Chamberlain 82LM Quick Start Manual

For use with garage door openers, gate operators or other products that are 390 MHz.
82LM/82LMC
2-Button Remote Control
Compatible with Dip switch devices
See Section A for programming
Compatible with Green Smart/Learn Button devices
See Section B for programming
NOTE: Your product may look different than the products illustrated in this manual.
SECTION A - PROGRAMMING THE REMOTE CONTROL TO DIP SWITCH DEVICES
The Dip switches MUST be set to matching positions in all remote controls used to operate the same device. Follow the instructions described and shown below.
1
Remove the cover.
SECTION B - PROGRAMMING THE REMOTE CONTROL TO SMART/LEARN BUTTON DEVICES
1
TO ERASE ALL CODES FROM MEMORY
When deactivating any unwanted remote control code, all
previous codes will be erased.
1
Press and hold the learn button
1
on garage door opener or other
product until the learn LED goes
9
1 2 3
out (approximately 6 seconds).
All previous codes are now erased.
Reprogram each remote control
you wish to use.
For service, dial our toll-free number:
1-800-528-9131
114A4117
84LM/84LMC
4-Button Remote Control
Compatible with Dip switch devices
See Section A for programming
Compatible with Green Smart/Learn Button devices
See Section B for programming
2
Place the old and new remote controls
side by side. Set the Dip switches
1 through 9 to matching positions in all
remote controls. Use a pen or screwdriver
to move the switches to +, - or 0.
2
1 2 3
Locate the
1 2
Smart/Learn
button.
THE REMOTE CONTROL BATTERY
The battery should produce power for at least one year. If the
green LED is dim or does not come on, replace the battery.
1
PROGRAMMING 2 AND 4-BUTTON REMOTE CONTROLS
To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:
• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or
play with remote controls.
• Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and there are no
obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to
cross path of moving gate or door.
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
3
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
+
+
0 0
Match Dip switches (1-9)
3
1 1
Press and
9
9
immediately
3
release the learn
button. The learn LED will
glow steadily for 30 seconds.
Within 30 seconds...
1. Remove the cover.
2. Remove and dispose of the old
batteries properly.
3. Replace the batteries with the
same size and type of battery.
4. Replace the cover.
© 2010, The Chamberlain Group Inc.
All Rights Reserved
4
Replace the cover.
Press the remote control
button to activate the device.
Press and hold the button
on the remote control
that you wish
to use.
REPLACEMENT PARTS
12V Battery (2-Button Remote Control) . . . . . . . . . . . . . . . . 10A14
9V Battery (4-Button Remote Control) . . . . . . . . . . . . . . . . . 10A16
Visor Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29B137
Visor Clip Holder (4-Button Remote Control) . . . . . . . . . .31C412-1
NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or
modifications of this receiver and/or transmitter are prohibited, except for changing the
code setting or replacing the battery. THERE ARE NO OTHER USER SERVICEABLE
PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject
to the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Release the button when
the garage door opener
lights blink or two clicks
are heard. If programming
1 2 3
to other products, press
the button a second time
to activate the product.
