of the instruction manual, you will Roasting in uncovered cookware find information on how to configure the microwave ¡...
- Page 41 How it works en 28.7 List of foods Recommended settings for a variety of foods, sorted into food categories. Recommended settings for various types of food Food Accessory/ Shelf pos- Heating Temperat- Microwave Steam in- Cooking time cookware ition function ure in °C power set- tensity in mins...
- Page 42 en How it works Food Accessory/ Shelf pos- Heating Temperat- Microwave Steam in- Cooking time cookware ition function ure in °C power set- tensity in mins → Page 11 ting in W Bread, without a tin, Universal pan 1. 210– 1. 10–15 750 g 2.
- Page 43 How it works en Food Accessory/ Shelf pos- Heating Temperat- Microwave Steam in- Cooking time cookware ition function ure in °C power set- tensity in mins → Page 11 ting in W Small chicken por- Wire rack 220 - 230 - 30 - 35 tions, 250 g each Small chicken por- Wire rack...
- Page 44 en How it works Food Accessory/ Shelf pos- Heating Temperat- Microwave Steam in- Cooking time cookware ition function ure in °C power set- tensity in mins → Page 11 ting in W Meat loaf, 1 kg, + Uncovered 170 - 190 360 30 - 40 20 ml water cookware Fish, grilled, whole,...
- Page 45 How it works en Recommended settings for desserts and compote Food Accessory/ Shelf pos- Heating Temperat- Microwave Steam in- Cooking cookware ition function ure in °C power set- tensity time in → Page 11 ting in W mins Blancmange made Covered cook- 5 - 8 from blancmange ware powder...
- Page 46 en How it works Final fermentation: Place the dough in the specified shelf position. ‒ Continue processing the dough and turn it into Wipe the cooking compartment dry before baking. ‒ the final shape for baking. Recommended settings for proving dough Food Accessory/cookware Shelf posi- Heating func-...
- Page 47 How it works en surface. Even if the container only vibrates a little, the Warming up and reheating food hot liquid may suddenly boil over and spatter. Your appliance offers you various ways of warming up Always place a spoon in the container when heating ▶...
- Page 48 en How it works 28.9 Test dishes The information in this section is provided for test institutes to facilitate testing of the appliance in accordance with EN 60350-1:2013 or IEC 60350-1:2011 and EN 60705:2012 or IEC 60705:2010. Baking ¡ The setting values apply to food that is placed into a Baking tray: Shelf position 1 cold cooking compartment.
-
Page 49: 29.1 General Installation Instructions
Installation instructions en Recommended settings for grilling Food Accessory/cookware Shelf posi- Heating func- Temperature Cooking time in tion tion in °C/grill set- mins → Page 11 ting Toasting bread Wire rack 3–5 Do not preheat the appliance. Microwave cooking ¡ If you use the wire rack, slide it into the cooking ¡... - Page 50 en Installation instructions between the wall and the cabinet base as ¡ For appliances that have a hinged switch well as the rear panel of the cabinet situ- panel, make sure that the switch panel ated above. does not hit adjacent kitchen units when ¡...
- Page 51 Installation instructions en ¡ To ventilate the appliance, the intermediate floor 29.3 Installation below a worktop must have a ventilation cut-out. Observe the installation dimensions and the installation ¡ The worktop must be secured to the built-in unit. instructions when installing below a worktop. ¡...
- Page 52 en Installation instructions ¡ To ensure that the appliance door can be opened, 29.5 Installation in a tall unit you must take the minimum dimensions into consid- Observe the installation dimensions and the installation eration when installing in a corner. The dimension instructions when installing in a tall unit.
- Page 53 Installation instructions en 29.8 Installing the appliance Slide the appliance all the way in and centre it. Screw the appliance into place. Note: The gap between the worktop and the appliance must not be closed by additional battens. Thermal insulation strips must not be fitted to the side panels of the surround unit.
- Page 56 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001619893* 9001619893 (010712)
