UML -202-90
11
Technical Specifications
Electrical
Rated Voltage
Voltage Range
Power at Rated Voltage 70 W
Sync Format
LCD Panel
Screen Size (H x V)
Viewable Picture Area
Pixel Pitch (H x V)
Resolution
Aspect Ratio
Display Colors
Response Time
Backlight
LCD Panel Optical Characteristics
Luminance
Contrast Ratio (CR)
Viewing Angle
Sync Format
Video Input
Composite Video (CVBS)
Y/C (S-video)
Picture-in-Picture
Bosch Security Systems, Inc.
110/230 VAC, 50/60 Hz
90 to 264
PAL/NTSC
TFT LCD
408 x 306 mm (16 x 12 in.)
20.1 in. (53 cm) measured diagonally
0.255 x 0.255 mm (0.01 x 0.01 in.)
1600 x 1200 pixels, 500 TV lines typical
4:3
8-bit interface; 16.7 million colors
16 ms (typical)
Six (6) cold cathode fluorescent tubes, rated life 50,000 hours, at 50% brightness
300 cd/m2, hard-coating (3H), non-glare treatment
800:1
178° horizontal, 178° vertical @ CR >= 10
PAL/NTSC
1.0 Vp-p (0.5-1.5 Vp-p), automatic switching from 75 Ohm unbalanced termination
to Hi-Z with passive loop-through operation
0.7 Vp-p (Y-signal), 0.3 Vp-p (C-signal) 75 Ohm termination
Video 1, Video 2, S-video
Instruction Manual
Technical Specifications | en
F01U076723 | 1.0 | 2007.09
29
