Tiger SIDE ROTARY JD6110-30M/R T4F Mounting And Operating Instructions

page of 202

/ 202
Bookmarks

Quick Links

Download this manual

SIDE ROTARY

ASSEMBLIES

3/25/2020

Tiger Corporation

1-800-843-6849

1-605-336-7900

www.tiger-mowers.com

06011031

Summary of Contents for Tiger SIDE ROTARY JD6110-30M/R T4F

Page 1 SIDE ROTARY ASSEMBLIES 3/25/2020 Tiger Corporation 1-800-843-6849 1-605-336-7900 www.tiger-mowers.com 06011031...
Page 2 TO THE OWNER / OPERATOR / DEALER BEFORE YOU START!! READ AND UNDERSTAND THIS MANUAL! Non–English speaking operators will need to GET THE MANUAL TRANSLATED as needed! Warranty Information: Read and understand the complete Warranty Statement found in this manual. Fill out the Warranty Registration form in full and return it within 90 days.
Page 3 • Classify the problem • Hydraulic, electrical or mechanical - Read the trouble shooting section • Tractor or Truck chassis - Contact vehicle dealer • If unable to correct the problem yourself, contact your local Tiger Dealer after gathering: • Machine model _______________________ •...
Page 5: Table Of Contents
PARTS SECTION______________________________________ COMMON PARTS SECTION____________________________ WARRANTY INFORMATION_____________________________ This symbol means: CAUTION – YOUR SAFETY IS AT RISK! When you see this symbol, read and follow the associated instructions carefully or personal injury or damage may result. Tiger is a registered trademark.
Page 7: Safety Section
SAFETY SECTION...
Page 8 SAFETY General Safety Instructions and Practices A safe and careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner / operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
Page 9 SAFETY Si no lee Ingles, pida ayuda a alguien que PELIGRO! LEA EL si lo lea para que le traduzca las medidas INSTRUCTIVO! de seguridad. (SG-3) Never operate the Tractor or Implement until you have read and DANGER! completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
Page 10 SAFETY Never allow children or other persons to ride on the Tractor or Implement. DANGER! Falling off can result in serious injury or death. (SG-10) DANGER! Never allow children to operate or ride on the Tractor or Implement. (SG-11) WARNING! Do not mount the Tractor while the tractor is moving.
Page 11 SAFETY WARNING! The operator and all support personnel should wear hard hats, safety shoes, safety glasses, and proper hearing protection at all times for protection from injury including injury from items thrown by the equipment. (SG-16) CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PER- MANENT HEARING LOSS! Tractors with or without an Implement attached can often be noisy enough to cause permanent hearing loss.
Page 12 SAFETY WARNING! Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. Make sure the tractor engine is off before working on the Implement. (SG-20) WARNING! Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
Page 13 SAFETY CAUTION! On a fully-assembled unit, do not remove the Wing Retaining Strap until hoses are attached to the tractor and the Wing Cylinders are filled with oil. Lower the Wings slowly and carefully. Keep bystand- ers away during operations. (STI-5) DANGER! NEVER use drugs or alcohol immediately before or while operating the...
Page 14 SAFETY DANGER! The rotating parts of this machine have been designed and tested for rugged use. However, the blades could fail upon impact with heavy, solid objects such as metal guard rails and concrete structures. Such impact could cause the broken objects to be thrown outward at very high velocities.
Page 15 SAFETY Rotary Mowers are capable under adverse conditions of throwing DANGER! objects for great distances (100 yards or more) and causing serious injury or death. Follow safety messages carefully. STOP MOWING IF PASSERSBY ARE WITHIN 100 YARDS UN- LESS: -Front and Rear Deflectors are installed and in good, working condition;...
Page 16 SAFETY WARNING! Never leave the Tractor and Implement unattended while the Implement is in the lifted position. Accidental operation of lifting lever or a hydraulic failure may cause sudden drop of unit with injury or death by crushing. To properly park the implement when disconnecting it from the tractor, lower the stand and put the retaining pin securely in place, or put a secure support under the A-Frame.
Page 17 These parts are made and tested to Tiger specifications. Non-genuine “will fit” parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties and present a safety hazard. Use genuine Tiger mower parts for economy and safety. SEE YOUR...
Page 18 SAFETY Side Rtry Safety Section 1-12...
Page 19 DESCRIPTION 22839 INSTRUCT Don Not Lubricate With Automatic Grease Gun 22840 WARNING Foreign Objects Contacted 24028 WARNING Inspect Rear Flap 31522 LOGO TIGER MOWERS 31523 LOGO TIGER MOWERS 42350 DANGER Cuttershaft Direction 33743 INSTRUCT Mowing Safet Tips 42399 REFLECT Red Reflector...
Page 20 SAFETY PART NO. LOCATION 22839 MOWER DECK 22840 INSIDE OF CAB 24028 MOWER DECK 10"X5.5" 31522 MOWER DECK 18.25"X10" 31523 HYDRAULIC TANK Side Rtry Safety Section 1-14...
Page 21 SAFETY PART NO. LOCATION 42350 MOWER DECK 33743 INSIDE OF CAB 42399 MOWER DECK 42400 MOWER DECK Side Rtry Safety Section 1-15...
Page 22 SAFETY PART NO. LOCATION 6T3217 MOWER DECK 6T3219 INSIDE OF CAB 6T3220 FRONT PUMP MOUNT 6T3221 INSIDE OF CAB 29-6T3221 Side Rtry Safety Section 1-16...
Page 23 SAFETY PART NO. LOCATION 6T3233 INSIDE OF CAB 6T3234 INSIDE OF CAB 6T3236 MOWER DECK 6T3243 INSIDE OF CAB Side Rtry Safety Section 1-17...
