3 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
2 Three Button Programmable RF Transmitters
Four Channel Code Learning Receiver
Remote Start Safety Control Switch
Safe Start RF Control (Double Push Of RF Transmitter)
Selectable Automatic Timed Start Mode
7 Function LED, Arming, Armed, Disarmed, Valet, Zones 1, 2, & 3
Audible Arm, Disarm, Defect Zone, And Intrusion Indications
Instant Siren Activation All Entry Points
Selectable Run Time 10 or 15 Minutes
WARNING! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if the car is garaged.
Model AA-RS20CS
FEATURES:
Anti Code Grabbing Technology
Remote Panic In All Modes
Protected Valet/Override
Intrusion Alert With Memory
Starter Disable When Armed
True Last Door Arming
Defective Zone By-Pass
On Command RF Chirp Delete
6 Tone Multi-Tone Siren
Two Stage Shock Sensor
OPTIONS:
Remote Trunk Release
Remote Keyless Entry
Illuminated entry
Remote Power Window Control
Remote Garage Door Interface
Multiple Vehicle Capable
Owner's Manual
Advertisement
Table of Contents
Related Manuals for Audiovox AA-RS20CS
Summary of Contents for Audiovox AA-RS20CS
- Page 1 WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if the car is garaged. Model AA-RS20CS Owner's Manual FEATURES: OPTIONS:...
-
Page 2: Arming The System - Active
Your AA-RS20CS Remote Start Alarm System has many features and available options some of which are selected at time of installation. For your reference, the list on the back page of this manual show what features and options have been installed. Consult your installing dealer for options that may have been installed and are not listed. -
Page 3: Disarming The System
continue to protect all other zones. Whenever the system is armed, the dash mounted LED will slowly flash. This serves as a visual deterrent to a potential thief. This LED is a very low current light emitting diode, and will not cause the battery to drain even if left unattended for long periods of time. Whenever the system is triggered, the vehicle parking lights will flash for the full siren sounding period. -
Page 4: Valet/System Override Switch
INTRUSION WARNING SIGNAL This system will inform you if an intrusion attempt has occurred while you were away from the vehicle. Upon disarm, the siren will chirp 4 times and the parking lights will flash 3 times. Enter the vehicle and before turning on the ignition switch, observe the LED flash pattern. -
Page 5: Remote Panic Operation
The control switch allows you to temporarily disable the remote starting function of your AA-RS20CS. To disable the unit, move the red handled control switch to the off position. The control switch also allows you to select between 2 hour start up and 4 hour start up when using the automatic start up timer mode. -
Page 6: Operating On Automatic Start Up Timer Mode
5. Race the engine to above 4000 RPM. OPERATING ON AUTOMATIC START UP TIMER MODE The AA-RS20CS has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine. - Page 7 CANCELING THE AUTOMATIC START UP TIMER To cancel the automatic start up timer do one of the following; 1. Start the vehicle manually with the use of the ignition key and depress the brake pedal. 2. Remote start the vehicle using your keychain RF transmitter. ADDITIONAL REMOTE FUNCTION CHANNEL 2 The system has an additional feature, ( Channel 2) ,that can be connected to a number of different optional accessories.
- Page 8 3 FLASH CONTINUOUS FLASH = REMOTE START SIREN INDICATIONS 1 LONG/1SHORT REMOTE START PARKING LAMP INDICATIONS 1 FLASH CONTINUOUS FLASH = © 2000 Audiovox Electronics Corp., Hauppauge, N.Y. 11788 PASSIVE ARMING ARMED DISARMED VALET MODE INTRUSION ZONE 3 INTRUSION ZONE 2...
