Passport 4400
Hardware Installation Manual
Part Number 800-1951-20 Rev. A
June 1998

Advertisement

Table of Contents
loading

Related Manuals for Nortel Passport 4400 Series

Summary of Contents for Nortel Passport 4400 Series

  • Page 1 Passport 4400 Hardware Installation Manual Part Number 800-1951-20 Rev. A June 1998...
  • Page 2 Declaration of CE Conformance (for International sales) A Declaration of CE Conformance is on file at the Nortel addresses shown below. The declaration lists the models described in this manual. If the unit carries the CE mark, this declaration certifies that it meets the specific EMC standards and safety (LVD) standards required for CE marking.
  • Page 3 IEC 320 connector on the (IEC 320). SHUCKO et à l’autre une prise IEC 320. other end. Technical Data Technische Daten Donnees Techniques Passport 4400 Series Passport 4400 Series Passport 4400 Series ac units ac Geraete ac appareils ∼...
  • Page 4 Changes or modifications to this product, that could increase the amount of Radio Frequency Emissions from this product, without the expressed written approval of Nortel/Micom could cause the product and the user to violate the FCC’s Rules and Regulations, thus requiring the product to be turned off or disconnected.

  • Page 5: Table Of Contents

    Contents Who Should Read this Document ..........1 Introduction —...
  • Page 6 Connecting the Expansion Modules — 4 High-speed Data Module (HDM) ..........4-1 Legacy Data Module (LDM) and Legacy Data Expansion Module (LEM) .
  • Page 7 Analog Voice Modules — 8 Universal Analog Voice Module (UAVM) ..........8-1 Removing an Interface Module .
  • Page 8 viii...

  • Page 9: Who Should Read This Document

    About this document This document contains detailed information about the hardware components that make up the Passport 4400 device. It describes the 3- and 5-slot chassis, the ethernet base card, and all optional modules. Cabling information is included, as is a discussion of system indicators and warning signals. Who Should Read this Document This document is intended for anyone responsible for installing and upgrading Passport 4400 units and their hardware components.
  • Page 10 About this document Hardware Installation Manual About this document-2...

  • Page 11: Introduction

    Introduction Passport 4400 devices are multimedia, frame relay access devices deployed as an overlay to an existing Passport frame relay network. In this configuration, Passport 4400 units form distinct networks in which separate units communicate using switched virtual circuits (SVCs) provided by the Passport backbone. This arrangement allows small branch sites to consolidate multimedia traffic (such as voice and LAN) over a single low-speed network link (operating at speeds such as 56 or 64 kbps) and pass traffic through regional concentration sites served by...

  • Page 12: Overview

    Passport 4400 Hardware Installation Manual Introduction Model 3e Model 5e Model 5eR with Redundant Power Supply Figure 1-1. Passport 4400 Models Overview The mix of hardware and functions in each Passport 4400 unit depends on the application and site requirements. The major hardware components of the 4400 are described in this section.
  • Page 13 Introduction Passport 4400 Hardware Installation Manual Passport 4400 units are available for use with either ac or dc current, and a redundant power supply option is available on the 5-slot models. Passport 4400 units are available in the following configurations: •...

  • Page 14: Safety Information

    Passport 4400 Hardware Installation Manual Introduction Low-Speed Data Services Modules include the Legacy Data Module (LDM) and the Legacy Data Expansion Module (LEM). The LDM and LEM provide legacy protocol for branch sites connected to a Passport only network. These include FR, X.25, ITI, tr, SNA, SDLC, DTDS, HTDS.

