CLUB CAR CARRYALL
Side View Mirrors
p/n: 47587417001
Approximate Installation Time *
Approximate Product Specifications
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 30 Minutes
Do-It-Yourself – 45 Minutes
(*=Not including accessories)
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Rev. C, 08/03/2020
p/n: IM-47587417001
Advertisement
Related Manuals for Curtis 47587417001
Summary of Contents for Curtis 47587417001
- Page 1 1 of 4 CLUB CAR CARRYALL Side View Mirrors p/n: 47587417001 Approximate Installation Time * Approximate Product Specifications Experienced Dealer Technician – 15 Minutes Average Dealer Technician – 30 Minutes Do-It-Yourself – 45 Minutes (*=Not including accessories) The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
- Page 2 For accurate installation, proper operation, and years of satisfaction, please read and understand the installation and owner’s manual fully prior to installing the mirrors. From all of us at Curtis, we thank you for choosing our product TOOLS REQUIRED: ADDED WEIGHT 3/8”...
- Page 3 3 of 4 MIRROR INSTALLATION 2. Carryall 4x2 - On Cab Doors: 2.1 Remove rubber plugs from doors in location shown in figure 2.1. 2.2 Install mounting adapter to driver’s side door of the cab through holes where dome plugs were removed, using 1/4-20 x 3/4”...
- Page 4 4 of 4 SERVICE PARTS PART NUMBER. DESCRIPTION QTY. 9SV-PM5L EXTERIOR MIRROR, LEFT 9SV-PM5R EXTERIOR MIRROR, RIGHT...
