Portfolio DualBrite Manual

D B
ual rite
Motion Sensing
Coach Light
Features
• Light comes on when motion is detected.
• Automatically turns light off.
• Dusk Accent lighting.
• Photocell keeps the light off during daylight
hours.
This package includes:
• Lantern
• Easy to use Universal Mounting Bracket
• Mounting Hardware
• Wire Connectors
• Some Models Include an Optional Decora-
tive Tail Assembly
Requirements
• The Light Control requires 120 volts AC.
• If you want to use Manual Mode, the control
must be wired through a switch.
• Some codes require installation by a
qualified electrician.
OPERATION
Mode: On-Time
Test 5 Seconds
Auto
1, 5, or 10 Min
Manual To Dawn*
Accent 3, 6 Hr, to Dawn
* resets to Auto Mode at dawn.
Note: When first turned on wait about 1
minutes for the circuitry to calibrate.
Before installation, record the model
number from back of fixture below.
Attach receipt in case of possible war-
ranty issues.
© 2006 DESA Specialty Products™
®
Works: Day Night
x
Set the ON-TIME switch
on the bottom of the cover
plate to TEST and the D
B switch OFF.
®
al rite
Set ON-TIME switch to
1, 5, or 10 minutes.
Manual mode only works at
night because daylight re-
turns the sensor to AUTO.
Flip the light switch off for
one second then back on to
toggle between AUTO and
MANUAL MODE.
Manual mode works only with
the ON-TIME switch in the 1,
5, or 10 position.
Mode Switching Summary
TEST
AUTO
MANUAL MODE
x
x
* If you get confused while switching modes, turn
x
the power off for 1
x
After the calibration time the control will be in the
AUTO mode.
/
1
2
D
ual
Light comes on dim for selected time after
dusk (Off, 3 hr., 6 hr., until dawn). If motion
is sensed, the light turns on full bright for
the ON-TIME (1, 5, or 10 minutes) then
returns to dim mode.
TEST
-
u
TEST 1 5 10 MIN
AUTO
TEST 1 5 10 MIN
MANUAL MODE
ON-TIME Switch at 1,
5, or 10 minutes
Flip light switch
off for one sec-
ond then back
/ minutes, then back on.
1
2
B Dimmer Control
®
rite
1 Second
OFF then...
... back on.
on*
598-1166-02