Page 24 SAFETY PART NO. LOCATION 6T3233 HYDRAULIC TANK 6T3234 INSIDE OF CAB 6T3236 MOWER DECK HYDRAULIC TANK 6T3243 INSIDE OF CAB Side Rtry Safety Section 1-18...
Page 25 SAFETY PART NO. LOCATION 6T3249A MOWER DECK 6T3261 MOWER DECK TB1011 MOWER DECK 02962764 MOWER DECK DRAFT BEAM Side Rtry Safety Section 1-19...
Page 26 SAFETY PART NO. LOCATION 02965262 DRAFT BEAM 02967827 CAB FENDER Side Rtry Safety Section 1-20...
Page 27 SAFETY 34852 HYDRAULIC TANK 00756059 MOWER DECK Side Rtry Safety Section 1-21...
Page 28 SAFETY ITEM PART NO. QTY. DESCRIPTION 50023 AVAIL MANUAL CANISTER COMPLETE 00776031 Round Manual Canister 33997 Decal, Sheet, Manual Canister Decal Decal Decal AVAIL Specification Product Manual 33753 EMI Safety Manual 34296 Front Adhesive Pad 34297 Rear Adhesive Pad 6T1823 Zip Tie 14"...
Page 29 SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 30 SAFETY Side Rtry Safety Section 1-24...
Page 31: Assembly / Mounting Section
JD6110-30M/R - SIDE ROTARY T4F ASSEMBLY SECTION Assembly Section 2-1...
Page 32 Always use a floor jack, hoist or fork lift to lift and raise heavy parts. Read and understand the entire Assembly Section instructions before attempting to mount your Tiger mower. Refer to the Parts Section of this manual for detailed illustrations to locate all parts.
Page 33 ASSEMBLY FRONT CRANKSHAFT PULLEY Tiger has found that the front crankshaft pulley used by John Deere will not allow for the installation of a front drive system. You will need to order a different pulley, washer and bolt from John Deere to allow for a front drive to be installed on your tractor.
Page 34 ASSEMBLY DRIVESHAFT AND FRONT PUMP MOUNTING Install spacer plate on tractor engine using bolts and lockwashers as shown in Parts Section. Grease sleeve section of the driveshaft and install from the side of the engine compartment. Once you have the sleeve section in place, bolt to spacer plate using bolts and lockwashers as shown in Parts Section.
Page 35 ASSEMBLY APPLICATION OF LOCTITE 2047 MOWER MAINFRAME MOUNTING BOLTS All mower mainframe mounting bolts shall be secured utilizing Loctite 2047 and torqued per the Torque Chart in the maintenance section. Shake bottle for 60 seconds before use. To prevent clogging of nozzle, do not allow tip to touch metal surfaces during application.
Page 36 ASSEMBLY MAINFRAME INSTALLATION With an overhead hoist and / or jack-stands, raise one side of the frame up to the correctly matching mounting holes. Install capscrews and other hardware to secure the sides of the mainframe to the tractor casting, as shown on the tractor mount kit page in the Parts Section. DO NOT tighten at this time.
Page 37 ASSEMBLY WEATHER-PACK / METRI-PACK ASSEMBLY These instructions apply to both Weather-Pack and Metri-Pack connectors. NOTE: Use the specific tool for the type of connector you are assembling. (ASM-C-0009) HYDRAULIC PORTS These ports are located at the rear of the tractor, under the lift valve, where the valve mounting bracket attaches to the tractor.
Page 38 Locate the plug on the tractor rear remotes for the load sense, and remove the plug. Install a 14mm adapter or elbow and run a 1/4” hose from the remotes to the Tiger valve. Refer to the Parts Section pages for an exploded diagram of the tractor remote valve hookup.
Page 39 ASSEMBLY *NOTE ON HUSCO CONTROL VALVES* Manual, cable controlled (Husco control valve) boom mowers require check valves with integral restricting orifice (#06502036) installed in the control valve work ports that are connected to the gland ends of the main and secondary boom cylinders. This check valve allows oil to free flow into the gland end of the main and secondary boom cylinders, but restricts flow out of the cylinder, thereby providing proper boom control.
Page 40 ASSEMBLY MANUAL SWITCHBOX MOUNTING The switchbox is to be secured to the operator’s side of the control handles, or valve stand. Refer to the Parts Section for assembly and components needed. (ASM-C-0053a) Assembly Section 2-10...
Page 41 ASSEMBLY CABLE CONTROL LEVER STAND On the corner cab post, mark a point at 1-3/8” from the windshield and 22-1/2” from the floor; then cut a 3/4” diameter hole through the outer plastic shell. This will expose a threaded steel boss to attach the control box support bracket.
Page 42 ASSEMBLY DRAFT BEAM INSTALLATION Install ½” O-ring breather into butt port of inboard cylinder. Install fittings in the rod end of the cylinder according to the diagram in the Common Parts section. These fittings should be positioned to face the butt end of the cylinder. Next turn the clevis onto the rod of the cylinder until it is tight against the shoulder and lock into place with locking bolt on clevis.
Page 43 ASSEMBLY MOWER MOUNTING Check that all grease zerks have been installed in the draft beams pivot arm, left linkage arm, right linkage arm, and cylinder mounting ears. Using a clevis pin and roll pins, connect the pivot arm to clevis on draft beam. NOTE: Make sure the longer distance between the cutout and the end of the pivot arm is closest to the draft beam pivot ears on the center tube as shown in the diagram below.
Page 44 ASSEMBLY SIDE MOWER HYDRAULIC DIAGRAM (ASM-C-0090) WHEEL WELL HYDRAULIC TANK INSTALLATION Install all fittings and tubes into tank and tank filter as shown in the Parts Section illustration. Insert tank sight glass onto the tractor side of the tank. Place the tank in the mounting bracket on the axle brace as shown in the Parts Section. Secure the tank with the hardware provided.
