Command/Response Code - Epson WF-R8590 Service Manual

EPSON WF-R8590/WF-R8591/WF-R8593
Error
Code
(HEX)
F21 System error
F23 Communication error
F24 Communication error
F25 Communication error
F27 System error
F28 System error
F29 Communication error
F2A Communication error
F2B No image data for reprint exists
F2F System error
F3A Communication error
F51 System error
F57 Communication error
F58 Communication error
F59 System error
F60 A scanner fatal error occurs
F61 A printer fatal error occurs
F62 Reserved
F63 ADF misfeed or paper jam occurred
F64 The memory for printing received image is full
Note *: Confirm the fatal error code with the Adjustment Program to check which error occurred. (See " 1.3 Fatal Error Code List
(p20)".)


Command/response code

Command/response
code
DIS
CSI
NSF
DTC
CIG
NSC
PWD
SEP
Reserved (PSA)
Reserved (CIA)
Reserved (ISP)
DCS
TSI
NSS
SUB
SID
TRN
TCF
CTC
Reserved (TSA)
Table 1-9. Error Code List
Phenomenon
Table 1-10. Command/Response Code
FCF value (HEX)
(LSB first: X=0)
First Second
80 -
40 -
20 -
81 -
41 -
21 -
C1 -
A1 -
61 -
E1 -
11 -
82 -
42 -
22 -
C2 -
A2 -
E6 -
F0 -
12 -
62 -
Fatal Error Code List
LCD Display
System Error
Communication error
Communication error
Communication error
System Error
System Error
Communication error
Communication error
No Image
System Error
Communication error
System Error
Communication error
Communication error
System Error
Same message when a scanner
fatal error occurred
Same message when a printer
fatal error occurred
---
Same message when an ADF
fatal error occurred
Error code
Content
Digital Identification Signal
Called Subscriber Identification
Non-Standard Facilities
Digital Transmit Command
CallInG subscriber identification
Non-Standard facilities Command
PassWorD
Selective Polling
Polled Sub Address
Calling subscriber Internet Address
Internet Selective Polling address
Digital Command Signal
Transmitting Subscriber Identification
Non-Standard facilities Set-up
Sub Address
Sender IDentification
Training
Training Check
Continue To Correct
Transmitting Subscriber internet Address
Revision F
