High Level Input Wiring

The high level input(s) should only be used when your head unit lacks RCA outputs.
If the RCA outputs are not present, connect the speaker outputs from the receiver
to the high level input connector of the amplifier. Be sure to observe polarity to
avoid audio phase problems.
NOTE: Do not connect BOTH the high level and low level inputs from your
receiver to your amplifier at the same time!
4-Channel Amplifiers
OL1800 and OL2400
REMOTE SUBWOOFER
LEVEL CONTROL
Remote
Subwoofer Level Control
To Speaker
Terminals
of head unit
CH CH CH CH
1+ 1- 2- 2+
1/2
CH
LOW LEVEL INPUTS
BASS BOOST INPUT LEVEL
3
CH
+ + +
CH CH 1 1 CH CH 2 2
HIGH INPUTS
3/4
CH
BASS BOOST INPUT LEVEL
+ +
3 4 4
CH CH CH
HIGH INPUTS
CH CH CH CH
3+ 3- 4- 4+
To Speaker
Terminals
of head unit
1/2 CROSSOVER
CH
FREQ MODE
1
CH
LOW HIGH
PASS PASS
40Hz
FULL RANGE
150Hz
3/4
CH CROSSOVER
FULL RANGE
2
CH
LOW HIGH
40Hz
PASS PASS
150Hz
FREQ MODE
OUTLAW MOSFET Amplifier User's Manual - page 7
