Grandstream Networks GDS3710 Configuration Manual
Connecting gds3710 with gxv32xx
Hide thumbs
Also See for GDS3710:
- User manual (133 pages) ,
- Quick installation manual (47 pages) ,
- Connection manual (22 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Grandstream Networks GDS3710
Summary of Contents for Grandstream Networks GDS3710
- Page 1 Grandstream Networks, Inc. Connecting GDS3710 with GXV32XX Configuration Guide...
-
Page 2: Table Of Contents
Figure 3: Enable Direct IP Call ........................6 Figure 4: GXV3275 General Settings ......................6 Figure 5: GXV3275 SIP Settings........................6 Figure 6: GXV32XX Connected to GDS3710 through UCM6XXX ............... 7 Figure 7: SIP Basic Settings ......................... 8 Figure 8: Door System Settings ........................8 Figure 9: White List ............................ -
Page 3: Introduction
SIP phone, initiate calls from the phone to GDS3710 and get real time audio/video stream. The GDS3710 can be connected with a SIP phone in 2 different ways, either using peering mode (without a SIP server) or through a SIP server. -
Page 4: Peering Scenario
Settings Configuration on the GDS3710 Side The GDS3710 needs to be configured with the IP address of the GXV3275 and related SIP port, and remote PIN for door opening. (the second account will be used on the GXV3275 for this example, when using third or fourth…... -
Page 5: Figure 2: Door System Settings
GDS3710. 5. Click in order to apply changes. Make sure that the Direct IP Call feature is active from the GDS3710 WebGUI under “SIP Settings SIP Advanced Settings” then click on “Enable Direct IP Call”. P a g e... -
Page 6: Settings Configuration On The Gxv3275 Side
The GXV3275 related Account need to be set as “Active”, and correct “Local SIP Port” need to be configured at the GDS3710 side. These are the basic settings to make the peering scenario work. 1. On the GXV3275 webGUI navigate under “Account General Settings” and set “Account Active”... -
Page 7: Connection Using Sip Server
CONNECTION USING SIP SERVER In case of multiple GDS3710 and GVX32XX are available, a SIP server needs to be set in order to communicate between different devices. Note: We recommend using Stateless SIP server in this type of installations, Stateful SIP servers may not work. -
Page 8: Figure 7: Sip Basic Settings
2. Number Called When Door Bell Pressed (assuming 1001 is the GXV3275 number). 3. Remote PIN to Open the Door. The following figure shows an example of the configuration done. Figure 8: Door System Settings P a g e Connecting GDS3710 with GXV32XX Configuration Guide... -
Page 9: White List Settings
White List Settings Any number calling the GDS3710 extension will have its call auto answered. To restrict allowed numbers to call the GDS3710, user needs to navigate under “SIP Settings White List”. 1. Check Enable White Number List. 2. Click on Add to add numbers allowed to dial the GDS3710. -
Page 10: Figure 11: Gds Settings
Figure 11: GDS Settings Once the user presses the ring button on the GDS3710, an INVITE will be sent to the GXV32xx phone and the GDS3710 stream will be played on the GVX phone with a button that appears on the left side panel named “open”...