Page 45 ASSEMBLY FILLING HYDRAULIC RESERVOIR Refer to the Maintenance Section for filling specifications and hydraulic oil requirements. NOTE: Starting or running your Tiger mower before filling reservoir will cause serious damage to the hydraulic pump. (ASM-C-0004hydro resrv) INSTALLING O-RING FITTINGS Installing straight, 45º and 90º O-rings requires that the O-ring and washer be up against the swivel body.
Page 46 ASSEMBLY SOLENOID BRAKE VALVE Install a solenoid valve on the mounting bracket with the supplied hardware as shown in the Parts Section in this manual. While installing the fittings to the brake valve, the electrical coil on the spool may have to be removed to make room. When reinstalling the coil, it is important to use no more than 5 ft.
Page 47 ASSEMBLY FINAL PREPARATION FOR OPERATION Place operator’s safety and operation decals on the steering column and side console where they are clearly visible to the operator. These decals should be understood by each operator of the machine in conjunction with the Safety and Operation Sections of this book. The decals are to be maintained in good condition as a reminder to the operator, and should be replaced if damaged.
Page 48 ASSEMBLY Assembly Section 2-18...
Page 50 OPERATION TIGER SIDE ROTARY MOWER OPERATING INSTRUCTIONS READ AND UNDERSTAND THE ENTIRE OPERATING INSTRUCTIONS AND SAFETY SECTION OF THIS MANUAL AND THE TRACTOR MANUAL BEFORE ATTEMPTING TO USE THE TRACTOR AND IMPLEMENT. (OPS-U- 0001) © 2014 Alamo Group Inc.
Page 53 OPERATION 3. TRACTOR REQUIREMENTS Tractor Requirements and Capabilities 3.1 ROPS and Seat Belt OPS-U- 0003 3.2 Tractor Safety Devices OPS-U- 0004_A 3.3 Tractor Horsepower © 2013 Alamo Group Inc.
Page 54 OPERATION 3.4 Front End Weight OPS-U- 0005 4. GETTING ON AND OFF THE TRACTOR OPS-U- 0007 4.1 Boarding the Tractor OPS-U- 0008 © 2014 Alamo Group Inc.
Page 55 OPERATION 4.2 Dismounting the Tractor OPS-U- 0009_A 5. STARTING THE TRACTOR Essential Tractor Controls: Before starting the tractor ensure the following: OPS-U-0028 © 2013 Alamo Group Inc.
Page 56 OPERATION 6. CONNECTING THE MOWER TO THE TRACTOR OPS-R-0001 6.1 Connecting Mower Hydraulics Figure Ops-1252 OPS-R-0104 © 2014 Alamo Group Inc.
Page 59 OPERATION OPS-U- 0011_A NOTE: The mower Operator’s Manual and affixed Decals contain important instructions on the safe and proper use of the mower. Maintain these important safety features on the mower in good condition to ensure the information is available to the operator at all times. OPS-R-0099 ©...
Page 64 OPERATION 7.3 Blade Bolt Inspection Always replace Blade Bolts with new bolts whenever replacing the Blades. OPS-U-0037 © 2014 Alamo Group Inc.
Page 65 OPERATION Tractor PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 66 OPERATION Side Rotary Mower PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 68 OPERATION 7.4 Starting the Tractor OPS-U-0033 7.5 Brake and Differential Lock Setting OPS-U- 0013 © 2014 Alamo Group Inc.
Page 70 OPERATION OPS-R-207 8. OPERATING THE TRACTOR AND IMPLEMENT THE OPERATOR MUST COMPLETELY UNDERSTAND HOW TO OPERATE THE TRACTOR AND IMPLEMENT AND ALL CONTROLS BEFORE ATTEMPTING TO OPERATE. OPS-U- 0015 © 2014 Alamo Group Inc.
Page 71 OPERATION 8.1 Foreign Debris Hazards Remove Foreign Material OPS-R-208 Raise Mower over solid objects 8.2 Bystanders/Passersby Precautions OPS-R-209 © 2013 Alamo Group Inc.
Page 72 OPERATION STOP MOWING IF PASSERSBY ARE WITHIN 300 Feet UNLESS: NOTE: Where there are grass and weeds high enough to hide debris that could be struck by the blades, the area should be: inspected and large debris removed, mowed at an intermediate height, inspected, closely with any remaining debris being removed, and mowed again at desired final height.
Page 73 OPERATION 8.3 Ground Speed OPS-R-210 9. Operating the Control Valves - Side Mount MOWER VALVE OPERATION © 2013 Alamo Group Inc.
Page 79 OPERATION 300 feet The engine should not be operated at any time at more than 2400 RPM on the tractor tachometer. DO NOT Maintenance Section 300 feet © 2013 Alamo Group Inc.
Page 80 OPERATION After the first day of operation, all bolts should be checked and tightened securely. OPS-R-212 © 2014 Alamo Group Inc.
Page 82 OPERATION 9.4 Shutting Down the Implement OPS-U- 0016 10. DISCONNECTING THE MOWER FROM THE TRACTOR OPS-R-213 © 2014 Alamo Group Inc.
Page 83 OPERATION 11. MOWER STORAGE OPS-R-214 12. TRANSPORTING THE TRACTOR AND IMPLEMENT OPS-U- 0017 © 2013 Alamo Group Inc.
Page 84 OPERATION 12.1 Transporting Mower TRANSPORTING UNDER THE UNIT’S OWN POWER TRANSPORTING UNIT BY FLATBED TRAILER Figure Ops-1226. © 2014 Alamo Group Inc.