  • Page 15: Specifications

    Introduction Passport 4400 Hardware Installation Manual WARNUNG, AVERTISSEMENT Warning: Remove power plug from the power socket, or disconnect dc power, before performing any service work on the unit. Vor öffnen des Gerätes, muss der Netzstecker aus der Steckdose gezogen werden. Débrancher la prise de courant avant d’entreprendre aucun travail de réparation de l’appareil.
  • Page 16 Passport 4400 Hardware Installation Manual Introduction Operating Environment Temperature ° ° Operating 32 to 122 F (0 to 50 ° ° Storage -40 to 158 F (-40 to 70 Relative Humidity 10-90% non-condensing Operating Storage 0-95% non-condenseing Power Requirements 100-240 volts ac, -5%, +10% 43-63 Hz, 160 Watts maximum (model 4430ac –...
  • Page 17 If you find the problem is in your Nortel equipment, contact your customer service representative.
  • Page 18 Passport 4400 Hardware Installation Manual Introduction In addition to the above information you will be required to supply the following supplemental information if your system is an XD, DD, DE or OT requiring three or more C.O. lines: • Sequence in which the trunks are to be connected •...
  • Page 19 Introduction Passport 4400 Hardware Installation Manual some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
  • Page 20 Passport 4400 Hardware Installation Manual Introduction AFFIDAVIT FOR CONNECTION OF CUSTOMER PREMISES EQUIPMENT TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES For the work to be performed in the certified territory of ___________________(Telco Name), State of____________________, county of________________________________, I,_____________________(name), _____________________________________(business address)________________________(telephone number) being duly sworn, state: I have responsibility for the operation and maintenance of the terminal equipment to be connected to ________________________________________________1.544 Mbps and/or _____________________Subrate digital services.

  • Page 21: Wan Serial Interface Module

    Introduction Passport 4400 Hardware Installation Manual WAN Serial Interface Module Specifications apply to the WAN Serial Interface Module as part of the Passport 4400 unit. Agency Compliances Safety UL 1950 CSA Standard C22.2 No. 950 IEC 950 TUV: EN 60950 Telecom Requirements BABT: CTR-2 56kbps CSU/DSU Interface Module...

  • Page 22: T1 Csu/Dsu Interface Module

    Passport 4400 Hardware Installation Manual Introduction T1 CSU/DSU Interface Module Specifications apply to the T1 CSU/DSU Interface Module as part of the Passport 4400 unit. Agency Compliances Safety UL 1950: 1993 (T1 only) CSA Standard C22 (T1 only) User’s Responsibility This equipment is limited for use on T1 Digital Service lines only.

  • Page 23: Isdn S/T Interface Module

    Introduction Passport 4400 Hardware Installation Manual ISDN S/T Interface Module Specifications apply to the ISDN S/T Interface Module as part of the Passport 4400 unit. Agency Compliances Safety IEC 950 TUV: EN 60950 EN 41003 Telecom Requirements CETECOM: CTR-3 Standard ISDN U Interface Module Specifications apply to the ISDN U Interface Module as part of the Passport 4400 unit.

  • Page 24: High-Speed Data Module (Hdm)

    Passport 4400 Hardware Installation Manual Introduction High-speed Data Module (HDM) Agency Compliances Electromagnetic Compatibility FCC Part 15, Level A (T1 only) C.R.C., c, 1374 (T1 only) EN 55022 CISPR 22, class A IEC 801-2:1991/prEN55024-2:1992, 3KV, CD, 8KV DA IEC 801-3:1984/prEN55024-3:1991, 3 V/m IEC 801-3:1988/prEN55024-4:1993, 0.5KV Signal, 1KV Power EN 60555 Telecom Requirements...

  • Page 25: T1 Voice Module (Tvm)

    Introduction Passport 4400 Hardware Installation Manual T1 Voice Module (TVM) Agency Compliances Safety EN 41003 :1993 EN 60950:1992 +A1 +A2 Electromagnetic Compatibility EN 55022 :1994 class A EN 50082 -2, -3, -4 :1995 FCC Part 15, class A CISPR22, class A Limitations This equipment is intended for use on T1 Digital Service lines ONLY.

  • Page 26: E1 Voice Module (Evm)

    Passport 4400 Hardware Installation Manual Introduction E1 Voice Module (EVM) Agency Compliances Safety EN 41003 :1993 EN 60950:1992 +A1 +A2 Telecom Requirements CTR/TBR13 BABT - Pan European CE-Mark 120 Ohm Structured Leased Line Interface U.K. Only 75 Ohm Structured Electromagnetic Compatibility EN 55022 :1994 class A EN 50082 -2, -3, -4 :1995 FCC Part 15, class A...

