10 Basic Installation

Connecting the Scanner to the AXIS 70U/7000

Caution!
• Check that the power supply included with your AXIS 70U/7000 is marked with the correct
mains voltage.
AXIS 70U
1. Switch off the scanning device and disconnect the AXIS 70U external
power supply.
2. Connect the USB cable to the USB connector on the AXIS 70U.
3. Connect the USB cable to the scanning device.
AXIS 7000
1. Switch off the scanning device and disconnect the AXIS 7000 external
power supply. The SCSI bus may become damaged if you connect or dis-
connect units when power is on.
2. Connect the SCSI cable to the SCSI connector on the AXIS 7000.
3. Connect the SCSI cable to the scanning device. The AXIS 7000 uses a
built-in SCSI terminator. Note that the scanning device must also be termi-
nated properly. Refer to the documentation supplied with your scanning
device.

Connecting the AXIS 70U/7000 to the Network

1. Connect your AXIS 70U/7000 to the network. The AXIS 70U/7000 is
designed for 10 Mbps and 100 Mbps Ethernet networks and connects to the
network via a twisted pair category 5 cable (10baseT and 100baseTX) or
better.
2. Switch on the scanning device.
3. Connect the external power supply to the AXIS 70U/7000. The network
indicator will flash during power up and self test. The following message
will appear on the display during self test (x.xx is the software version
number, e.g. 1.06):
AXIS 70U
version: x.xx
AXIS 70U/7000 User's Guide