Page 85 OPERATION OPEN THE BALL VALVES ON THE HYDRAULIC RESERVOIR BEFORE STARTING TRACTOR AGAIN! 12.2 Transporting on Public Roadways OPS-R-217 © 2013 Alamo Group Inc.
Page 89 OPERATION TROUBLESHOOTING GUIDE HYDRAULIC CYLINDER NOT WORKING NOTE: Refer to repair parts section on valve bank settings on individual relief cartridges. HYDRAULIC MOTOR NOT WORKING HYDRAULIC VALVE STRUCTURAL MEMBERS © 2013 Alamo Group Inc.
Page 92 Regular maintenance at the intervals mentioned will result in the maximum efficiency and long life of the Tiger Mower. When you purchase a Tiger Mower you also acquire another valuable asset, Tiger’s parts organization. Our rapid and efficient service has guaranteed the customer satisfaction for many years.
Page 93 MAINTENANCE Do not m odify or alter this Imple ment. Do not permit anyone to modify or alter this Implement, any of its components or any Implement function. (SG-8) Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine.
Page 94 MAINTENANCE REGULAR MAINTENANCE The intervals at which regular servicing should be done are based on hours of operation. Use the tractors hour meter to determine when regular servicing is required. Daily or Every 8 Hours ITEM SERVICE COMMENTS Drive Shaft Yoke, U-Joint Grease Grease as instructed in &...
Page 95 MAINTENANCE WEEKLY OR EVERY 40 HOURS ITEM SERVICE COMMENTS Rotary Spindle Lubricate Every 40 hours or weekly WEEKLY OR EVERY 50 HOURS ITEM SERVICE COMMENTS In Tank Hydraulic Fluid Change Change after first 50 hours only Filter (10 micron filter) then every 500 hours or yearly In-Line High Pressure Change...
Page 96 MAINTENANCE YEARLY OR EVERY 500 HOURS ITEM SERVICE COMMENTS Spindle Grease Change Motor to Spindle Spline Change Hydraulic Tank Fluid Change In Tank Hydraulic Fluid Filter Change (10 micron filter) In-Line HP Filter Change Change when indicated (10 micron filter) by restriction indicator.
Page 97 MAINTENANCE TROUBLESHOOTING SYMPTOMS CAUSE REMEDY Vibration Loose Bolts Check all bolts and tighten to recommended torque specifications in this section Cutter assembly a. Check for damaged blades, disc, unbalanced or cutter shaft. b. Replace if needed. c. Check for wire, rope, etc. en tangled in the cutter assembly Mower will not lift Hydraulic Fluid Low...
Page 98 MAINTENANCE TROUBLESHOOTING (CONTINUED) b. Remove the four bolts holding the small block to th e main block. Lift and remove small block being careful not to damage O- rings/filter. c. Clean filter and re-install. d. Remove large nut on side of large valve block.
Page 100 Grease Gun Lithium-Complex Mobilgrease CM-S U-joint & Stub Shaft Extreme Pressure NLGI 2 - ISO 320 Deck Spindle (Rotary) Grease Gun Tiger Part Spindle Lubricant Mobilith SHC 220 Part Number 06540000 SIDE ROTARY Maintenance Section 4-10 © 2014 Alamo Group Inc.
Page 101 The proprietary UV and Abrasion Resistant surface coating on SHIELDS SUPERCOATED polycarbonate significantly improves performance. Periodic cleaning using proper procedures and compatible cleaners are recommended to prolong service life. Tiger Corp. polycarbonate is SUPERCOATED on both sides. CLEANING THE SUPERCOAT HARD-COAT 1.
Page 102 MAINTENANCE RECOMMENDED FILLING INSTRUCTIONS FOR HYDRAULIC RESERVOIRS When filling or checking the oil level, the unit should be parked on a level surface., shut “OFF”, and allow sufficient time to cool to ambient temperature. Use caution when removing the pressurized breather.
Page 103 MAINTENANCE REPLACING HIGH PRESSURE HYDRAULIC FILTER ELEMENT Be certain that th e system has bee n shut down and depressurized. Locate High Pressure Filter housing. Confirm that the new element to be installed matches the element p/n on the filter model tag. Example: V3.0510-06 (world line 100, HD049 model).
Page 104 MAINTENANCE GREASING THE SHEAVE Locate the grease zerk on the ends of the sheave pin. Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications into the pin until it pr otrudes from the ends. This should be greased daily or for every 8 hours of service.
Page 105 MAINTENANCE GREASING DRAFT BEAM PIVOT POINTS Locate the grease zerks on the inner and outer draft beam pivot bosses. Inject Lithium-Complex extreme pressure grease, conforming to NLGI2- ISO 320 specifications, into each zerk until grease protrudes from joints. Gr ease all pivots daily or every 8 hours of service.
Page 106 MAINTENANCE DRIVE SHAFT YOKE, U-JOINT & STUB SHAFT With engine stopped, inject Lithium-Complex extreme pressure grease, conforming to NL GI2-ISO 320 specifications, into universal joints and slip yoke until grease appears at the seal. Grease them daily or every 8 hours.
Page 107 COUPLED TO MOTOR OR PTO! Failure to do so will result in component failure! GREASING SPINDLE Locate grease fitting o n inside of deck hou sing. Inject Tiger Spindle Lubricant, part number 06540000, into spindle ho using. Fill with lubricant until lubricant weeps out of to p spindle seal.
Page 108 GREASING MOTOR SPLINE TO SPINDLE SPLINE For direct drive mowers, locate motor spline and spindle spline on the mower deck. Grease splines with Accrolube (Tiger # 06520310). Use about 4 ounces of grease. Change grease yearly or every 500 hours. SIDE ROTARY Maintenance Section 4-18 ©...
