Chamberlain 825LM Manual

OVERVIEW
The Remote Light Control module offers a quick and convenient way
to control the lights in your home. The module can be programmed
to a remote control, a garage door opener, or a MyQ™ Internet
Gateway Accessory. The module is compatible with up to 8
Security✚ 2.0 TM remote controls OR a combination of up to 8 MyQ™
enabled garage door openers or MyQ™ Internet Gateway
Accessories. This product is NOT to be used for appliances.
SPECIFICATIONS
Fluorescent .........................................................................600W / 5A
Tungsten .............................................................................600W / 5A
LED .....................................................................................600W / 5A
Electronic Ballast (Fluorescent) ................................... 599W / 4.99A
Re-lamp with listed SBCFL only, 599W total, maximum
MODES OF OPERATION
The module can be programmed to a Security✚ 2.0
REMOTE CONTROL OPERATION:
Allows you to activate the
module from a remote
control.
INSTALLATION & PROGRAMMING
1
Plug the lamp into the module and plug
the module into an electrical outlet (the
LED on the module will flash). NOTE:
Make sure the lamp is switched ON.
4
Press the button on
OR
the remote control.
TO ERASE ALL PROGRAMMING
Press and hold the Learn button on the module for 6 seconds. All
programming is now erased.
TM remote control, a MyQ™ enabled garage door opener, or a MyQ™ Internet Gateway Accessory.
GARAGE DOOR OPENER OPERATION:
Allows you to synchronize
the module with your garage
door opener light bulbs.
Example: The garage door
opener light bulbs are set to
automatically turn off after 4 ½ minutes, the
module will also turn off after 4 ½ minutes.
2
If the lamp is not ON, press and release
the Power button on the module to turn
the lamp ON.
Press the Learn button on
OR
the garage door opener.
Power Button
Learn
Button
LED Lamp
Outlet
Visit www.myliftmaster.com.
Go to "Manage Devices", then
"Learn Device" to program the
MyQ™ Internet Gateway
Accessory.
ONE YEAR LIMITED WARRANTY
The Chamberlain Group, Inc. warrants to the first retail purchaser of this
product that is free from defect in materials and/or workmanship for a
period of 1 year from the date of purchase.
REMOTE LIGHT CONTROL
MODEL 825LM
To prevent possible SERIOUS INJURY or
DEATH from electrocution or fi re, the light
control is ONLY for indoor use.
NOTICE: To comply with FCC and/or Industry Canada (IC) rules.
adjustment or modifications of this transceiver are prohibited.
THERE ARE NO USER SERVICEABLE
This device complies with Part 15 of the FCC rules and IC RSS-
210. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
MyQ™ GATEWAY OPERATION:
Allows you to activate the
module from a web browser
or smart phone (requires
the MyQ™ Internet Gateway
Accessory, Model 828LM).
3
Press and release the Learn button on
the module (the LED on the module
will light).
The lamp's light bulb will blink and the
LED on the module will turn OFF when the
device has been programmed.
PARTS.
