- Page 1 Portable Party Speaker MODEL: APPS-0721 User Manual AFTER SALES SUPPORT info@tempo.org 1300 002 534 MODEL: APPS-0721 PRODUCT CODE: 706414 07/2021...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Unpack and Prepare Product Overview Remote Control Operation Troubleshooting Specifications Compliance and Responsible Disposal Warranty Information Repair and Refurbished Goods or Parts Notice... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the box Before setting up your new product, check you have everything: A. Portable Party Speaker B. Remote Control C. AAA Activ Energy Batteries (2) D. AC Power Cable E. AC Power Adaptor Warranty Certificate E G H G. -
Page 5: Product Overview
Product Overview Speaker Overview LED display screen + Remote sensor Tweeter Control Panel (see next page) Woofers PRODUCT OVERVIEW | 5... - Page 6 Control Panel 3 AUX In Port 4 GUITAR: input for guitar (not included) 5 MIC 1/MIC 2: input for wired microphones (not included) 6 Volume Knob: adjust volume level 7 EQ: change EQ mode 8 MIC PRIORITY: turn microphone priority on/off 9 LIGHT EFFECT: press to change the speaker light effect.
- Page 7 Rear Panel 19 DC In Port 20 Charging Status Indicator 21 Power Switch: press to turn speaker on/off APPS-0721 / 706414 Portable Party Speaker Input: 20V 3.6A YEAR WARRANTY Battery: 12V, 9Ah TEMPO (AUST) PTY LTD 07/2021 Barcode 4088700192856 PLU 16876...
-
Page 8: Remote Control
Remote Control Setup Insert the supplied AAA Activ Energy Batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed AAA size into place. batteries included Precautions When Using Batteries •... - Page 9 Remote Overview MUTE : Mute the sound. Press again to MODE : Press to switch between input unmute modes NUMBER BUTTONS : Numerical input to GT.VOL+ :Press to increase guitar volume directly play a track. level ECHO+ : Press to increase echo level GT.VOL- :Press to decrease guitar volume level ECHO- : Press to decrease echo level...
-
Page 10: Operation
Operation Charging and Power on • Charging: plug in the supplied power adaptor to the DC IN port to charge the speaker for 5-6 hours before use. During charging, the charging status indicator on the back of the speaker will flash blue. Once fully charged, the indicator will light up green. •... - Page 11 • On your smart phone, search for "BAUHN APPS-0721." If a password is required, enter "0000". If pairing is successful, the LED display screen on the speaker will display "bLUE". You will also hear "Bluetooth connected." You can now play music from your smart phone.
- Page 12 Micro SD Card Mode • Insert your Micro SD (TF) card into the MICRO SD CARD slot on the speaker. The speaker will automatically play the files. • Press the button on the speaker or the remote control to play/pause music. •...
- Page 13 Microphone • Plug in a wired microphone (not included) into the MIC 1 port of the speaker. Another wired microphone can be plugged into the MIC 2 port of the speaker if 2 microphones are desired. • Press the M.VOL+/M.VOL- buttons on the remote control to adjust the volume level. •...
-
Page 14: Troubleshooting
Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. Problem Solution No power • Ensure that the battery is charged or the power adaptor is connected. •... - Page 15 Problem Solution Unable to find BAUHN • Ensure you have paired the speaker with your Bluetooth enabled device. APPS-0721 in the • Ensure the Bluetooth function is activated on your Bluetooth enabled device. Bluetooth device list • Press and hold the button on the remote for 3 seconds to disconnect the existing paired device.
-
Page 16: Specifications
12V, 9Ah Speaker 2 x 50W Audio output power 100W RMS Max. For Technical Support: Bluetooth pairing name BAUHN APPS-0721 ® Ph: 1300 002 534 > 8m Bluetooth pairing operation range ® W: www.tempo.org Dimensions (W x H x D) 365mm x 870mm x 358mm E: info@tempo.org... -
Page 17: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian Safety selected from environmentally friendly Standard AS/NZS 62368.1 to ensure the safety of the materials and can usually be recycled. Please ensure product. -
Page 18: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 19: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 20 Online support Visit www.bauhn.com.au for the latest User Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
