Quick Installation Guide

Super G Wireless Cardbus Adapter

Model # AWLC4130

Section 1

This Quick Installation Guide only provides the basic instructions. For more

advanced features, please refer to the User's Manual in the provided CD.

Note: Do not insert the Cardbus Adapter until you have reached the appointed

step.

Step 1

Insert the Driver & Utility CD into your CD drive and select Install Driver

and Utility from the menu.

Note: If the autorun screen doesn't appear automatically, go to Start, Run, and

type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK.

Ver. 1A

Package Content:

•

Cardbus Adapter

•

Driver & Utility CD

•

Quick Installation Guide

Step 2

Click Next at the welcome screen.

Table of Contents

Page 1: Quick Installation Guide
Quick Installation Guide Super G Wireless Cardbus Adapter Model # AWLC4130 Section 1 Install Utility and Driver This Quick Installation Guide only provides the basic instructions. For more advanced features, please refer to the User’s Manual in the provided CD.
Page 2 Step 3 Click Next to accept the default destination folder to install the software or Section 2 click Browse to manually select a different destination folder. Step 4 Click Next at the Select Program Folder screen. Step 5 Insert the Cardbus Adapter when you are prompted to do so. Step 6 Verify “Yes, I want to restart my computer now”...
Page 3: Configure The Cardbus Adapter
Section 3 Section 2 Configure the Cardbus Adapter Step 1 To open the cardbus adapter’s utility, double-click on the WLAN Monitor Icon in the system tray. The utility automatically adds an available wireless network to the Preferred WLANs box. If no SSID is added, or if the SSID is wrong, please refer to the following steps to join the appropriate wireless network.
Page 4: Technical Support
Step 5 A blue circle will surround the SSID you have chosen after connecting successfully. Click OK to close the window. Congratulations! The installation for your Super G Carbus Adapter is complete. For more advanced features and additional details, please refer to the User’s Manual on the provided CD.