  • Page 27: Analog Voice Modules (Avm, Uavm)

    Introduction Passport 4400 Hardware Installation Manual Analog Voice Modules (AVM, UAVM) Agency Compliances Safety UL 1950:1993 CSA Standard C22.2 No. 950:1993 IEC 950:1991+A1:1992 TUV: EN 60950:1992 EN 41003:1993 BABT 340: Sixth Edition (Manufacturing) Electromagnetic Compatibility FCC Part 15, class A C.R.C., c, 1374 CISPR 22, class A EN 55022...
  • Page 28 Passport 4400 Hardware Installation Manual Introduction User’s Responsibility If a need arises in the future, the telephone company will call the user and request the following information: • Model number of the device(s): — Single-channel AVM: NTAU61xx — Dual-channel AVM: NTAU62xx —...
  • Page 29 Introduction Passport 4400 Hardware Installation Manual UAVM FXO USO Jack: RJ11C Ringer Equivalence: 0.9B Please refer to , page 1-7, for more information. Telecommunication Requirements Registration UAVM only: The FXO and E&M interfaces are registered with the FCC based upon compliance with Part 68 of its rules. The FXS interface is not registered with the FCC.
  • Page 30 Passport 4400 Hardware Installation Manual Introduction 1-20...

  • Page 31: Installing The Passport 4400

    Installing the Passport 4400 This section describes the procedures used to set up and connect a configured Passport 4400. Note: For the purposes of this document, the term “configured” refers to the Passport 4400 unit in which all expansion modules have been previously installed and operational.
  • Page 32 Passport 4400 Hardware Installation Manual Installing the Passport 4400 Allow 12 inches (30.5 cm), or greater, for access to rear 5 inches Allow 2 inches (5.1 cm), (12.7 cm) or greater, side space for air vents 12 3/4 inches (32.4 cm)* 18 inches (45.7cm) *For dc models, add 2 1/4 inches (5.7 cm)

  • Page 33: Unpacking The 4400

    Installing the Passport 4400 Passport 4400 Hardware Installation Manual Unpacking the 4400 Procedure 1: Unpacking the 4400 Read the labels on the box, then open the box. Note: Make sure that you keep the packing list included. It contains model numbers and information about the Passport 4400 unit and all included modules.
  • Page 34 Passport 4400 Hardware Installation Manual Installing the Passport 4400 Rack Clip Nut Shelf Washer — Nylon Filler Washer — Nickel Finish Screw Shelf Top View Figure 2-4. Installing the Shelf Rack-mounted 5-Slot chassis Unit Rack-mounted Unit with Redundant Power Supply Rack-mounted 3-Slot Chassis Unit Figure 2-5.

  • Page 35: Powering Up An Ac Unit

    Installing the Passport 4400 Passport 4400 Hardware Installation Manual Powering Up an ac Unit Before the unit is powered up or turned on, make sure there is a Warning: separate ground wire connection between the unit chassis and input power source ground. The power cord supplied with your unit should be one of the following: •...

  • Page 36: Powering Up A Dc Unit

    Passport 4400 Hardware Installation Manual Installing the Passport 4400 Plug the power cord supplied with your unit into the back of the chassis and into an appropriately grounded three-pin wall outlet. This turns the unit on. Powering Up a dc Unit Before applying power to the Passport 4400 unit, make sure that Warning: the unit is properly grounded.

  • Page 37: Verifying Operation

    Installing the Passport 4400 Passport 4400 Hardware Installation Manual Verifying Operation All indicators can be seen through a series of small windows at the front of the chassis (see Figure 2-9 and Table 2-2 below). The bottom window contains status indicators for the Ethernet Base Module, in addition to any serial interface modules that are installed.

  • Page 38: Reset Switch

    Passport 4400 Hardware Installation Manual Installing the Passport 4400 Reset Switch A reset switch is located on the base module and can be accessed from the back of the unit, as shown. Use a small, pointed object to press the switch through the hole in the back panel.

