Aiphone NEM-10 Specifications

NEM Master Stations
NEM-10, NEM-20, NEM-30, NEM-40
NAMES & FUNCTIONS:
Power On/Off
Switch
DESCRIPTION:
The NEM series is a selective calling open voice
style intercom system. Masters are available in 10,
20, 30, and 40 station sizes, with optional 20 and 40
call add-on selectors. Maximum capacity is 120
stations. Master stations can be wall or desk
mounted.
Sub stations are available in surface or flush mount
styles, with or without privacy. Outdoor stations are
available in surface or flush mount styles. Vandal
and weather resistant sub stations are also available.
Incoming calls from a sub station are annunciated
with an electronic tone and an LED, remaining
activated until the call is answered at the master or
reset at the calling location. The master answers
the call by selecting the button with the lit LED.
Communication at the master is press-to-talk,
release-to-listen. Person at the sub station speaks
hands free. The master station can selectively call
and talk with any sub station in the system. The
privacy feature on selected sub stations prevents
eavesdropping from the master station.
Several Special Order Product variations of this
system are available. Additional features available
through SOP are selective door release, CCTV
camera call-up, two levels of call signaling from sub
stations, and master units modified for long distance/
elevator applications. See Aiphone's SOP catalog
for more information on these systems.
Mic
Voice/Call tone
Volume controls
Talk button
All Call button

SPECIFICATIONS

Speaker
Station Select
OFF Button
buttons
NEM-20 Pictured
FEATURES:
• Console master system with Lamp Memory,
where call-in tone and LED remains active until
answered
• 10, 20, 30 and 40 call master stations
• Expandable to 120 stations with the addition of
20 and 40 call add-on selectors
• Wide assortment of accessories to meet a variety
of applications
• Push-to-talk at master, hands free at sub station
• Selective calling, Group calling, or All Call
• Separate transmit, recieve, All Call, and call tone
volume controls
• Two master stations can be included in a system
with NEW-5's (1 per 5 sub stations)