Page 109 MAINTENANCE Blades Check the Blades for cracks and wear and Blade Bolts for tightness, daily. Blades should be replaced when they are worn excessively, bent, deformed, or out of balance. Blades should always be replaced in pairs. Blades of different weights can cause serious imbalance and damage to the machine and personnel.
Page 110 MAINTENANCE ROTARY KNIFE REPLACEMENT 1. Be sure you have a complete matching set of new knives for replacement. 2. Remove knives and inspect holes for damage. Also watch for cracks in the disk around the holes. 3. Lube threads with anti-seize, motor oil or grease. Install bolts through knife and disk from bottom side of disk.
Page 111 HEAVY DUTY SPINDLE ASSEMBLY INSTALLATION AND BEARING ADJUSTMENT A press MUST be used to in stall bearing cups, bearing cones, and seals. DO NOT u se a hammer to install races, bearings, or seals. The parts of assembly may be damaged. NOTE: The grease zerk and gussets are located on the top side of the spindle housing.
Page 112 5. Turn the spindle housing over (up position) and fill with Tiger Spindle Lubricant (part number 06540000) to the top edge of the upper bearing cup.
Page 113 MAINTENANCE DAILY MAINTENANCE SCHEDULE The following services should be performed daily or every 8 hours of service, following the detailed maintenance instructions in the operator’s manual. _______ Pump Driveshaft: Check for end play in driveshaft / coupler and lubricate at zerks. _______ Crankshaft adapter: If equipped with rubber grommets check condition, replace if missing or damaged.
Page 115: Parts Section
JD6xxx PARTS SECTION...
Page 116 PART NAME INDEX PARTS ORDERING GUIDE ..................................3 TRACTOR MOUNT KIT....................................4 TRACTOR MOUNT KIT - HYDRAULICS..............................6 CABLE (MANUAL) LIFT VALVE - 2 SPOOL............................8 2 SPOOL CABLE CONTROL STAND..............................10 DRAFT BEAM ASSEMBLY..................................12 BERM DRAFT BEAM....................................14 BERM DRAFT BEAM - HYDRAULICS..............................
Page 119 TRACTOR MOUNT KIT Continued... ITEM PART NO. QTY. DESCRIPTION 06300383 MAINFRAME MOUNT, JD6110M, T4F 06402946 RISER, LH, 06300383 33880 FLATWASHER, 3/4" GR8, SAE 06530237 CAPSCREW, 3/4" X 2-1/4" NC GR8 06531008 HEX NUT, 3/4" NC, GR8 31731 CAPSCREW, 20MM X 50MM (2.5 PITCH) 06300459 AXLE BRACE, RH, TM, JD6110M, T4F 06300387...
Page 121 TRACTOR MOUNT KIT - HYDRAULICS Continued... ITEM PART NO. QTY. DESCRIPTION ------ MAIN FRAME *REFER TO TRACTOR MOUNT KIT ------ HYDRAULIC TANK *REFER TO TRACTOR MOUNT KIT 06503084 ELBOW,1-1/2"FOR X 1-1/2"FOR 06503083 ADAPTER,1-1/2"MOR X 1-1/2"MOR 34309 BALL VALVE,1-1/2"FOR 34710 ADAPTER,1-1/2"MOR X 1-1/2"MJ 32382 BRACKET,HOSE 27281...
Page 123 CABLE (MANUAL) LIFT VALVE - 2 SPOOL Continued... ITEM PART NO. QTY. DESCRIPTION 06340063 VALVE MOUNTING PLATE 6502041 VALVE,2SPHSC,TM,COMBO,LS 06505100 CABLE CONTROL,108" 6T4411 CLEVIS,CBL CTRL,3/16" 21500 HEX NUT,1/4",NF 6T3017 ROLL PIN 32678 ADAPTER,5/8MORB X 1/2FORB 33382 ELBOW,1/2MORB X 1/2MJ X 90 33383 ELBOW,5/8MORB X 1/2MJ X 90 21632...
Page 125 2 SPOOL CABLE CONTROL STAND Continued... ITEM PART NO. QTY. DESCRIPTION 23865B CBL CTRL MT BRK 6T1251 CBL CTRL BOX,180 DEG 34496 BRKT,SWITCHBOX,UNI 6510102 SWITCHBOX,SIDE,GND 6T3951 SCREW,MACHINE 8/32" X 1/2" 32360 LOCKWASHER,#8 30750A BRKT,CBL CTRL,JD6000 33534 CAPSCREW,10MM X 20MM,1.5P 32691 LOCKWASHER,10MM 21544 CAPSCREW,1/4"...
Page 127 DRAFT BEAM ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 06350032 DRAFT BEAM, HD CMB, SHRT 6T0151R HYD CYLINDER 3" X 10" 25343 HYD CYLINDER 3" X 12" TF4500A PIVOT ARM TF4507B RIGHT LINKAGE ARM TF4506B LEFT LINKAGE ARM TF4514A PIN, HEAD PIVOT 6T3001 PIN, BEAM PIVOT TF4519...
Page 129 BERM DRAFT BEAM Continued... ITEM PART NO. QTY. DESCRIPTION 06300398 MAINFRAME, TSF, JD6110M, BERM 06350019 DRAFT BEAM, BERM 06320298 BONNET, 75 XD, RH, BERM 06420203 PIN, 1.50 X 6.19 W/.47 PULL TF4514A PIN, SWIVEL, 1-1/2" X 4-1/2" (CAPPED) 21688 CAPSCREW, 7/16 X 3-1/4, NC 21677 NYLOCK NUT, 7/16"...