  • Page 39: Connecting The Ethernet Base Module

    Connecting the Ethernet Base Module This section makes the assumption that all expansion modules have been installed and the Passport 4400 is ready to connect to the network. If you need to install expansion modules in the unit, refer to Section 6, “Installing Expansion (Data and Voice) Modules.”...

  • Page 40: Frame Relay Dce Serial Access Port (Port 1)

    Passport 4400 Hardware Installation Manual Connecting the Ethernet Base Module Procedure 3: Attaching cables to the Ethernet base module Note: The connections made in this procedure will depend on the specific site requirements. If you are not sure of the exact connections required for the Passport 4400 unit, consult your system administrator.
  • Page 41 Connecting the Ethernet Base Passport 4400 Hardware Installation Manual Pin 1 MD 50 pin assignments 1, 2 Interface Type Indication 3, 28 V.35 Transmit Data 4, 29 V.35 External Receive Data Clock V.35 External Transmit Data Clock 5, 30 V.36/X.21 Transmit Data 6, 31 V.36/X.21 External Receive Clock 7, 32...

  • Page 42: Management Port

    Passport 4400 Hardware Installation Manual Connecting the Ethernet Base Module Management Port • supports asynchronous operation using an RS-232 physical driver • data rate is automatically selected for speeds from 9.6 to 38.4 Kbps − • management port is RS-232/V.24 a crossover cable is required for DTE operation.

  • Page 43: Ethernet Access Ports

    Connecting the Ethernet Base Passport 4400 Hardware Installation Manual Ethernet Access Ports The base module has hardware for both 10BaseT and AUI ports. However, only one of these ports can be used at any one time. Pin 1 RJ45 pin assignments (Tx+) Transmit data positive RJ45 (Tx-) Transmit data negative...

  • Page 44: Interface Module Connectors

    Passport 4400 Hardware Installation Manual Connecting the Ethernet Base Module Interface Module Connectors Pin 1 MD 50 pin assignments 1, 2 Interface Type Indication 3, 28 V.35 Transmit Data 4, 29 V.35 External Receive Data Clock V.35 External Transmit Data Clock 5, 30 V.36/X.21 Transmit Data 6, 31...
  • Page 45 Connecting the Ethernet Base Passport 4400 Hardware Installation Manual Pin 1 RJ48 Pin Assignments RJ48 Transmit Data from Network Transmit Data from Network Pins 3, 4, 5, 6 Not Connected Receive Data to Network Receive Data to Network Figure 3-7. 56kbps CSU/DSU Module Connector Pin 1 RJ48 Pin Assignments RJ48...
  • Page 46 Passport 4400 Hardware Installation Manual Connecting the Ethernet Base Module Pin 1 RJ48 RJ45 Pin Assignments Pins 1, 2, 7, 8 Not Connected Transmit Data to Network Receive Data from Network Receive Data from Network Transmit Data to Network Figure 3-9. ISDN S/T Module Connector Pin 1 RJ48 RJ45 Pin Assignments...

  • Page 47: Connecting The Expansion Modules

    Connecting the Expansion Modules This section makes the assumption that all the optional modules have been installed and the unit is ready to connect to the network. If you need to install modules in the unit, refer to Section 6, “Installing Expansion (Data and Voice) Modules.”...
  • Page 48 Passport 4400 Hardware Installation Manual Connecting the Expansion Modules Pin 1 MD 50 1, 2 Interface Type Indication 3, 28 V.35 Transmit Data 4, 29 V.35 External Receive Data Clock 5, 30 V.35 External Transmit Data Clock V.36/X.21 Transmit Data 6, 31 V.36/X.21 External Receive Clock 7, 32...

  • Page 49: Legacy Data Module (Ldm) And Legacy Data Expansion Module (Lem)

    Connecting the Expansion Modules Passport 4400 Hardware Installation Manual Procedure 4: Attaching cables to the High-speed Data Module Note: The connections made in this procedure will depend on the specific site requirements. If you are not sure of the exact connections required for the Passport 4400 unit, consult your system administrator.
  • Page 50 Passport 4400 Hardware Installation Manual Connecting the Expansion Modules Procedure 5: Connecting the Legacy Data Module Note: The connections made in this procedure will depend on the specific site requirements. If you are not sure of the exact connections required for the Passport 4400 unit, consult your system administrator.

