SECTION 8—SEAT/BACK
3. Remove the back upholstery from the back canes. Refer to Detail "B".
DETA IL "A"
D E T A I L " B "
Upholstery
Back Cane
FIGURE 4.3 Removing/Installing Standard Back Upholstery
Assembly description Screw Tool Torque
Upholstery fixation CR B CS ST 4,8x16 Pozidriv #2 2,5 ±0,5 Nm
