Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
General Safety Information
Only qualified personnel should install this fan.
Personnel should have a clear understanding of these
instructions and should be aware of general safety
precautions. Improper installation can result in electric
shock, possible injury due to coming in contact with
moving parts, as well as other potential hazards.
1. Follow all electrical and safety codes, as well as
the National Electrical Code (NEC) and the National
Fire Protection Agency (NFPA) where applicable.
Follow the Canadian Electrical Code (CEC) in
Canada.
2. The rotation of the wheel is critical. It must be free
to rotate without striking or rubbing any stationary
objects.
3. Motor must be securely and adequately grounded.
4. Verify the power source is compatible with the
equipment.
®
Wall/Ceiling Exhaust Fan
Model SP-L is a direct drive wall/ceiling exhaust
fan designed for clean air exhaust applications.
Installation options include wall mount frame
construction and ceiling mounts. Accessories are
available, see catalog and CAPS for selections. The
motor is designed for continuous use and is thermally
protected. A backdraft damper is standard on the
outlet of the fan to stop backdrafts when the fan is not
in use and a grille with mounting screws is provided
for quiet, rattle-free operation. Capacities range
from 50-80 cfm and 0.75 in. wg. The SP-L is UL/cUL
Listed for above bathtub or shower with GFCI branch
protected circuit.
Document 481174
Model SP-L
Wall/Ceiling Exhaust Fan 1
