INSTALLATION
GUIDE
GUIDE
D'INSTALLATION
GUIA DE
INSTALACION
Model/Modele/Modelo
T24UR925RS
T24UR925LS
T24UR915RS
T24UR915LS
T24UR905RP
T24UR905LP
Glass Door Refrigerator
Verre Porte Frigo
Refrigerador Puerta de Vidrio
Page | 1

Advertisement

Table of Contents
loading

Summary of Contents for Thermador T24UR925RS

  • Page 1 INSTALLATION Model/Modele/Modelo T24UR925RS GUIDE T24UR925LS T24UR915RS T24UR915LS GUIDE T24UR905RP T24UR905LP D'INSTALLATION Glass Door Refrigerator GUIA DE Verre Porte Frigo Refrigerador Puerta de Vidrio INSTALACION Page | 1...
  • Page 2: Table Of Contents

    IMPORTANT: Before you begin, read these instructions completely and carefully. INSTALLER: Please leave this manual with owner for future reference. OWNER: Save these installation instructions for local electrical inspector’s use and for future reference. Table of Contents ….…………. 3 Important Safety Instructions Inspect the Glass Door Refrigerator Tools needed for installation ……………..
  • Page 3: Important Safety Instructions

    Important Safety Instructions READ AND SAVE THESE INSTRUCTIONS! These installation instructions are intended for use by qualified installers. In addition to these instructions, the appliance shall be installed: • In the United States, in accordance with the National Electric Code/State and municipal codes and/or local codes.
  • Page 4: Tools Needed For Installation

    Tools needed for installation Tape Measure Philips Screwdriver Level These are the tools that you may need for the installation of the appliance. However, if you need to modify the counter or cabinetry to fit the unit, you may need other tools to make counter/cabinetry modifications before installing the appliance.
  • Page 5: Installing The Appliance

    Installing the appliance Most of the installation work must be done before the Glass Door Refrigerator is moved into place. Have a qualified technician install and connect the appliance according to the enclosed installation instructions. WARNING: Do not install this appliance: - Outdoors - In an environment with dripping water - In rooms where there is a risk of frost...
  • Page 6: Installation Location

    Installation location A dry, well ventilated room is suitable as an installation location. The installation location should not be exposed to direct sunlight and not placed near a heat source, e.g. a cooker, radiator, etc. If installation next to a heat source is unavoidable, use a suitable insulating plate or observe the following minimum distance from the heat source: ▪...
  • Page 7 TOP VIEW OPEN RIGHT SWING TOP VIEW OPEN LEFT SWING Page | 7...
  • Page 8: Installing Side-By-Side

    Installing Side-by-Side The appliance can be installed next to another Thermador appliance. Follow the next dimensions and notes for the correct installation of the appliance in a side-by-side layout. NOTE: Before placing the unit into the niche, adhere the Insulating Foam (included with the product) on the side of the unit that will be placed next to the additional appliance.
  • Page 9: Ventilation

    Do not place one appliance with Right Hinge next to an appliance with a Left Hinge. 1226mm 48 1/4 in 13mm 607mm 607mm ½ in 23 7/8 in 23 7/8 in (MÍNIMUM) Interference Ventilation The Glass Door Refrigerator unit is ventilated only at the Toe-Kick in the base. Never cover that area or place anything in front of it.
  • Page 10: Electrical Connection

    Electrical connection WARNING: These installation instructions are intended for use by qualified installers. WARNING: Avoid the risk of an electric shock! Insert into a grounded receptacle. Never remove grounding phase. Do not use any adapters. Do not use any extension cords. WARNING: It is the customer’s responsibility to ensure that the appliance installation is in compliance with all national and local electrical codes and ordinances.
  • Page 11: Door Opening

