- Page 1 Ver 1.0 March, 2008 Ink Conversion Procedure Roland SolJet Pro II Converting Roland Eco-Sol Max Ink to ElevenTen Color R-1121 Series Inks 1110 W. Butler Rd., Suite C Greenville, SC 29607 866.597.1110 Phone 864.752.1042 Fax www.eleventencolor.com...
- Page 2 Ver 1.0: March 2008 THIS DOCUMENT MAY NOT BE COPIED, STORED ELECTRONICALLY OR COMMUNICATED TO A THIRD PARTY, IN PART OR IN WHOLE, WITHOUT WRITTEN AGREEMENT OF ELEVENTEN COLOR. ElevenTen Color reserves the right to make changes, without notice, to specifi cations and materials herein and shall not be responsible for any damages (consequential or otherwise) caused by reliance on the materials presented, including but not limited to typographical, arithmetic or listing errors.
- Page 3 Conversion from Roland Eco-Sol Max Ink to ElevenTen Color R-1121 Series Ink The following conversion procedure is designed to convert your Roland printer from the Roland Eco- Sol Max inkset to the ElevenTen Color R-1121 Series inkset. This procedure can be used for either a CMYKx3 or CMYKLcLm x 2 ink confi...
- Page 4 Empty the waste bottle before starting this procedure. The waste bottle is usually located on the underside of the printer. Dispose of the ink safely, as guided in your Roland user manual. (Consult your user manual if you are unsure of the waste tank location.) For more information on proper disposal of cartridges and/or ink waste please contact your local, county or state regulatory agency.
- Page 5 When the last Powerful Head Cleaning has fi nished, return to the main screen by pressing the [ ] key 3 times. Perform a Test Pattern print and compare it against the Test Pattern print previously printed with the Roland EcoMax inkset.
- Page 6 ElevenTen Color Ink Conversion Guide APPENDIX Performing a Test Pattern print Press and hold the [TEST PRINT] key for more than one second. The printer will now perform a Test Pattern print. Performing a Normal Head Clean Function Press the [CLEANING] key, then press the [ ] key to select the printing head group that will be cleaned.
- Page 7 ElevenTen Color Ink Conversion Guide APPENDIX Preventative Maintenance Measures Gently wipe down around the cap station and the wiper arm, removing any dried ink which may contaminate the new inkset. Using a swab and some of the ElevenTen Color R-1121 Series Cleaning solution, gently wipe down the area around the cap station, followed by wiping down the wiper blade and underneath the carriage on the fascia of the printheads.
- Page 8 Solvent-Compatible Parts for Roland Printers Before switching your Roland printer to the ElevenTen Color R-1121 Series inkset, care needs to be taken that the parts used in your printer are solvent compatible. In both cases there are parts available that are not solvent compatible and would result in damage to the part or to the printer.
- Page 9 ElevenTen Color Ink Conversion Guide APPENDIX 2 Warranty Registration and Conversion Acknowledgement END USER INSTALLING DEALER Company: Company: Contact: Technician: Address: Location/Address: Phone Number(s): Phone Number(s): Fax Number: Fax Number: Email: Email: Printer Make: Date of Installation: Printer Model: Serial Number: Age of Printer: Conversion Checklist Pre-Conversion Nozzle Check Patterns Printed...
