INSTRUCTION MANUAL
Cordless Grass Shear
DUM604
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita DUM604

Summary of Contents for Makita DUM604

  • Page 1 INSTRUCTION MANUAL Cordless Grass Shear DUM604 Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model: DUM604 Cutting width 160 mm Strokes per minute 2,500 min Dimensions 353 mm x 177 mm x 131 mm (L x W x H) Rated voltage D.C. 18 V Net weight 1.4 - 1.8 kg • Due to our continuing program of research and development, the specifications herein are subject to change without notice.
  • Page 3 Do not expose power tools to rain or wet con- Store idle power tools out of the reach of children and ditions. Water entering a power tool will increase do not allow persons unfamiliar with the power tool the risk of electric shock. or these instructions to operate the power tool.
  • Page 4 Operate the equipment only if you are in good Remove sand, stones, nails etc. found within the physical condition. Perform all work calmly working range. Foreign particles may damage the and carefully. Use common sense and keep in cutting tool and can cause dangerous kick-backs. mind that the operator or user is responsible Should the cutting tool hit stones or other hard for accidents or hazards occurring to other...
  • Page 5 18. When moving the hedge trimmer to another Cordless Hedge Trimmer Safety location, including during work, always Warnings remove the battery cartridge and put the blade cover on the cutter blades. Never carry or Keep all parts of the body away from the cutter transport the trimmer with the cutter running.

  • Page 6: Functional Description

    ► 1. Red indicator 2. Button 3. Battery cartridge causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and To remove the battery cartridge, slide it from the tool charger.

  • Page 7: Overheat Protection

    The indicator lamps without pressing the lock-off button. Ask your local light up for a few seconds. Makita Service Center for repairs. Indicator lamps Remaining capacity...

  • Page 8: Indicator Lamp

    Change the fixed position of the grass receiver by Indicator lamp moving it in the direction of the arrow. The indicator lamp blinks or lights up when the remain- ing battery capacity is low or empty. The indicator lamp also lights up when the tool becomes overloaded. NOTE: The shearing height value is a guideline.
  • Page 9 NOTICE: If the parts other than the shear blades such as the crank are worn out, ask Makita Authorized Service Centers for parts replacement or repairs. ► 1. Grass receiver...
  • Page 10 Removing the shear blades Installing the shear blades Remove the grass receiver and place the tool Prepare the crank, undercover, and new shear upside down. blades. ► 1. Crank 2. Undercover 3. Shear blades While pressing the lock lever, turn the undercover counterclockwise until on the undercover is aligned Remove the blade cover from the old shear...
  • Page 11 Apply a small amount of grease to the periphery Place the undercover so that on the under- of the crank. Attach the crank to the pins with the small cover is aligned with on the lock lever. and large rounds facing up. While pressing the undercover, turn the under- cover clockwise until on the undercover is aligned...
  • Page 12 Attach the blade cover before removing or installing the shear blades. NOTICE: If the parts other than the shear blades such as the crank are worn out, ask Makita Authorized Service Centers for parts replacement or repairs. Removing shear blades Place the tool upside down.
  • Page 13 Installing shear blades Apply a small amount of grease to the periphery of the crank. Attach the crank to the pins with its small and Prepare the crank, undercover, and new shear large rounds facing down. blades. ► 1. Crank ►...
  • Page 14 Tighten the two screws firmly with a screwdriver. 10. Make sure that the lock lever fits in the groove on the undercover. ► 1. Screws ► 1. Lock lever Place the undercover so that on the under- cover is aligned with on the lock lever.

  • Page 15: Operation

    To remove the chip receiver, press the levers on both Shearing (for grass shear) sides to release the hooks. Turn the tool on after adjusting the shearing height and hold it so that the bottom of the tool rests on the ground. Gently move the tool forward.
  • Page 16 NOTICE: NOTICE: Do not trim the wet grass or foliage of Do not cut down dead trees or similar small trees. hard objects. Doing so may damage the tool. NOTICE: Do not trim the grass or weeds while Cutting long lawn using the shear blades.

  • Page 17: Blade Maintenance

    To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Cleaning the tool Clean the tool by wiping off dust with a dry cloth or one dipped in soapy water and wrung out.

  • Page 18: Optional Accessories

    CAUTION: These accessories or attachments are recommended for use with your Makita tool Storage specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons.
  • Page 20 Makita Corporation 885551A2 20190213 www.makita.com...