    WARNING: Never connect the appliance to electronic energy saver plugs. This appliance can be used with mains and sine-controlled inverters. Main controlled inverters are used for photovoltaic systems which are connected directly to the national grid. Sine-controlled inverters must be used for isolated applications (e.g. on ships or in mountain lodges) which are not connected directly to the national grid.
  • Page 12 2. Grab the stopper pin from the bag included with this appliance and insert into the hole as shown: 3. Push firmly to ensure the stopper pin has locked into the hinge. Now, the door opens only 90°. METALLIC RIB OPEN SLOT Page | 12...
  • Page 13: Installing The Anti-Tip-Brackets

    Installing the anti-tip-brackets The appliance includes two anti-tip-brackets. If your cabinetry is not designed for the specific dimensions of your appliance, or if you plan to use the appliance as a free-standing unit, you should use these brackets to avoid your appliance tilting due to unbalanced overweight situations where the door is open. For free-standing use 1.
  • Page 14 3. Peel the adhesive foam and paste the anti-tip-bracket at both sides on the back of the appliance as shown in the illustrations. Paste the anti-tip-bracket to the back of the appliance. 4. With the anti-tip-brackets pasted on the back of the appliance, slide the appliance to the wall until the anti-tip-bracket is touching the wall.
  • Page 15 For under counter use 1. Consider the distance necessary for the appliance to be flush with the front of your cabinetry. 600mm Thermador Glass Door 23 5/8” Refrigerator Top View Unit 2. Take the measurement from the top of the cabinet of the unit to the bottom of the counter.
  • Page 16 4. Peel the adhesive foam and paste the anti-tip-bracket at the front on the top of the cabinet of the appliance, near the corners as shown in the picture: Paste the anti-tip-bracket near the corners. 5. Slide the appliance into the cabinet until the front of the appliance is flush with the front of the cabinetry.
  • Page 17: Installing The Overlay Frame

    Installing the overlay frame (For T24UR905LP and T24UR905RP models only) If you plan to install a custom overlay frame, you will need to create the frame yourself or consult a qualified cabinetmaker or carpenter. A full sized template for easier hole pattern marking is included in the manual package. IMPORTANT: - The thickness of the overlay frame must be ¾”...
  • Page 18 IMPORTANT: It is recommended to install the custom overlay frame with the help of another person. 1. Install the custom handle of your preference on the overlay frame before installing the frame on the door. - Every custom handle is different and it is the responsibility of the customer to make the necessary adjustments to place the handle on the overlay frame.
  • Page 19 3. Remove the door gasket from the corners, by pulling it gently until the four screws are visible. Then remove the two screws further to the corner. The two holes shown on the below illustration must be accessible to screw (install) the custom overlay frame to the door. There should be 8 accessible holes in total, two per corner.
  • Page 20 5. Once the overlay frame is securely attached to the door with the 8 screws, put the gasket back in its place pressing it against the door until all is even and firm into its channel. Put gasket back in its place 6.
  • Page 21: Customer Service Information

    (in the order listed below) until the problem is corrected to your satisfaction. 1. Contact your dealer or the Thermador Authorized Servicer in your area. 2. E-mail us from the Customer Service section of our web site, www.Thermador.com. 3. Write to us at the address below: BSH Home Appliances Corporation...
  • Page 22: Addendum A

    Addendum A. Detailed dimensions for Overlay Frame. Important Ø5/16” (8mm) Hole. Depth: ¼” (7mm) - The thickness of the overlay Cutout depth: 3/16” (4mm) frame must be ¾” (19mm). - Overlay frame must not weigh Ø1/2” (12mm) Hole. Depth: ¼” (7mm) more than 10lbs (4.54kg).
  • Page 23 Data Rating Label The data rating label shows the model and serial number of your appliance. It is located in the interior of the cabinet, at the opposite side of the hinge. Service Information For handy reference, copy the information in the form below from the data rating located in the interior of the cabinet, at the opposite side of the hinge.
  • Page 24 PN: ARAH1E105040 / 8001025785 T24UR925RS T24UR925LS T24UR915RS 04/2021 T24UR915LS Printed in Me xi c o Impreso en Mé xi c o T24UR905RP Imprime au Me xiqu e T24UR905LP Page | 24...
