- Page 1 SoundMax 1 Model Number: AWS1-815 INSTRUCTION MANUAL www.tempo.org 1300 886 649 Model: AWS1-815 Product Code: 51592 10/2015...
- Page 2 Welcome Congratulations on choosing to buy a BAUHN ® product. All products brought to you by BAUHN ® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty.
-
Page 3: Warranty Details
SoundMax 1 Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 4: Table Of Contents
Contents Welcome Warranty Details General Safety Instructions Product Overview Getting Started Instructions Troubleshooting/FAQs Specifications Repair and Refurbished Goods or Parts Notice www.tempo.org 1300 886 649 Model: AWS1-815 Product Code: 51592 10/2015... -
Page 5: General Safety Instructions
General Safety Instructions Read this manual thoroughly before first use and keep it in a safe place for future reference, along with the warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. - Page 6 General Safety Instructions (Cont.) Usage Conditions and Restrictions • Installation and adjustments: The product must be installed in accordance with local laws. Follow the instructions in this manual when installing and adjusting the product. Only adjust those controls that are covered in this manual, as improper adjustment of other controls may result in damage and/or expose you to danger.
- Page 7 General Safety Instructions (Cont.) • Holes, slots and openings: Do not push any objects into holes, slots or openings on the unit. This could result in fatal electric shock. • Handle with care: Press the buttons gently; pressing them too hard can damage the speaker.
-
Page 8: Product Overview
Product Overview Top View 1. Wi-Fi 4. Play/Pause 2. Vol-/Previous 5. Power ON/OFF 3. Vol+/Next 6. Indication Light Back View 7 8 9 10 7. Line-IN 9. USB (USB Charger Function) 8. Adapter 15V-1.2A 10. Reset www.tempo.org 1300 886 649 Model: AWS1-815 Product Code: 51592 10/2015... - Page 9 Product Overview (Cont.) Buttons and Functions Wi-Fi: Switch between Wi-Fi mode, Bluetooth mode, Line-In mode and USB charging mode. Vol-/Previous: Decrease the volume. Double press to go to the previous track in Bluetooth and Wi-Fi mode. Vol+/Next: Increase the volume. Double press to go to the next track in Bluetooth and Wi-Fi mode.
-
Page 10: Getting Started
Getting Started Turning ON To turn this unit ON, press and hold the Power ON/OFF button. When the unit turns on, a welcome voice will be heard and the indicator light will flash Blue. In order to connect this device to your Wi-Fi, you need to know your network credentials. - Page 11 Getting Started (Cont.) Getting Started (Cont.) Connect your SoundMax Device to your Home Network • Turn on your SoundMax 1 speaker. • Install the SoundMax App to your Smartphone or Tablet. (Refer to pages 9 and 10 for instructions.) • Ensure that your Smartphone is connected to the same network that you are connecting your...
- Page 12 Getting Started (Cont.) NOTE: You cannot have two units with same name in the SoundMax app. When you open the app for first time, after setting up a unit a pop up menu will come up and you can select the name from pre-defined names or write desired name for your unit.
- Page 13 Getting Started (Cont.) Installing the SoundMax App For Android Devices • Open the Google Play Store on your Smartphone or Tablet and search for the SoundMax App • Install the App to your Android device. • When you open the App for the first time, it will search for the available SoundMax units that are connected to the Wi-Fi network.
- Page 14 Getting Started (Cont.) For iOS Devices • Open the App store and search for the SoundMax App • Install the App to your iOS device. • When you open the App for the first time, it will search for available SoundMax units connected to the home Wi-Fi network.
-
Page 15: Instructions
Instructions My Music Through ‘My Music’ you can access the music that you have saved on your iOS or Android device’s internal storage. Once you enter the ‘My Music’ menu you will see the following options: • iPhone or Phone •... - Page 16 Instructions (Cont.) Spotify In order to use Spotify on your SoundMax speakers you need to install Spotify on your connected Smartphone or Tablet. Go to the App Store or the Play Store and search for the Spotify App. Install the App and login into your account. If you do not have an account you will need to set one up.
- Page 17 Instructions (Cont.) AirPlay You can play music through AirPlay on your iOS ® device. To do this you need to ensure that your iOS device and the SoundMax 1 speakers are connected to the same Wi-Fi network. Swipe up from the bottom of your iOS device and select ‘AirPlay’.
- Page 18 Instructions (Cont.) Adding to an Existing SoundMax System You can connect two or more SoundMax speakers together to create a surround sound and multi-room listening experience. In order to do this you need to ensure that all your SoundMax units are connected to the same Wi-Fi network.
-
Page 19: Troubleshooting/Faqs
Troubleshooting / FAQ’s Troubleshooting Guide Symptom Solution Check to make sure that the power cord is properly seated. Network issues may be preventing the product from connecting to your SoundMax system. Try moving the SoundMax components closer to the modem router. Check your modem router configuration and make sure it is not on isolation mode. - Page 20 Troubleshooting / FAQ’s Troubleshooting Guide Symptom Solution If the status indicator is not lit and no sound is produced when the unit is plugged in, check to ensure that the power cord is properly seated. SoundMax Check to ensure there are no obstacles that will Player is not impede wireless operation.
-
Page 21: Specifications
Specifications Technical Specifications Amplifier Integrated Class-D Digital Amplifier Speaker Output (RMS) Supported Streaming Services iHeartRadio, Spotify, Pandora , Airplay ® Wi-Fi 802.11 b/g/n Bluetooth V4.0 Line-In Input Yes, 3.5mm USB Output 5V DC, 1A (Charging Only) Battery 2200 mAh Lithium-ion Power Supply DC 15V/1.2A The Bluetooth... -
Page 22: Repair And Refurbished Goods Or Parts Notice
SoundMax 1 Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of... - Page 23 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: AWS1-815 Product Code: 51592 10/2015...
- Page 24 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund.
