Commissioning and Setup
6. Use the up and down arrows to adjust the TOU
Schedule. Once the desired value is set, press the
center button to exit edit mode.
NOTE: See the latest Time of Use Program Guide for
current TOU schedule values. The program guide is
https://www.generac.com/resources-and-
available at
tools/ce-installer-resources/clean-energy-design-
support.
7. Set the Time Zone to the desired location based on
Table 2: Time Zone
value is set, press the center button to exit edit
mode.
Table 2 - Time Zone Codes
Time Zone
UTC
US / Eastern
US / Central
US / Mountain
US / Pacific
US / Alaska
US / Hawaii
US / Arizona
US / Puerto Rico
8. See 6-14. To commit changes to all entries,
Figure
highlight Commit. Press the center button, then
use the arrows and center button to confirm the
choice.
Access Code:
TOU Schedule:
Time Zone:
Cancel
Figure 6-14. Configuring TOU Schedule (4 of 4)
See Figure 6-15 and Figure
LCD will alternate between a TOU Scheduler Running
Screen and a Current System Mode screen. Both
screens will display the time until the next system change
and the mode the system will change to. The TOU
Schedule name will be listed at the bottom of the device
page.
30
Codes. Once the desired
Units
0
1
2
3
4
5
6
7
8
57
1
4
Save
010112
6-16. When enabled, the
REbus Beacon
TOU Scheduler
running
Next Change:
To:
Schedule:
Figure 6-15. Running.
REbus Beacon
TOU Scheduler
Priority Backup
Next Change:
To:
Schedule:
Figure 6-16. Current System Mode.
See and
Figure 6-17 Figure
the text above the power flow diagram will alternate
between Scheduler Active and the current system mode.
Figure 6-17. Scheduler Active
Figure 6-18. Current Mode
Installation Manual for Generac PWRCell Inverter
1h:37m
Self Supply
SDGE
010113
1h:37m
Self Supply
SDGE
010114
6-18. On the home page,
010115
