3 Button Remote Security System with
Shock Sensor, Starter Disable, & Keyless Entry
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on " MANUALLY OVERRIDING YOUR SYSTEM " is
necessary to fully understand the procedure required to enable your vehicle in such situa-
tions. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected. Valet
Switch manual override is pre-selected from the factory, however, the system can be
configured for "Custom Code" operation. Confirm the override mode selected on the last
page of this manual, and familiarize yourself with the selection on it's operation.
FEATURES :
2 Three Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Three Channel Receiver
Anti Code Grabbing Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override Code
7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Starter Disable
True Last Door Arming ( hardwire only )
Defective Zone By - Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi - Tone Siren (And or)
Car Horn Activation for additional alarm response
Additional Negative Trigger Input
RF Inhibit with ignition on
Parking Light Flasher
Remote Trunk Release ( must have electronic trunk release )
Remote Keyless Entry
Illuminated Entry
OPTIONS :
Multiple Vehicle Capable
Headlight Illumination during Arming and Disarming
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Plug In Electronic Shock Sensor
With Optional Access Guard
Page 1
Model PRO 9549FT
Owner's Manual
( must have power door locks )
Advertisement
Table of Contents
Related Manuals for Audiovox PRO9549FT3
Summary of Contents for Audiovox PRO9549FT3
- Page 1 3 Button Remote Security System with Shock Sensor, Starter Disable, & Keyless Entry IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.
-
Page 2: Arming The System - Active
YOUR “ ANTI CODE GRABBING “ TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re transmit at a later time to disarm your system. -
Page 3: Arming The System - Passive ( Automatic )
The vehicle’s headlights turn on for approximately 30 seconds, illuminat- ing the path as you leave the vehicle. SILENT ARMING - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid. 2. Press and hold the ARM / DISARM button on the keychain transmitter for 2 seconds. Red dash mounted L.E.D. -
Page 4: Disarming The System
monitor all protected entry points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed, and ignore that triggered zone. Whenever the system is armed, the red dash mounted L.E.D. indicator will slowly flash. -
Page 5: Silent Disarming
Doors Unlock. Using the optional Access Guard feature, the alarm can be wired to unlock only the drivers door during this step. To unlock all the doors, press and release the Arm/Disarm button of the transmitter a second time within 3 seconds. (Power Door Locks Required.) Headlight Illumination - Optional The vehicle’s headlights turn on for approximately 30 seconds, illumi- nating the path to the vehicle. -
Page 6: Valet Switch
the red dash mounted L.E.D. to identify which zone was triggered. If the L.E.D. is flashing one time...pause...one time...pause...etc., then an intrusion attempt was made to the OPTIONAL shock sensor, or an accessory triggering device that may have been added to the system. If the L.E.D. - Page 7 PROGRAMMING THE CUSTOM CODE MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to disarm the system if you lose your transmitter, or if the transmitter battery fails. If your system has been selected for Custom Code manual override as indicated on the last page of this manual, in order to provide the highest level of security, this system will allow you to program your personal manual override code.
-
Page 8: Eliminating The Normal Arm / Disarm Chirps
1. Open the door. The alarm will sound. 2. Turn the ignition key to the on position. The alarm will stop for three seconds, then the siren will begin counting with long chirps. 3. As soon as the chirp that corresponds with your first digit sounds, quickly turn the ignition key ;... -
Page 9: Additional Remote Function ( Channel 3 )
more seconds. The alarm will immediately sound. 2. To stop the alarm, press and hold the ARM / DISARM button on the transmitter again for 3 seconds. If the button is not pressed, the alarm will automatically stop after 30 seconds. NOTE : All normal transmitter functions will operate in the panic mode. - Page 10 Auto Unlock with ignition key Headlight Illumination during arm & disarm Passive Arming No Lock in passive mode Hardwire doors, hood, and trunk Custom Code Override Valet Switch Override Audiovox Corp. 150 Marcus Blvd. PRO 9549FT PASSIVEARMING ARMED DISARMED VALET MODE...
