- Page 1 INSTALLATION Model/Modele/Modelo GUIDE T24UC925DS T24UC915DS GUIDE T24UC905DP D'INSTALLATION Refrigerator Freezer Drawers Réfrigérateur Congélateur Tiroirs Refrigerador de doble cajón con congelador GUIA DE INSTALACION Page | 1...
-
Page 2: Table Of Contents
IMPORTANT: Before you begin, read these instructions completely and carefully. INSTALLER: Please leave this manual with owner for future reference. OWNER: Save these installation instructions for local electrical inspector’s use and for future reference. Table of Contents ….…………. 3 Important Safety Instructions Inspect the Refrigerator Tools needed for installation …………….. -
Page 3: Important Safety Instructions
Important Safety Instructions READ AND SAVE THESE INSTRUCTIONS! These installation instructions are intended for use by qualified installers. In addition to these instructions, the appliance shall be installed: • In the United States, in accordance with the National Electric Code/State and municipal codes and/or local codes. -
Page 4: Tools Needed For Installation
Tools needed for installation Tape Measure Philips Screwdriver Level Flat-blade screwdriver Adjustable wrenches ¹ ₄" Nut driver ¼” Drill bit & drill These are the tools that you may need for the installation of the appliance. However, if you need to modify the counter or cabinetry to fit the unit, you may need other tools to make counter/cabinetry modifications before installing the appliance. -
Page 5: Installing The Appliance
Installing the appliance Most of the installation work must be done before the Refrigerator is moved into place. Have a qualified technician install and connect the appliance according to the enclosed installation instructions. WARNING: Do not install this appliance: - Outdoors - In an environment with dripping water - In rooms where there is a risk of frost Transporting... -
Page 6: Installation Location
Installation location A dry, well ventilated room is suitable as an installation location. The installation location should not be exposed to direct sunlight and not placed near a heat source, e.g. a cooker, radiator, etc. If installation next to a heat source is unavoidable, use a suitable insulating plate or observe the following minimum distance from the heat source: ▪... -
Page 7: Installing Side-By-Side
Installing Side-by-Side The appliance can be installed beside another Thermador appliance. Follow the next dimensions and notes for the correct installation of the appliance in a side-by-side layout. NOTE: Before placing the unit into the niche, adhere the Insulating Foam (included with the product) on the side of the unit that will be placed next to the additional appliance. - Page 8 One Double Drawer and one swing door appliance: opening of the door should be opposite to the Double Drawer to avoid interference or damage by hitting. 1224mm 48 3/16 in 13mm 607mm 607mm ½ in 23 7/8 in 23 7/8 in (MÍNIMUM) 90°...
-
Page 9: Ventilation
Ventilation The Refrigerator unit is ventilated only at the Toe-Kick in the base. Never cover that area or place anything in front of it. Otherwise the refrigeration cooling performance will be affected and the unit must work harder increasing power consumption. Additionally, make certain all 4 leveling legs are extended (unit height approximately 34 ¾”), so that there is sufficient airflow underneath the appliance. - Page 10 5. Using a cordless drill, drill a ¹ ₄" hole in the cold water pipe you have selected. 6. Fasten the shutoff valve to the cold water pipe with the pipe clamp. Be sure the outlet end is solidly in the ¹ ₄" drilled hole in the water pipe and that the washer is under the pipe clamp. Tighten the packing nut.
-
Page 11: Electrical Connections
After installing the appliance, wait at least 1 hour to turn on the appliance. During transportation the oil in the compressor may have flowed into the refrigeration system. Before switching ON the appliance for the first time, clean the interior of the appliance (see chapter “Cleaning the appliance”... -
Page 12: Installing The Anti-Tip-Bracket
WARNING: Never connect the appliance to electronic energy saver plugs. This appliance can be used with mains and sine-controlled inverters. Main controlled inverters are used for photovoltaic systems which are connected directly to the national grid. Sine-controlled inverters must be used for isolated applications (e.g. on ships or in mountain lodges) which are not connected directly to the national grid. - Page 13 Resultant formed “step”. NOTE: The adhesive foam must be at the bottom of the step, never on the reverse side. 3. Peel the adhesive foam and paste the anti-tip-bracket at both sides on the back of the appliance as shown in the illustrations. Paste the anti-tip-bracket to the back of the appliance.
- Page 14 For under counter use 1. Consider the distance necessary for the appliance to be flush with the front of your cabinetry. Screw the bracket to the wall. 2. Take the measurement from the top of the cabinet of the unit to the bottom of the counter. The measurement X”(mm) may vary depending on the design of the counter, extension of the legs of the product, etc.
- Page 15 4. Peel the adhesive foam and paste the anti-tip-bracket at the front on the top of the cabinet of the appliance, near the corners as shown in the picture: 5. Slide the appliance into the cabinet until the front of the appliance is flush with the front of the cabinetry.
-
Page 16: Installing The Overlay Panel
Installing the overlay panel (For T24UC905DP models only) If you plan to install a custom overlay panel, you will need to create the panel yourself or consult a qualified cabinetmaker or carpenter. A full sized template for easier marking the hole pattern is included in the manual package. IMPORTANT: - The thickness of both the overlay panels must be ¾”... - Page 17 Bottom drawer: 1. Install the custom handle of your preference on the overlay panel before installing the panel on the drawer. - Every custom handle is different, and it is the responsibility of the customer to make the necessary adjustments to place the handle on the overlay panel. - The screws used to affix the custom handle to the panel must be flat and flush with the surface of the panel (Fig A);...
- Page 18 2. Remove the gasket from the top corners of the door pulling it gently. Under the gasket in each corner there is a recess with a guide to break through to use as screw positions for the panel. It is not necessary to remove all the gasket, only a portion enough to make the recess accessible.
-
Page 19: Customer Service Information
(in the order listed below) until the problem is corrected to your satisfaction. 1. Contact your dealer or the Thermador Authorized Servicer in your area. 2. E-mail us from the Customer Service section of our web site, www.Thermador.com. 3. Write to us at the address below: BSH Home Appliances Corporation... - Page 20 Data Rating Label The data rating label shows the model and serial number of your appliance. It is located at the right side of the bottom compartment. Service Information For handy reference, copy the information in the form below from the data rating plate located at the right side of the bottom compartment.
- Page 21 PN: ARAH1E1050600 / 8001025790 04/2021 T24UC925DS Printed in Me xico T24UC915DS Impreso en Mé xico Imprime au Me xique T24UC905DP...
