Cateye GVolt70.1 HL-EL552G-RC Manual

RECHARGEABLE HEADLIGHT
HL-EL552G RC
Under The Handlebar Mount Model
Manual
K 1703
Before using the light, read this
manual thoroughly and keep it
for future reference.
Design Pat. Pending
Copyright© 2019 CATEYE Co., Ltd.
1
HLEL552GRC-191223
Light unit
USB cable
( MICRO USB )
FlexTight™ bracket
( H-34N )
Always charge the product before use.
Before Initial Use
This unit is shipped with a small charge to check
the light. Be sure to charge it before use,
according to the instructions "HOW TO CHARGE".
WARNING!!!
• Be sure to direct the light beam downward so the
driver approaching does not get dazzled.
• Before your trip, please make sure the light is firmly
mounted to the bracket and it lights up.
• Always attention to the remaining battery power by
checking the indicator periodically while using.
CAUTION!
• Do not place it within children's reach.
• In preparation for unexpected battery shutoff, we
recommend you carry a spare light.
• This device is rated IPX4 based on JIS C0920. Do not
immerse the device in water. Doing so may cause a
malfunction. Wipe off any moisture after using the
device in rainy weather.
• If the light unit or parts become dirty with mud, etc.,
clean with a soft cloth which is moistened with mild
soap. Never apply paint thinner, benzine or alcohol;
damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 41°F and 104 °F ( 5 and 40°C ) .
• Before charging, be sure that no dust or other foreign
objects attach to the USB plug.
• Do not subject the light to vibrations while charging.
• Once charging is complete, be sure to disconnect the
USB plug.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable battery to
deteriorate faster. Do not place the light inside a
vehicle or near a heater.
• If the illumination time is significantly reduced even
after proper charging, the rechargeable battery may
be nearing the end of its service life. Dispose of the
battery as described in "Cautions for dispose".
Cautions on storage
Cool and dry storage is recommended. For long period
storage, it is important to charge the battery 30
minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the internal
rechargeable battery and dispose of it according to
local regulations.
1
ENG
HOW TO CHARGE
Charge
jack cover
To PC or
USB battery charger
2
HOW TO MOUNT TO A BICYCLE
Can only be mounted under the handlebar.
GP bracket
Rubber pad
Bracket
CAUTION!:
• Be sure to tighten the dial by hand. When you tighten it too hard with a tool, the screw thread may be stripped.
• Check the dial and screw (*1) on the bracket periodically, and use them without any loosening.
• Round off the cut edge of the bracket strap to prevent injury.
3
SWITCH OPERATION
Switch (indicator)
*2 : When turning the
light on, it lights up in
the mode that was
used last time. ( Mode
memory function )
SPECIFICATIONS
Light source
Battery type
Charge
Operating time
Standard charging time
Temperature range
Recharge/discharge number of times About 300 times (until the rated capacity drops to 70%)
Dimensions/weight
* The specifications and design are subject to change without notice.
Switch ( Indicator )
On
1
Charging
Off
Charging is
completed
2
Standard charging time
USB cable
Approx.
1
Strap
*1
Screw
Mounting height : 400 – 1200 mm
OFF
High
High-intensity LED x 1
Li-ion 3.6 v - 3400 mAh
Micro USB plug
High
Middle
Low
* Average runtime at 20˚C.
Approx. 5 hours (1 A)
Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
1-27/64" x 4-3/16" x 1-53/64" (36 x 106.5 x 46.5 mm) / 3.5 oz (100 g)
1. Connect the light unit to your PC or a commercial
USB battery charger using the USB cable.
( Fig 1
–
1 2
The switch indicator turns on and charging starts.
* When your PC is in sleep state, the unit cannot be
charged.
* We recommend using 1+A USB battery charger.
2. After charging is completed, remove the USB cable,
and install the charge jack cover.
* Charging and lighting times are approximate values,
and will vary by environmental and user conditions.
5 h
( 1A )
3
2
Dial
5
Release button
4
ON
*2
Switch : Press and hold
Middle
Click
: Approx.4 hours
: Approx. 5.5 hours
: Approx. 25 hours
) .
1. Mount the bracket to the
handlebar. ( Fig 2
–
1
2. Insert the light unit into
the bracket until it clicks,
and adjust the beam angle.
( )
4
3. To remove the light unit,
depress the release button
( ) on the top of the unit
5
and pull the unit forward.
* To re-adjust the beam angle,
loosen the dial enough to
move the bracket, and firmly
tighten it after adjustment.
Remaining battery
capacity:
When the switch
( indicator ) lights up,
the remaining battery
power is 20% or less.
Please charge as soon
as possible.
Low
Indicator ( Light up )
)
3