  • Page 51: T1 Voice Module (Tvm)

    Connecting the Expansion Modules Passport 4400 Hardware Installation Manual T1 Voice Module (TVM) Note: Before you can connect this module, the T1 Voice Module location switch must be set for slot B. If your Passport 4400 unit has been factory assembled, the switch has already been set for slot B.

  • Page 52: E1 Voice Module (Evm)

    Passport 4400 Hardware Installation Manual Connecting the Expansion Modules E1 Voice Module (EVM) Note: Before you can connect this module, the E1 Voice Module location switch must be set for slot B. If your Passport 4400 unit has been factory assembled, the switch has already been set for slot B.

  • Page 53: Analog Voice Module (Avm)

    Connecting the Expansion Modules Passport 4400 Hardware Installation Manual Analog Voice Module (AVM) Prior to connecting the Analog Voice Module (AVM), ensure that the interface type/signaling convention has been properly strapped (refer to Section 8, “Analog Voice Modules”). The connection procedure is identical for modules with either single or dual channels, although modules with the dual channel feature may be configured for two different types of signaling conventions.
  • Page 54 Passport 4400 Hardware Installation Manual Connecting the Expansion Modules Procedure 9: Attaching cables to the Analog Voice Module Note: The connections made in this procedure will depend on the specific site requirements. If you are not sure of the exact connections required for the Passport 4400 unit you are installing, consult your system administrator.

  • Page 55: Universal Analog Voice Module (Uavm)

    Connecting the Expansion Modules Passport 4400 Hardware Installation Manual Universal Analog Voice Module (UAVM) The Universal Analog Voice Module (UAVM) consists of two channels into which one of the three voice interface modules for E&M, FXO, or FXS is inserted. The UAVM board must be configured with the correct jumper settings for the types of interface modules you plan to use before you can connect the modules to the network.

  • Page 56: Use Of Terminal Block

    Passport 4400 Hardware Installation Manual Connecting the Expansion Modules Use of Terminal Block Wiring to the tie trunk terminal block should be carried out by a Caution: qualified technician. Wires used for this purpose must be UL type CM, 22/24 AWG, 8-conductor. On FXS and FXO interface modules, the 4-pin terminal block is an alternate method of connection to the telephone interface equipment.
  • Page 57 Connecting the Expansion Modules Passport 4400 Hardware Installation Manual Procedure 10: Terminal block connection Remove the plug from the terminal block. Use a cable (not supplied) with bare-wire leads. Insert each cable lead into the cutout at the front of the plug and secure it with a small flathead screwdriver at the top.
  • Page 58 Passport 4400 Hardware Installation Manual Connecting the Expansion Modules 4-12...

  • Page 59: Ethernet Base Module And Interface Modules

    Ethernet Base Module and Interface Modules The Ethernet Base Module performs central processing functions for the 4400. It must be present in the lowest slot (LIM A) for the unit to function. This module includes the following: • processor and memory •...

  • Page 60: Interface Modules

    Passport 4400 Hardware Installation Manual Ethernet Base Module and Interface Modules The Ethernet Base Module comes installed in your 4400 Should you need to remove it, remove all modules above it (refer to Section 6, "Installing Expansion (Data and Voice) Modules" for information on opening the unit), disconnect the power connector, remove the 4 screws in the back panel and lift the board out.

  • Page 61: Wan Serial Interface Module

    Ethernet Base Module and Interface Modules Passport 4400 Hardware Installation Manual WAN Serial Interface Module The WAN serial interface module provides additional port capability, identical to port 1 on the base module. The module supports RS-232, V.35, V.36, and X.21 interfaces, determined by the cable used.

  • Page 62: 56Kbps Csu/Dsu Interface Module

    Passport 4400 Hardware Installation Manual Ethernet Base Module and Interface Modules 56kbps CSU/DSU Interface Module The 56kbps module supports the Dataphone Digital Service (DDS) without the secondary signaling channel. This interface module supports the following loopback modes: • DSU loopback •...

