- Page 1 SoundMax Soundbar INSTRUCTION MANUAL www.tempo.org 1300 886 649 Model: ASBWS-0716 Product Code: 53997 07/2016...
- Page 2 Welcome Congratulations on choosing to buy a BAUHN product. ® All products brought to you by BAUHN are manufactured to the highest standards ® of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will enjoy using your purchase for many years to come.
-
Page 3: Table Of Contents
Contents Welcome Remote Control Warranty Details General Safety Instructions Product Overview Controls and Connections Installation Instructions FAQs Troubleshooting / FAQ's Specifications Repair and Refurbished Goods or Parts Notice www.tempo.org 1300 886 649 Model: ASBWS-0716 Product Code: 53997 07/2016... -
Page 4: Remote Control
Remote Control POWER: Switch the unit between on and standby mode. MUTE: Silences the sound bar VOL+: Increase the volume level. VOL-: Decrease the volume level. PREVIOUS: Press to go to the previous track in both Bluetooth and Wi-Fi mode. NEXT: Press to go to the next track in both Bluetooth and Wi-Fi mode. -
Page 5: Inserting Batteries
Remote Control (Cont.) Inserting batteries 1. Open the cover at the back of the remote control unit completely. 2. Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into place so they can power the remote control unit. -
Page 6: Using The Remote Control
Remote Control (Cont.) Using the remote control • The remote control has a range of up to 3 metres from the soundbar. Point the remote control directly towards the sensor at the front of the soundbar. • Make sure no obstacles are blocking its path. The remote control will not operate if its path is blocked. -
Page 7: Warranty Details
SoundMax Soundbar Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 8: General Safety Instructions
General Safety Instructions Read this manual thoroughly before first use and keep it in a safe place for future reference, along with the warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. - Page 9 General Safety Instructions (Cont.) Usage conditions and restrictions • Instructions: Follow the instructions in this manual when installing and adjusting this equipment. Only adjust those controls that are covered in this instruction manual, as improper adjustment of other controls may result in damage. If this happens, unplug the equipment and have it serviced by appropriately qualified personnel.
-
Page 10: Product Overview
Product Overview 13 14 15 Source LED 11 COAX IN Power LED 12 AUX IN IR Sensor 13 OPTICAL IN VOL+ 14 DC IN VOL- 15 Firmware update port Source Pair Power On / Off HDMI Input 10 HDMI Output www.tempo.org 1300 886 649 Model: ASBWS-0716 Product Code: 53997 07/2016... - Page 11 Product Overview (Cont.) LED Indicators and Buttons Source LED The following Source LED light indication will let you know which mode the Soundbar is currently in. Source LED Mode LED Light Indications Disconected Flashes Green Wi-Fi Connected Solid Green Pairing Fast Flashing Green HDMI HDMI input...
- Page 12 Product Overview (Cont.) Source: Press the Source button (6) on the main unit or remote control to change the input of the Soundbar. As you change the input source, your current mode will be indicated by the colour of the Source LED (1). Pair Button: State Change mode...
-
Page 13: Controls And Connections
Controls and Connections Back Panel Connections HDMI Input HDMI Output COAX IN AUX IN OPTICAL IN DC IN Power in • Ensure to only connect the power supply provided. It must be 24V DC, 1.5A. Power connection • Before connecting the AC adapter, ensure you have completed all other connections. - Page 14 Controls and Connections (Cont.) to your TV's instruction manual for details on setting up HDMI-CEC and ARC. ARC mode is used for connecting the Soundbar to the TV via HDMI, utilizing the audio relay channel. This enables you to hear the TV through your Soundbar without using additional cables.
- Page 15 Controls and Connections (Cont.) • Connect the other end of the cable to the back of the Soundbar's Coax in socket. AUX socket Press the Source button either on the Remote control or on the Soundbar to change the input to AUX. The Source LED will change to PURPLE •...
-
Page 16: Installation
Installation Installing the SoundMax App For Android Devices • Open the Google Play Store on your Smartphone or Tablet and search for the SoundMax App. • Install the App to your Android device. • When you open the App for the first time, it will search for the available SoundMax units that are connected to the Wi-Fi network. - Page 17 Installation (Cont.) Connect your SoundMax Device to your Home Network • Turn on your Soundbar speaker. • Install the SoundMax App to your Smartphone or Tablet. (Refer to pages 8 and 9 for instructions.) • Ensure your Smartphone and Soundmax Soundbar are connected to the same Wi-Fi Network.
- Page 18 Installation (Cont.) NOTE: You cannot have two units with same name in the SoundMax app. When you open the app for first time and after setting up a unit, a pop up menu will be displayed. You can select the name from pre-defined names or write your own name for your unit.
-
Page 19: Instructions
Instructions Playing Music through Wi-Fi Your SoundMax Soundbar has the ability to play music wirelessly through the SoundMax App. You can play the music that you have stored on your iOS or Android device, or you can stream music from iHeartRadio or Spotify. Swipe right twice from the Device List screen on the App to access the menu. -
Page 20: Factory Reset
Instructions (Cont.) AirPlay You can play music through AirPlay® on your iOS device. To do this you need to ensure that your iOS device and the SoundMax Soundbar speakers are connected to the same Wi-Fi network. Swipe up from the bottom of your iOS device and select ‘AirPlay’. Select ‘SoundMax Soundbar ’... -
Page 21: Firmware Update
Instructions (Cont.) Adding to an Existing SoundMax System You can connect two or more SoundMax speakers together to create a surround sound and multi-room listening experience. In order to do this you need to ensure that all your SoundMax units are connected to the same Wi-Fi network. -
Page 22: Important Notes
Instructions (Cont.) Bluetooth Playing Bluetooth Enabled Devices ® You can listen to tracks from a media device if connected to the unit via Bluetooth wireless technology. Pairing Bluetooth ® Enabled Devices The first time you connect your Bluetooth device to this player, you need to pair your device to this player. - Page 23 Instructions (Cont.) TIPS • If you are prompted for a password, enter "0000". • If there is an existing connection, press the PAIR button on the remote control to re- activate the pairing mode, the connection will be disconnected. The blue will flash slowly.
-
Page 24: Faqs
FAQs To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. Problem Solution Try to increase the volume. No sound Reselect the audio input channel. Ensure the cables are correctly connected. -
Page 25: Troubleshooting / Faq's
Troubleshooting / FAQ’s Troubleshooting Guide Symptom Solution If the status indicator is not lit and no sound is produced when the unit is plugged in, check to ensure that the power cord is properly seated. Check to ensure there are no obstacles that will impede SoundMax wireless operation. -
Page 26: Specifications
Specifications Technical Specifications 2 x 1" tweeter, 8 ohm Speaker 2 x 3" woofer, 8 ohm 2 x 40*120mm full frequency speaker 8ohm Frequency Respone 65Hz ~ 20KHz (-10db) >75db(A) <10% Amplifier Integrated Class-D Digital Amplifier Speaker Output (RMS) 18W x 2CH + 36W Supported Streaming Services iHeartRadio, Spotify, Tune In, 802.11 b/g/n... -
Page 27: Repair And Refurbished Goods Or Parts Notice
SoundMax Soundbar Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of... - Page 28 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund.
