Instructions for Continued Airworthiness
Reg. No.____________
Rev.
Date
1
07/16/10
2
08/11/10
3
04/09/15
4
06/18/15
5
02/08/17
500W Series
Bell 206B
Dwg. Number:
190-01226-03 Rev. 5
Garmin International, Inc.
1200 E. 151st Street
Olathe, Kansas 66062 USA
Record of Revision
Initial Release
Updated ref. doc. revisions in section 2.1, revised part number and weight
of item 2 in table 2.2.1.
Add information for remote HTAWS annunciators
Updated Airworthiness Limitations section
Updated troubleshooting table section and interconnects to add GDL 88H
and GTX 3X5
S/N_______________
Description of Change

Advertisement

Table of Contents
loading

Related Manuals for Garmin 500W Series

Summary of Contents for Garmin 500W Series

  • Page 1 500W Series Instructions for Continued Airworthiness Bell 206B Reg. No.____________ S/N_______________ Dwg. Number: 190-01226-03 Rev. 5 Garmin International, Inc. 1200 E. 151st Street Olathe, Kansas 66062 USA Record of Revision Rev. Date Description of Change 07/16/10 Initial Release 08/11/10 Updated ref. doc. revisions in section 2.1, revised part number and weight of item 2 in table 2.2.1.
  • Page 2 Company Proprietary Information This drawing and the specifications contained herein are the property of Garmin International or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission.

  • Page 3: Table Of Contents

    ICA Revision and Distribution ................22     2.16 Assistance......................23     2.17 Implementation and Record Keeping ..............23     AIRWORTHINESS LIMITATIONS ..................23 500W Series 190-01226-03 Rev. 5 Instructions for Continued Airworthiness Bell 206B Page 3 of 23...

  • Page 4: Introduction

    1.4 Permission to Use Certain Documents Permission is granted to any corporation or person applying for approval of a Garmin Model 500W series to use and reference appropriate STC documents to accomplish the Instructions for Continued Airworthiness and show compliance with STC engineering data.

  • Page 5: Instructions For Continued Airworthiness

    2.1 Introduction Content, Scope, Purpose and Arrangement: This document identifies the Instructions for Continued Airworthiness for the modification of the rotorcraft by installation of a 500W series GPS/WAAS Nav/Com unit under the Garmin Bell 400W/500W HTAWS STC SR02080SE. Applicability: Applies to Bell model 206B rotorcraft altered by...

  • Page 6: Description Of Alteration

    This STC upgrades existing avionics for the Bell 206B rotorcraft as summarized below. The Garmin Model 500W Series GPS/WAAS Nav/Com unit is a 6 ¼ inch wide unit mounted in the center pedestal of the Bell 206B. The 500W Series units combine a large number of easily accessible controls to use the color multi-function display, Nav and Com transceiver, GPS/WAAS navigator in a single unit.
  • Page 7 013‐00245‐00 0.50 [1] A rotorcraft weight and balance is required after installation of the 500W Series Unit. Refer to the 500W Rotorcraft STC Installation Manual listed in paragraph 2.1 of this document, for additional information, including overall size and center of gravity location of all LRUs.

  • Page 8: Control, Operating Information

    The moment arms to the left side (looking forward) are negative (-) and the moment arms to the right side are positive (+). [4] Location of the 500W Series unit and GPS antenna may vary slightly depending whether or not a dual navigator system is installed.
  • Page 9 2.5 milliohms. Reinstall the 500W Series unit in the mounting rack. GPS Antennas Every 2000...
  • Page 10 The display backlight lamp is rated by the manufacturer as having a usable life of 20,000 hours. This life may be more or less than the rated time depending on the operating conditions of the 500W Series unit. Over time, the backlight lamp may dim and the display may not perform as well in direct sunlight conditions.

  • Page 11: Troubleshooting Information

    2.6 Troubleshooting Information If error indications are displayed on the 500W series unit, consult the Troubleshooting section contained below: Table 2 Troubleshooting Guide Problem Possible Cause Solution  The unit is not getting power to  The 500W Series Make sure power is connected to the unit does not power the main connector P5001.
  • Page 12  Device not compatible, or  Verify 500W Series unit RX is improper connection. connected to remote device TX and 500W Series unit TX is connected to remote device Rx.  Multiple TX lines connected  Verify that there is only one TX together.
  • Page 13 2.6.1 500W Series Alerts The 500W Series will display a number of alerts. These are listed in the following table. Table 3. 500W Series Alert Troubleshooting Guide Alert Text Possible Cause Solution ADS-B traffic has failed  The ADS-B traffic system may have ...
  • Page 14  Go to the MAIN CDI/OBS CDI key disabled the MAIN CDI/OBS CONFIG page. CONFIG page and deselect “Ignore CDI key”  The 500W Series unit has detected  Check for adequate ventilation Check unit cooling excessive display backlighting or check cooling airflow. Refer temperature.
  • Page 15 (user re-attempted. re-transmit waypoints and/or flight plans). Display backlight failure  The 500W Series unit has detected a  Contact Garmin technical failure in the display backlighting. support.  The 500W Series unit is in Demo ...
  • Page 16 3.20 and later). processor and the GPS receiver has failed. Operational status of the GPS receiver is unknown.  The 500W Series unit has detected a  Contact Garmin technical GPS needs service failure in its GPS receiver. support.
  • Page 17 RS-232 (Serializer: Icarus, Rosetta or device is not communicating Shadin) or grey code inputs. with the 500W/530W”.  The 500W Series unit has detected a  Contact Garmin technical No basemap data available failure in the built-in basemap (land support to reload the basemap data) memory.
  • Page 18  Reload the TERRAIN database.  Contact Garmin technical support. Traffic device has failed  The 500W Series unit cannot  Check for proper configuration communicate with the traffic system  Check for correct wiring and/or the traffic system is reporting a ...
  • Page 19 Alert Text Possible Cause Solution  The GNS 530W has detected a failure  Contact Garmin technical VLOC has failed (530 only) in its VLOC receiver. support.  Internal system-to-system  Contact Garmin technical VLOC is not responding (530W only) communication between the main support.

  • Page 20: Removal And Installation Information

    New, Repaired or Exchange 500W Series is Installed If the 500W Series unit is removed for repair and reinstalled, or if the 500W unit is removed and replaced with a different 500W Series unit, then verify the correct software versions are on the 500W Series unit as specified in the Equipment List 400W/500W Series Installation Bell 206B STC listed in paragraph 2.1...

  • Page 21: Diagrams

    Installation drawing Bell 206B, listed in Section 2.1 of this document. Point to point wiring diagrams are in the Appendix of the 500W Rotorcraft STC Installation Manual. Refer to the GNS 500W Series Post- Installation Checkout Log retained in the rotorcraft permanent records for a list of the interfaced equipment and port configurations.

  • Page 22: Special Inspection Requirements

    The system does not require overhaul at a specific time period. Power on self-test and continuous BIT will monitor the health of the 500W Series unit. If the unit indicates an internal failure, the unit may be removed and replaced. See troubleshooting section 2.6 contained in this document.