  • Page 63: T1 Csu/Dsu Interface Module

    Ethernet Base Module and Interface Modules Passport 4400 Hardware Installation Manual T1 CSU/DSU Interface Module The T1 CSU/DSU interface module provides a direct T1 or fractional T1 connection to Passport T1 FP or any other compatible device. The T1 connection provides a larger communication bandwidth than the serial connection.

  • Page 64: Isdn Interface Module

    Passport 4400 Hardware Installation Manual Ethernet Base Module and Interface Modules ISDN Interface Module The ISDN (integrated services digital network) basic rate interface (BRI) plug-in module will be used as a primary network link connection to the WAN or for backup in case of failure.
  • Page 65 Ethernet Base Module and Interface Modules Passport 4400 Hardware Installation Manual ISDN S/T Interface Module There are two user-adjustable straps on the ISDN S/T interface module, E3 and E4. These straps are used to configure the ISDN connection. Both straps are set to the factory default of OUT.
  • Page 66 Passport 4400 Hardware Installation Manual Ethernet Base Module and Interface Modules...

  • Page 67: Installing Expansion (Data And Voice) Modules

    Installing Expansion (Data and Voice) Modules This section contains general installation information for all optional expansion modules for Passport 4400 units. For information on installing interface modules refer to the following sections: • Section 5, “Ethernet Base Module and Interface Modules” •...

  • Page 68: Module Stacking Order

    Passport 4400 Hardware Installation Module Installing Expansion (Data and Voice) Modules Module Stacking Order Before placing any expansion modules into the Passport 4400, the stacking order must be determined. Table 6-1 shows the proper stacking order for each expansion module. Using the table, determine the stacking order for your Passport 4400 expansion modules.

  • Page 69: Setting The Switchbank

    Installing Expansion (Data and Voice) Modules Passport 4400 Hardware Installation Module Setting the Switchbank To set a switch to on, use a ballpoint pen or similar pointed tool and push the switch down. Take care that only one switch is on (down) and that the remaining three switches are off (up).

  • Page 70: Stacking Connectors

    Passport 4400 Hardware Installation Module Installing Expansion (Data and Voice) Modules Stacking Connectors Stacking connectors act as a bus allowing data to be transferred between the expansion modules and the base card; they must be firmly seated within their mating connectors. Connect Shroud To Block Figure 6-2.

  • Page 71: Spacers

    Installing Expansion (Data and Voice) Modules Passport 4400 Hardware Installation Module Spacers Spacers are attached to the inside of the front of the 4400. They are used to secure the expansion modules inside the unit. Figure 6-4. Spacers Blank Back Panels Any open space not occupied by a module must contain a blank back panel.

  • Page 72: Installing An Expansion Module

    Passport 4400 Hardware Installation Module Installing Expansion (Data and Voice) Modules Installing an Expansion Module Modules should be set for the appropriate application when they arrive from the factory. If changes need to be made to the module, such as setting jumpers or switches, refer to the section that specifically covers the module.
  • Page 73 Installing Expansion (Data and Voice) Modules Passport 4400 Hardware Installation Module Front Flanges Mounting Screw (4) Figure 6-7. Location of Front Flanges and Mounting Screws Refer to Section 10, “Power Supplies,” to verify that the correct number of power supplies are configured for the number of modules used in the unit. Strap the module, (refer to the section for the individual module).
  • Page 74 Passport 4400 Hardware Installation Module Installing Expansion (Data and Voice) Modules Figure 6-8. Installing Expansion Modules in the Passport 4400 Chassis...

  • Page 75: Data Modules

    Data Modules High-speed Data Module There are two versions of the High-speed Data Module (HDM), one with four ports and one with eight ports. The High-speed Data Module provides additional port capability, identical to port 1 on the base module. The module supports RS-232, V.35, V.36, and X.21 interfaces, determined by the cable used.
  • Page 76 Passport 4400 Hardware Installation Module Data Modules Pin 1 MD 50 1, 2 Interface Type Indication 3, 28 V.35 Transmit Data 4, 29 V.35 External Receive Data Clock 5, 30 V.35 External Transmit Data Clock V.36/X.21 Transmit Data 6, 31 V.36/X.21 External Receive Clock 7, 32 8, 33...

