Four Channel OL1800 MOSFET Car Audio OL2400 Amplifiers Congratulations on your purchase of a OUTLAW Amplifier. It has been designed, engineered and manufactured to bring you the highest level of performance and quality, and will afford you years of listening pleasure. Thank you for making your choice for car audio entertainment!
Introduction With the OUTLAW OL1800 and OL2400 amplifiers, we are introducing two new 4-channel models, both designed in the USA. These OUTLAW models feature variable low pass and fixed high pass crossovers, and variable input gain controls. For further flexibility in the use of a subwoofer, 0-+18dB Bass Boost control has been included on all amplifiers.
Features Your new OUTLAW amplifier features the following: • Class A-B operation • Bridgeable outputs • Tri-Mode capable • MOSFET PWM (Pulse Width Modulated) Power Supply • 2 Ohm stable stereo operation with output power increase • Thermal and speaker short protection •...
General precautions Before installing and using your amplifier, please be- come familiar with all the infor- mation contained in this manual. Please keep this manual in a safe place for future reference. • Do not open or attempt to repair this unit yourself.
Connecting the amplifier Before doing any wiring, look through this manual and identify the diagrams to follow for power, input and speaker connections for your particular installation. Be sure you understand all the connections before you proceed. 1. Connect the power ground terminal to the closest point on the chassis of the car.
Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Always use a high-quality RCA cable for best audio performance. NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time! 4-Channel Amplifiers OL1800 and OL2400 REMOTE SUBWOOFER...
High Level Input Wiring The high level input(s) should only be used when your head unit lacks RCA outputs. If the RCA outputs are not present, connect the speaker outputs from the receiver to the high level input connector of the amplifier. Be sure to observe polarity to avoid audio phase problems.
Power and Speaker Wiring Bridged Modes Bridged Mode Chassis ground point to REMOTE TURN-ON terminal of head unit Battery FUSE RIGHT Subwoofer SPEAKER IMPEDANCE 4-8 OHMS CH3/4 BRIDGED MODE LEFT Subwoofer SPEAKER IMPEDANCE 4-8 OHMS OUTLAW MOSFET Amplifier User’s Manual - page 9 4-Channel Amplifiers OL1800 and OL2400 Connect the Negative (-) terminal of the...
Page 10
Power and Speaker Wiring Tri-Mode Tri-mode operation allows you to connect this amplifier to a pair of main speakers plus a subwoofer on one pair of output channels. The main speakers will operate in STEREO while the subwoofer simultaneously operates in MONO. To set up the amplifier to run in this mode, put the crossover switches in the FULL position.
Troubleshooting If you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous pages. If problems persist, read the following troubleshooting tips which may help eliminate the problems. SYMPTOM POSSIBLE REMEDY Amplifier will not Check to make sure you have a good ground connection.
Specifications Four Channel MOSFET Amplifiers MODEL OL1800 RMS POWER 180W x 4 into 4 Ohms MAX POWER 450W X 4 into 2 Ohms BRIDGED POWER 900W X 2 into 4 Ohms Min. speaker 2 Ohm Stereo impedance 4 Ohm Mono Bridged 0.01% 9Hz-50kHz Frequency response...
