ADTRAN NetVanta 3200 Specifications

Product Features

Modular Network
■
Interface Module (NIM)
offering flexibility
Modular Dial Backup
■
Interface Module (DIM)
guaranteeing bandwidth
Stateful inspection fire-
■
wall for network security
Quality of Service (QoS)
■
for delay sensitive traffic
like VoIP
Command Line Interface
■
(CLI) mimics industry
de facto standard
Optional DSX-1
■
interface supplies
TDM voice transport
Comprehensive PPP dial
■
backup scheme prevents
network downtime
VLAN Trunking (802.1Q)
■
for routing between
VLANs
Network Address
■
Translation (NAT) for IP
Address Concealing
Optional VPN for secure
■
corporate connectivity
across the Internet
Built-in DSU/CSU for
■
circuit protection
Feature-rich ADTRAN
■
Operating System (AOS)
Industry-leading five-year
■
North American warranty

NetVanta 3200

Modular Access Router Supporting up to Two T1s Worth of Bandwidth
The NetVanta 3000 Series of modular access
®
routers are designed for cost-effective
Internet access, corporate Frame Relay,
point-to-point connectivity, ADSL, and
Virtual Private Networking (VPN). The
NetVanta 3000 Series currently consists of the
NetVanta 3200, 3205, and 3305 with a variety
of interchangeable Network Interface Modules
(NIMs) and Dial Backup Modules (DIMs).
Modular Hardware
The NetVanta 3200 is a single-slot, single-
Ethernet standalone unit in a plastic housing.
A single slot within any of the NetVanta 3000
Series will house a variety of NIMs and DIMs,
which include a 56/64k, T1/FT1, T1/FT1 with
DSX-1, Dual T1s, E1/FE1, E1/FE1 with G.703,
ADSL, or a Serial interface. For dial backup
an Analog Modem, an ISDN BRI, or Serial
DIM is available for preventing downtime
by dialing around a failed circuit to any PPP
compliant device.
Standard-based Protocols
The versatile hardware platform of the
NetVanta 3200 is further complemented with
the ADTRAN ® Operating System (AOS). AOS
allows for the support of static and default
routes, demand routing, and allows for fast,
accurate network convergence using routing
protocols such as BGP, OSPF, and RIP. In
addition, AOS terminates Frame Relay,
Multilink Frame Relay, PPP, Multilink PPP ,
and HDLC WAN protocols. Multihoming is
also available to provide redundant or backup
WAN links to multiple ISPs, guaranteeing a
wide-area connection.
Security
For added security, AOS provides a powerful,
high performance stateful inspection firewall.
It will examine all incoming and outgoing
packets against the security policies established
by the IT manager. In addition, the firewall can
identify and protect against common Denial of
Service (DoS) attacks like TCP syn flooding, IP
spoofing, ICMP redirect, ping-of-death, and IP
reassembly problems. With the AOS Enhanced
Feature Pack Upgrade, the NetVanta 3000 Series
adds the support for IPSec compliant VPN. The
NetVanta 3200 supports up to five simultaneous
VPN tunnels, while supporting encryption algo-
rithms like DES, 3DES, and AES. With
this upgrade, the NetVanta 3200 is fully
compatible with other IPSec VPN equipped
NetVanta products.
Quality of Service (QoS)
QoS is also supported for delay sensitive traffic
like VoIP or video. To prioritize mission critical
traffic and control network congestion, the
NetVanta 3200 uses Low Latency Queuing,
Weighted Fair Queuing (WFQ), Class-based
WFQ, and DiffServ marking to establish
priority of IP packets routed over the WAN.
VoIP Ready
In combination with the QoS features, a
specialized SIP Application Layer Gateway
(ALG) allows SIP traffic to traverse NAT-
enabled firewalls. For an enterprise network,
this interoperability allows IP PBXs, phones,
and other SIP-based devices to set up, tear
down, and pass voice and call control
messages seamlessly through the integral
NAT-enabled firewall.
Administration
AOS offers a standard Command Line Interface
(CLI) that mimics the widely adopted, industry
de facto standard. The sequence of commands
to configure similar devices is almost identical,
virtually eliminating training costs associated
with re-learning a new operating system or
costly industry certifications. The CLI also
allows for configuration scripts to be used,
saved, and downloaded for a quick and easy
recovery mechanism. In addition, an intui-
tive Web-based GUI provides step-by-step
configuration wizards, management capability,
and the ability to upload firmware updates.
ADTRAN, the leader in WAN connectivity,
offers reliable equipment that increases
network performance, lowers cost, and
positions networks for the future. The
NetVanta 3000 Series is no exception. In
addition, these products are backed by an
industry-leading five-year North American
warranty, free firmware downloads, and world-
class 24-hour technical support from ADTRAN.
