Summary of Contents for BFC Lira
- Page 1 • INSTRUCTIONS FOR PROGRAMMING LIRA CONTROL UNIT WITH DISPLAY USER...
- Page 3 PROGRAMMING COFFEE QUANTITIES AND CLOCK TO PROGRAM THE QUANTITY OF COFFEE PRESS BUTTON 5 “P” FOR LONGER THAN 5 SECONDS. BUTTON 5 STARTS FLASHING. AT THE SAME TIME BUTTONS 1 – 2 – 3 – 4 – 6 GO OFF. THE DISPLAY SHOWS: 5 sec.
- Page 4 TO SEE THE TOTAL NUMBER OF COFFEE QUANTITIES DISPENSED PRESS BUTTON 5 “P” FOR LONGER THAN 10 SECONDS, THEN PRESS THE SAME BUTTON REPEATEDLY UNTIL THE DISPLAY SHOWS THE MESSAGE BELOW. PRESS THE BUTTON AGAIN TO SEE HOW MANY COFFEE QUANTITIES HAVE BEEN DISPENSED BY EACH GROUP.
- Page 5 KEYBOARD BRIGHTNESS ADJUSTMENT TO SET THE FOLLOWING FUNCTION PRESS THE BUTTONS BELOW AFTER TURNING ON THE MACHINE: • BUTTON 1+ 5 = MAXIMUM BRIGHTNESS • BUTTON 2+ 5 = MEDIUM BRIGHTNESS • BUTTON 3+ 5 = MINIMUM BRIGHTNESS • BUTTON 4+ 5 = BRIGHTNESS OFF INSTRUCTIONS FOR WASHING THE GROUP WHILE THE MACHINE IS ON KEEP BUTTON 5 ”P”...
- Page 7 • INSTRUCTIONS FOR PROGRAMMING LIRA CONTROL UNIT WITH DISPLAY TECHNICIAN...
- Page 8 DISPLAY CONTRAST AND BRIGHTNESS ADJUSTMENT AFTER YOU HAVE REPLACED THE CONTROL UNIT ADJUST DISPLAY CONTRAST AS FOLLOWS: 1. REMOVE THE COVER OF THE CONTROL UNIT. 2. USING A SLOTTED SCREWDRIVER (A) ROTATE THE SCREW (B) AS SHOWN TO ADJUST DISPLAY CONTRAST.
- Page 9 TECHNICIAN LEVEL PROGRAMMING TO SET THE MACHINE IN “OFF FUNCTION” KEEP BUTTON 5 “P” PRESSED WHILE PRESSING BUTTON 3. THE DISPLAY SHOWS THE MESSAGE BELOW. WHEN IN “OFF” FUNCTION PRESS BUTTON “P” FOR 10 SECONDS UNTIL THE DISPLAY SHOWS “ Language“. PRESS BUTTONS 1 ( NEXT ) AND 2 ( PREV.) TO SELECT THE DESIRED LANGUAGE.
- Page 10 PRESS BUTTON 5 “P” AGAIN TO MOVE ON TO THE NEXT SETUP. THE DISPLAY SHOWS “ Function Crono “ ( COFFEE DISPENSING DURATION IN SECONDS) . PRESS BUTTON 1 ( ENABLED ) TO ENABLE OR BUTTON 2 ( DISABLED ) TO DISABLE. PRESS BUTTON 5 “P“ TO CONFIRM. PRESS BUTTON 5 “P”...
- Page 11 PRESS BUTTON 5 “P” AGAIN TO MOVE ON TO THE NEXT SETUP. THE DISPLAY SHOWS “ Doses setting “ . PRESS BUTTON 1 ( ENABLED ) TO ENABLE OR BUTTON 2 ( DISABLED ) TO DISABLE. PRESS BUTTON 5 “P“ TO CONFIRM.
- Page 12 THE DISPLAY SHOWS “ Steam boiler Gr “ . THIS IS AN OPTIONAL FUNCTION. THIS FUNCTION ENABLES THE DESIRED CONTROL PANEL, WHICH CONTROLS THE STEAM UNIT. PRESS BUTTON 1 ( NEXT 0-1-2-3 ) OR BUTTON 2 ( BACK 3-2-1-0 ) . PRESS BUTTON 5 “P“ TO CONFIRM. PRESS BUTTON 5 “P”...
- Page 13 PRESS BUTTON 5 “P” AGAIN TO MOVE ON TO THE NEXT SETUP. THE DISPLAY SHOWS “ Service Cycles “. THIS FUNCTION SHOWS HOW MUCH COFFEE CAN BE DISPENSED BEFORE THE “MAINTENANCE” MESSAGE APPEARS WITHOUT STOPPING THE MACHINE. PRESS BUTTON 1 ( NEXT ) OR BUTTON 2 ( BACK ) TO SELECT THE DIGITS.