  • Page 77: Low-Speed Data Services Modules

    Data Modules Passport 4400 Hardware Installation Module Low-speed Data Services Modules The Legacy Data Module (LDM) provides interface ports to support legacy data protocols in Passport 4400. Additional interface ports are supported through the use of the Legacy Data Expansion Module (LEM). Rear View Pins for LDM Memory Expansion Card...

  • Page 78: Connectors

    Passport 4400 Hardware Installation Module Data Modules Memory Expansion Card for Legacy Data Module For Passport 4400 units containing a Legacy Data Module (LDM) and one or more Legacy Data Expansion Modules (LEM), you must order a memory expansion card for the LDM. This memory expansion card provides 1MB of SRAM memory required to support the additional ports provided by the LEM.

  • Page 79: Analog Voice Modules

    Analog Voice Modules Analog voice modules provide support for Foreign Exchange Station (FXS), Foreign Exchange Office (FXO), and Ear and Mouth (E&M) analog voice services. The following voice modules are available: • the Universal Analog Voice Module (UAVM) and its three interface modules (for FXS, FXO, and E&M) •...
  • Page 80 Passport 4400 Hardware Installation Manual Analog Voice Modules Dual Channel Universal Analog Voice/Fax Module FXS and FXO Interface Modules E&M Interface Module Figure 8-2. Rear View of Universal Analog Voice Module Back Panel Interface Module Figure 8-3. Universal Analog Voice Module with Two Interface Modules Installed...

  • Page 81: Removing An Interface Module

    Analog Voice Modules Passport 4400 Hardware Installation Manual Removing an Interface Module The interface modules cannot be inserted into or removed from Caution: the unit while the Passport 4400 is operating. This could cause damage to the Passport 4400 or interruption of network service or both.

  • Page 82: Inserting An Interface Module

    Passport 4400 Hardware Installation Manual Analog Voice Modules Figure 8-5. Removing the Interface Module Inserting an Interface Module The interface modules cannot be inserted into or removed from Caution: the unit while the Passport 4400 is operating. This could cause damage to the Passport 4400 or interruption of network service or both.

  • Page 83: Interface Modules

    Analog Voice Modules Passport 4400 Hardware Installation Manual Interface Modules FXS and FXO Interface Modules Except for the type designation, the FXS and FXO interface modules have identical telephone interface connectors on the back panel. Each consists of an RJ11 modular jack labeled FXS or FXO and a 4-pin terminal block; see Figure 8- 6, “FXS and FXO Interface Modules.”...
  • Page 84 Passport 4400 Hardware Installation Manual Analog Voice Modules FXS Interface Stapping There are a total of six movable straps located on the FXS interface module, E1 through E6 (see Figure 8-8). These straps are reserved for factory use only. They must not be altered by the user.
  • Page 85 Analog Voice Modules Passport 4400 Hardware Installation Manual FXO Interface Strapping The FXO interface is designed to meet regulatory agency requirements unique to selected countries (such as Spain, France, and Germany). This module contains special straps that implement the requirements of each country. There are 13 movable straps located on the FXO interface module, E1 through E13.
  • Page 86 Passport 4400 Hardware Installation Manual Analog Voice Modules Country-specific Strap Settings The following figures give specific instructions on strapping the Caution: FXO Interface Module for use in Spain, France, Germany and Switzerland. The module is factory shipped with a default setting that operates correctly in all other countries.
  • Page 87 Analog Voice Modules Passport 4400 Hardware Installation Manual Spain • Locate the strapping block labeled E8/E9. Place the strap over the pins marked E8. • Locate the strapping block labeled E10/E11. Place the strap over the pins marked E11. • Leave other strapping blocks (E6/E7, E13/E14, E15/E16) in their default positions.
  • Page 88 Passport 4400 Hardware Installation Manual Analog Voice Modules Germany and Switzerland • Locate the strapping block labeled E15/E16. Place the strap over the pins marked E15. • Leave other strapping blocks (E6/E7, E8/E9, E10/E11, E13/E14) in their default positions. Jumper in Jumper out E14* E10*...
  • Page 89 Analog Voice Modules Passport 4400 Hardware Installation Manual E&M Interface Module The E&M interface module telephone interface signals are terminated in an 8- pin tie trunk terminal block on the back panel (see Figure 8-12, “E&M Interface Module, Back Panel Connector”). This connector is fitted with a female plug. Individual cable leads are connected to this plug to form a telephone interface cable.
  • Page 90 Passport 4400 Hardware Installation Manual Analog Voice Modules TYPE V TYPE II TYPE I Figure 8-13. Location of Straps, E&M Interface Module 8-12...