Page 130 BERM DRAFT BEAM - HYDRAULICS ITEM PART NO. QTY. DESCRIPTION 30481 CYLINDER 3" X 8" 610150 CYLINDER 3" X 18" 6T1051R CYLINDER 3" X 10" RTRY TOP PORT 33271 ADAPTER, 1/2" X 3/8" 34128 TEE, BRANCH, 3/8"MJ X 3/8"FJX X 3/8"MJ 32810 ELBOW, 1/2"...
Page 132 WHEEL SPACER ITEM PART NO. QTY. DESCRIPTION AL156779 SPCR, WHL, JD, 1.732 06400919 RING, SPACER, WHEEL, JD 6T2548 CAPSCREW, 20MM X 60MM JD6110-30M R T4F SIDE ROTARY ©2019 Alamo Group Inc. Parts Section -18...
Page 133 COMMON SIDE ROTARY PARTS SECTION...
Page 134 NOTES...
Page 135 PART NAME INDEX PARTS ORDERING GUIDE ..................................5 CABLE DRAFT BEAM ASSEMBLY................................6 COMBO DRAFT BEAM ASSEMBLY................................ 8 60IN SIDE CABLE TM ROTARY MOWER............................. 10 72IN SIDE CABLE TM ROTARY MOWER............................. 12 60IN SIDE COMBO TM ROTARY MOWER ............................14 72IN SIDE COMBO TM ROTARY MOWER ............................
Page 136 PART NAME INDEX FIRE SUPPRESSION FRONT MOUNT..............................68 FIRE SUPPRESSION SYSTEM ELECTRICAL SCHEMATIC........................ 70 WETCUT........................................71 WETCUT 50 GALLON TANK - 3PNT MOUNT............................72 WETCUT 100 OR 150 GALLON TANK - 3PNT MOUNT........................73 WETCUT 3PNT PLUMBING - 50IN MOWERS............................74 WETCUT 3PNT PLUMBING - LARGE MOWERS..........................
Page 139 CABLE DRAFT BEAM ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 6T0105 DRAFT BEAM (STD WITH TRAVEL LOCK) ------- 27241 DRAFT BEAM (EXTENDED 6”) 6T0150 CYLINDER 3” X 18” 6T0151R HYD. CYLINDER 3” X 10” 6T0100 LOWER SHEAVE BRACKET 6T0101 UPPER SHEAVE BRACKET 33768 SHEAVE 6T0110...
Page 141 COMBO DRAFT BEAM ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 06350001 COMBO DRAFT BEAM - STD DTY ROTARY 31063 COMBO DRAFT BEAM - HVY DTY ROTARY 6T0151R HYD. CYLINDER 3” X 10” 32215 HYD. CYLINDER 3” X 12” - STD DTY 25343 HYD.
Page 143 60IN SIDE CABLE TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 32099 RTRY, 60" DECK, CABLE 31773 GAURD,CHAIN,FRONT,SR60 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 6T0820H SKID SHOE, TM60 22592 FLAP, DEFLECTOR, TM60 6T0823 BAR, FLAP, TM60 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8" HOLES 21223 SPROCKET, 1-1/4"...
Page 145 72IN SIDE CABLE TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 21225B RTRY,72" DECK, CABLE 31931 GUARD,CHAIN,FRONT,SR72 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 21248 SKID SHOE, TM72 21295B FLAP, DEFLECTOR, TM72 21242A BAR, FLAP, TM72 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8" HOLES 21223 SPROCKET, 1-1/4"...
Page 147 60IN SIDE COMBO TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 30087D RTRY, 60" DECK, COMBO - STD DUTY 32617 RTRY, 60” DECK, COMBO - HEAVY DUTY 31773 GUARD,CHAIN,FRONT,SR60 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 6T0820H SKID SHOE, TM60 22592 FLAP, DEFLECTOR, TM60 6T0823...
Page 149 72IN SIDE COMBO TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 34260 RTRY, 72" DECK, COMBO - STD DUTY 31408A RTRY, 72” DECK, COMBO - HEAVY DUTY 31931 GUARD,CHAIN,FRONT,SR72 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 21248 SKID SHOE, TM72 21295B FLAP, DEFLECTOR, TM72 21242A...
Page 151 60IN SIDE TM CHAIN GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 31773 GUARD,CHAIN,TM60,FRONT,ASSY 31762 GUARD,CHAIN,TM60,FRONT 28407 CABLE,5/16",BULK (QTY IN FEET) 22993 CHAIN,5/16",GR30,9 LINK 28408 U-BOLT,CABLE,5/16" (NOT SHOWN) 31774 GUARD,CHAIN,TM60,REAR,ASSY 31763 GUARD,CHAIN,TM60,REAR 31879 ROD,SHORT,TM60 31878 ROD,LONG,TM60 22016 FLATWASHER,3/8",GR8 6T3028 COTTER PIN,1/8" X 1" 22992 CHAIN,5/16",GR30,10 LINK COMMON SIDE ROTARY...
Page 153 72IN SIDE TM CHAIN GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 31931 GUARD,CHAIN,TM72,FRONT,ASSY 31863 GUARD,CHAIN,TM72,FRONT 28407 CABLE,5/16",BULK (QTY IN FEET) 22993 CHAIN,5/16",GR30,9 LINK 28408 U-BOLT,CABLE,5/16" (NOT SHOWN) 31932 GUARD,CHAIN,TM60,REAR,ASSY 31864 GUARD,CHAIN,TM60,REAR 31934 ROD,LONG,TM72 31933 ROD,SHORT,TM72 22016 FLATWASHER,3/8",GR8 6T3028 COTTER PIN,1/8" X 1" 22992 CHAIN,5/16",GR30,10 LINK COMMON SIDE ROTARY...
