User Manual
Quick Installation Guide
Wireless N 150 Router
Model # AR570W
Ver. 2A
Package Contents
Before you begin the installation, please check the items of your package:
•
Wireless N 150 Router
•
Power Adapter
•
Ethernet Cable (Cat.5)
•
Setup CD
•
Quick Installation Guide
Section 1
This Quick Installation Guide only provides basic instructions. For detailed
information on using this product, please refer to the User's Manual on the
supplied CD.
Installing the Router
Step 1
Insert the Setup CD into your CD-ROM drive.
Advertisement
Related Manuals for Airlink101 AR570W
Summary of Contents for Airlink101 AR570W
-
Page 1: Quick Installation Guide
Quick Installation Guide Wireless N 150 Router Model # AR570W Ver. 2A Package Contents Before you begin the installation, please check the items of your package: • Wireless N 150 Router • Power Adapter • Ethernet Cable (Cat.5) • Setup CD •... - Page 2 Step 2 Click Next to start the configuration. Step 3 Connect one end of a network cable to the WAN port of the router and connect the other end to your DSL/Cable modem. Step 4 Connect one end of another network cable to the LAN port of the router and connect the other end to your computer.
- Page 3 Step 6 Make sure POWER, WAN, WLAN, and the LAN port that the computer is connected to are lit. If not, try the above steps again. LED Indicators: Light Description Status POWER Router is powered on. WPS setup is in progress. WLAN Wireless network is switched off.
- Page 4 Step 9 Enter the settings for your Internet Connection Type. Dynamic IP (Cable Modem users) Click on Clone to clone the MAC address of your PC to the modem then click Next. PPPoE (DSL users) Enter the user name and password provided by your ISP then click Next. Step 10 Please wait while the Wizard trying to connect to the Internet.
-
Page 5: Connecting To The Router Wirelessly
Step 12 Configure the security key for your wireless network. Check Enable WPA Pre-Share Key. Enter 8 to 63 characters into WPA-Pre-Share Key. Click Next. Step 13 Verify the settings you just configured for the Router. Click Finish to restart the Router. Congratulations! Your router configuration has been finished. -
Page 6: Technical Support
Step 2 Click on the wireless network you want to connect to and click Connect. Step 3 Enter the Security key you configured for the Router (see Step 8 in Section 2). Click Connect. Step 4 Click on Close. Now the wireless connection has been established successfully with the Router.
