- Page 1 U S E R G U I D E | C L O U D C O M M U N I C A T I O N S GDS3710 Hemispheric HD IP Video Door System Quick Installation Guide March 2019...
-
Page 2: Package Contents
Do not expose this device to environments outside of the following humidity range: 10-90% RH (non-condensing) • Please strictly follow the instruction to install or hire professionals to install properly PACKAGE CONTENTS 1 x GDS3710 1 x Installation 1 x Drilling 1 x Protecting... - Page 3 GDS 3 7 1 0 V ID E O D OOR ACC ES S SYST E M - Q UI C K IN STA L L AT I ON G UI D E MOUNTING GDS3710 On-Wall (Surface) Mounting Step 1: Refer to the “drilling template”...
- Page 4 Step 4: Take out the two preinstalled anti-tamper screws using the hex key provided. Carefully align the GDS3710 to the metal bracket on wall, press and pull the GDS3710 down to the right position.
- Page 5 CONNECTING THE GDS3710 Refer to the illustration below and follow the instructions on the next page. POWER OFF GDS3710 when connecting wires or inserting/removing the back cover panel piece! Option A: RJ45 Ethernet Cable to (Class 3) Power over Ethernet (PoE) Switch.
- Page 6 The GDS3710 is by default configured to obtain the IP address from DHCP server where the unit is located. In order to know which IP address is assigned to your GDS3710, please use GS Search tool as illustrated in following steps.
- Page 7 Enter username and password to login. (The default administrator username is “admin” and the default random password can be found at the sticker on the GDS3710). Important: please do not remove this sticker from the GDS door phone. Note: For security reasons, Masergy has already changed the default admin password.
- Page 8 GDS 3 7 1 0 V ID E O D OOR ACC ES S SYST E M - Q UI C K IN STA L L AT I ON G UI D E Step 8: To view video feed, access to LiveView. Click “Play”...
- Page 9 Wiegand Output Signal WG_D0_OUT (Brown) LED (Blue) Wiegand Output LED Signal (Special) WG_D1_IN (White) 2.0mm Wiegand Input Signal WG_D0_IN (Green) Beep (Yellow) Wiegand Output BEEP Signal 5V (Red) Wiegand Power Output For more details regarding GDS3710 wiring, please refer to User Manual.
- Page 10 GDS 3 7 1 0 V ID E O D OOR ACC ES S SYST E M - Q UI C K IN STA L L AT I ON G UI D E Electric Lock GDS3705 Connection Door Type Power On Power Off COM2 Normal Status...