Page 155 60IN SIDE TSR ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 34975 HEAVY DUTY GRASSKAT COMBO ------ 06320005 STD DUTY GRASSKAT COMBO ------- 06320008 HEAVY DUTY GRASSKAT CABLE 34980 SPINDLE ASSY,TM 60" 06504016 CURRENT MOTOR,(M365-1 1/4" 14-SPLINE) 06410254 SKID,OUTBOARD,TM60 22992 CHAIN,10 LINK 6T2270 PLOW BOLT,3/8"...
Page 157 60IN SIDE TSR REAR GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 34973 ROD,CHAIN,OUTER,TM60 34974 ROD,CHAIN,INNER,TM60 21631 CAPSCREW, 3/8 X 1-1/4,NC 34972 PLATE,CAP,CHAIN 21625 HEX NUT,3/8",NC 21988 LOCKWASHER, 3/8" 22992 CHAIN,10 LINK 06410947 MNT,FLAP,RH,EXT,TSR 06401184 STRAP,FLAP,EXT,TSR 06410948 COVER,FLAP,EXT,TSR 21632 CAPSCREW,3/8" X 1-1/2" NC 22016 FLATWASHER,3/8",GR8 06410946...
Page 159 SIDE ROTARY CASTER WHEEL ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 25214C FRAME,CASTER,WHL (TM60) 28297A FRAME,CASTER WHL (TM72) 22057 SPINDLE,CASTER AXLE,ASSY 6T2617 BUSHING,MACH,1-1/2IDX 2-1/4OD 28548 CASTER WHEEL,SOLID TIRE 22065 HUB,ASSY,CASTER ---- 22066 HUB,CASTER 22070 DUST CAP ---- 22071 HUB STUD 22073 HEX NUT,1”,NF (SLOTTED) ----...
Page 160 CASTER WHEEL ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 22057 SPINDLE,CASTER AXLE,ASSY 21987 LOCKWASHER,5/16” 21575 HEX NUT,5/16” 28548 CAPSCREW,5/16” X 3/4”,NC 22697 RIM,OUTER,CASTER ASSY 21416 TIRE,SOLID 22696 RIM,CASTER WHEEL 22070 DUST CAP 22533 COTTER PIN,3/16” X 2” 6T0836 CUP,CASTER WHEEL 22073 HEX NUT,1",NF (SLOTTED JAM NUT) 22071 HUB STUD...
Page 161 ROTARY DISK AND KNIVES ITEM PART NO. QTY. DESCRIPTION 34876 BLADE MOUNTING DISK 6T1023R NYLOCK NUT,1-1/8” 34878 SPACER 34497 KNIFE MOUNTING BOLT 34685 KNIFE,60" HIGH SUCTION - STANDARD 34684 KNIFE,60" - OPTIONAL 34682 KNIFE 72” (MOUNT ON 72” MOWER ONLY) 25270 FLATWASHER,5/8",USS,GR8 6T2259...
Page 163 TM MOWER SPINDLE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ 6T1024H5 SPINDLE ASSEMBLY COMPLETE 6T1031 SPROCKET 6T1016 BEARING LOCK NUT - THICK 22596 JAM WASHER 6T1015 BEARING ADJUSTMENT NUT - THIN 6T1014 BEARING ADJUSTMENT SLEEVE 6T1011 UPPER SEAL - SET OF 2 6T1012 BEARING CONE 6T1013...
Page 165 TSR MOWER SPINDLE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ 34980 SPINDLE ASSEMBLY COMPLETE 34978 SPINDLE MOUNT 34979 SPINDLE,TM60 6T1013 BEARING CUP 6T1012 BEARING CONE 6T1011 UPPER SEAL - SET OF 2 6T1014 BEARING ADJUSTMENT SLEEVE 6T1013H BEARING,CUP,HD 6T1012H BEARING CONE,HD 6T1011H SEAL,LOWER,HD...
Page 167 ROTARY MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504011 MOTOR ASSEMBLY 22790 END,COVER 06504088 HOUSING, PEC 06504111 HOUSING, GEAR 06504026 SET, GEAR SHAFT 06504104 CAPSCREW 06504078 SCREW, DRIVE 06504092 06504093 PIN, DOWEL 06504094 NAME PLATE 06504095 THRPL 2961940 PLUG, ODT 2962200 RING, SNAP 06504096...
Page 169 60IN TSR ROTARY MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504016 MOTOR(M365-1 1/4SPLINE),SEALED 22790 COVER,END 06504088 HOUSING,PEC 06504111 HOUSING,GEAR 06504110 SET,GEAR SHAFT 06504104 CAP SCREW 06504078 SCREW,DRIVE 06504093 PIN,DOWEL 06504094 NAME PLATE 06504095 THRPL 02961940 PLUG,ODT (0.25) 6T5200 RING,SNAP 06504097 SEAL,LIP 22797...
Page 171 FRONT HYDRAULIC PUMP BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 23152 PUMP ASSEMBLY,1-3/4”,COMPLETE 22766 SHAFT END COVER 22779 PORT END COVER 22774 GEAR HOUSING,1-3/4” 22771 GEAR SET 23824 CAPSCREW 06504078 SCREW,DRIVE 22773 DOWEL PINS 06504077 NAMEPLATE 22770 THRUST PLATE 22767 PLUG 06504075 SEAL,BK-UP...
Page 172 PUMP AND GRILL GUARD OPTIONS ITEM PART NO. QTY. DESCRIPTION 32430 UNIVERSAL PUMP GUARD 32737 UNIVERSAL GRILL GUARD 21833 CAPSCREW,3/4" X 2-1/4",NC 22021 FLATWASHER,3/4" 21993 LOCKWASHER,3/4" 21825 HEX NUT,3/4",NC COMMON SIDE ROTARY ©2014 Alamo Group Inc. Parts Section 6-40...
