9
CONNECTIONS AND INSTALLATION
I Supplied accessories
Microphone
Microphone hanger and
screws (3 × 16 mm)
Mounting bracket kit for the remote controller
Mounting bracket
Mounting bracket kit for the main unit
Mounting bracket
NOTE: Some accessories are not supplied, or the
s ape is i erent
version�
I Connections
D Connecting the microphone
1� Insert the microphone's connector into the
microphone jack on the remote controller's front
panel�
2� Rotate the connector clockwise until it is
completely tightened�
Microphone's
connector
68
Remote control cable
(5�1 m, 16�7 ft)
Spare fuse
Spare fuse
(ATC 30A)
(BFLP 5A)
Self-tapping screws (M5) Spring washers (M5)
Self-tapping screws (M5) Spring washers (M5)
epen ing on t e transcei er
DC power cable
GPS antenna and
double-sided adhesive pad
Tuner connector kit
Flat washers (M5)
Screws (M5)
Flat washers (M5)
Knobs
CAUTION:
• Be sure that the microphone's connector is
screwed in completely� Otherwise, the remote
controller may lose its waterproof protection�
• DO NOT use non-Icom microphones� Other
manu acturer s microp ones a e i erent pin
assignments, and connection to the remote
controller may damage it�
Accessory connector
(8-pin DIN)
