COMPONENTS

2-1
[1] [2]
[5] [6]
[10] [11]
[15]
[18] [20]
[21] [22]
[25] [26]
[3] [4]
[7] [8] [9]
[12] [13] [14]
[16] [17]
[19] [20]
[23] [24]
[27] [28]

Unit (Entrance Station)

[1] Speech module panel GH-DP
[2] Speech module GH-DA/A
[3] Camera module panel GF-VP
[4] Camera module GH-VA
[5] 1-call button panel GF-1P
[6] 2-call button panel GF-2P
[7] 3-call button panel GF-3P
[8] 4-call button panel GF-4P
[9] Call switch module GH-SW
[10] Digital name scroll module panel GF-NSP
[11] Digital name scroll module GH-NS
[12] RS-232C cable (included with GH-NS)
[13] Digital keypad module panel GF-10KP
[14] Digital keypad module GH-10K
[15] Address module panel GF-AP
[16] Blank panel GF-BP
[17] Address module GH-AD
[18] 3-module front frame GF-3F
[19] 2-module front frame GF-2F
[20] Mounting bracket (included with GF-3F and GF-2F)
[21] 3-module back box GF-3B
[22] 2-module back box GF-2B
[23] Joint pipe (included with GF-3B and GF-2B)
[24] Mounting gauge (included with GF-3B and GF-2B)
[25] Rain hood GF-nH (option)
[26] Surface-mount box GF-202B (option; for Europe Only)
[27] Hooded surface-mount box GF-nHB (option)
[28] 80 cm (32") connection cable GF-C (option)