Page 173 RESERVOIR TANK FILTER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06505044 FILTER ASSY SAE 10 MICRON 28583 CAPSCREW,8MM X 25MM(1.25 PITCH) 06505045 COVER 06505046 SEAL KIT 06505047 SPRING 06505048 BYPASS 35259 FILTER,10 MIC,RETURN LINE 06505049 CAN/BODY COMMON SIDE ROTARY ©2014 Alamo Group Inc. Parts Section 6-41...
Page 174 COOLER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 21530 CAPSCREW,1/4 X1 NC 21986 LOCKWASHER,1/4 22014 FLATWASHER,1/4 35176 1/4 U-NUT 06370015 SCREEN,COOLER,FRNT 06380006 MNT,COOLER,BUMPER TANK,RH 06380007 MNT,COOLER,BUMPER TANK,LH 06510026 COOLER,FRONT MNT 06510029 FAN ASSY, ONLY 21629 CAPSCREW,3/8 X 3/4 NC 21988 LOCKWASHER,3/8 22016 FLATWASHER,3/8 34117...
Page 175 3IN X 10IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 6T0151R HYD. CYLINDER 3" X 10" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0164 CYLINDER TUBE 6T0161 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0176 TIE ROD ASY ------ 6T0187 SEAL KIT...
Page 176 3IN X 12IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 32215 HYD. CYLINDER 3" X 12" (STD DUTY) 25343 HYD. CYLINDER 3" X 12" (HVY DUTY) 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0204 CYLINDER TUBE 6T0203 PISTON ROD 6T0173...
Page 177 3IN X 18IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 6T0150 CYLINDER 3" X 18" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0165 CYLINDER TUBE 6T0162 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0177 TIE ROD ASY ------ 6T0187 SEAL KIT...
Page 179 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 30801 Continued... ITEM PART NO. QTY. DESCRIPTION TB1017S INLET END COVER TB1702 END COVER, POWER BEYOND TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) 06502091 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) (NO AUX VALVE PORTS) TB1017M SHUT-OFF PLUG TB1017E...
Page 181 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31320 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 06503067 RELIEF PLUG 06503067 RELIEF PLUG 6T4209 RELIEF PLUG...
Page 183 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31321 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 06503067 RELIEF PLUG 31861 RELIEF VALVE, 360 PSI 6T4209 RELIEF PLUG...
Page 185 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31752 Continued... ITEM PART NO. QTY. DESCRIPTION TB1017S INLET END COVER TB1702 END COVER, POWER BEYOND TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) TB1017M SHUT-OFF PLUG TB1017E RELIEF VALVE, 2250 PSI TB1017M SHUT-OFF PLUG...
Page 187 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502040 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) (REMOVE SHUTTLE DISC) 06503067 RELIEF PLUG 06503067 RELIEF PLUG...
Page 189 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502041 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 06503067 RELIEF PLUG 31861 RELIEF VALVE, 360 PSI 06503068 RELIEF PLUG...
Page 190 BRAKE VALVE ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06510083 BRAKE VALVE, ASSY 34092 BRAKE VALVE, BLANK 34094 LOGIC ELEMENT 34095 RELIEF VALVE, 3000 PSI 06510095 METRI PAK COIL 34093 CARTRIDGE, 2 POSITION, 3 WAY (WITH NUT & WASHER) 34091 RELIEF VALVE, 2600 PSI 34096 RELIEF SEAL KIT ----...
Page 192 CABLE DRAFT BEAM TRAVEL LOCK ITEM PART NO. QTY. DESCRIPTION ------ CABLE DRAFT BEAM 6T0106 TRAVEL LOCK BRACKET 6T0107 TRAVEL LOCK PINS 3/4” X 3 1/4” 6T3020 R - CLIP 5/32” 21833 CAPSCREW 3/4” X 2 1/4” 21825 HEX NUT 3/4” 21993 LOCK WASHER 3/4”...
Page 193 COMBO DRAFT BEAM TRAVEL LOCK ITEM PART NO. QTY. DESCRIPTION ------ COMBO DRAFT BEAM 6T0106 TRAVEL LOCK BRACKET 21835 CAPSCREW,3/4” X 2-3/4”,NC ------ MAIN FRAME *REFER TO PARTS SECTION 33856 BRKT,PIN HOLDER 21988 LOCKWASHER,3/8” 21629 CAPSCREW,3/8” X 3/4”,NC 6T3020 R-CLIP,5/32” 6T0107 TRAVEL LOCK PINS,3/4”...
Page 194 SWITCH BOX ITEM PART NO. QTY. DESCRIPTION 06514013 SWBX,ALUM,BLK,06510102 35226 SWITCH,MOWER,COLEHERSEE 33811 SWITCH,MASTER/DECK FLOAT 6T3923 INDICTATOR LIGHT,ON,RED 06514014 BREAKER,10A,SWBX 34540 STRAIN RELIEF,3/4,BLACK,NYLON 06550018 DECAL,SWTCHBX,TM/TSF,CG 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON SIDE ROTARY ©2014 Alamo Group Inc. Parts Section 6-62...
Page 197 WARRANTY SECTION Warranty Section 7-1...
Page 199: Warranty Information
All Tiger obligation under this warranty shall be terminated if the equipment is modified or altered in ways not approved in writing by Tiger, if repair parts other than genuine Tiger repair parts have been used, or if the equipment has been subject to misuse, neglect, accident, improper maintenance or improper operation.
Page 200 . Common sense should play a large role in the operation of this machine. Since we at Tiger Corporation are constantly striving to improve out products, we reserve the right to change specifications or design at any time.
Page 201 TO THE OWNER / OPERATOR / DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this manual and on the machine. The table of contents clearly identifies each section where you can easily find the information you need. The Occupational Safety and Health Act (OSHA 1928.51 subpart C) makes the following minimum requirements for tractor operators.