  • Page 91: Analog Voice Module (Avm)

    Analog Voice Modules Passport 4400 Hardware Installation Manual Analog Voice Module (AVM) The Analog Voice Module converts analog signals to digital for processing by the Passport 4400 unit. FXS, FXO, and E&M interfaces are determined by changing the straps on the front of the module’s circuit board. Dual Channel Analog Voice Module OK LO RO LS RS TM OK LO RO LS RS TM...

  • Page 92: Strapping

    Passport 4400 Hardware Installation Manual Analog Voice Modules Strapping Strapping involves matching the voice/fax channel with the attached telephone interface. Specifically, the voice/fax channel may be strapped, depending on the application, for one of three common types of signaling conventions: FXS (Foreign Exchange Station), FXO (Foreign Exchange Office), or E&M (Ear and Mouth).
  • Page 93 Analog Voice Modules Passport 4400 Hardware Installation Manual Figure 8-17, “Telephone Interface Cable Connections,” shows the connector locations, pin assignments and wire colors of a dual channel AVM. Single channel modules have only one set of interface connectors. Use a modular cable to connect to the applicable telephone interface.
  • Page 94 Passport 4400 Hardware Installation Manual Analog Voice Modules 8-16...

  • Page 95: T1/E1 And Digital Voice Modules

    T1/E1 and Digital Voice Modules T1/E1 digital voice and data is supported on the 4400 through the use of the modules and components described below: • The T1 or E1 Voice Modules (TVM or EVM). The TVM or EVM allows a T1 or E1 leased line or PBX to connect directly to a Passport 4400 unit.
  • Page 96 Passport 4400 Hardware Installation Manual T1/E1 and Digital Voice Modules Stacking Connectors Rear Indicators (Back Panel) Module Switch Group Front Receptacles (6) for Digital Voice Modules Figure 9-1. T1/E1 Voice Module On the right front are 13 indicators. Of these, the six on the left are associated with the voice/fax channels represented by the six Digital Voice Modules, while the seven on the right are associated with the Voice Module.
  • Page 97 T1/E1 and Digital Voice Modules Passport 4400 Hardware Installation Manual Connectors Reserved for future use DSX-1 Interface Test RJ48 Interface Transmit Pair to T1 Transmit Pair from T1 Pin 1 (Monitor Only) (Monitor Only) RJ48 Ring (R) Tip (T) Ring 1 (R1) Tip 1 (T1) Pins 3, 6, 7, 8 Not Connected Figure 9-4.

  • Page 98: Strapping

    Passport 4400 Hardware Installation Manual T1/E1 and Digital Voice Modules Strapping E1 Voice Module Impedance Strapping Impedance for each E1 interface line is determined by the placement of a header on a jumper located on the E1 module. Impedance for each interface line may be straped for either 75 Ω...
  • Page 99 T1/E1 and Digital Voice Modules Passport 4400 Hardware Installation Manual 75 Ω Outer Conductor Strapping The outer conductors of the 75 Ω BNC interface connectors may be connected to earth or isolated. Strapping is implemented by a set of headers and jumpers as shown in the following figure.

  • Page 100: Digital Voice Expansion Module (Dvem)

    Passport 4400 Hardware Installation Manual T1/E1 and Digital Voice Modules Digital Voice Expansion Module (DVEM) The Digital Voice Expansion Module houses a maximum of 12 Digital Voice Modules (DVMs). It serves as an extension to the 6 DVMs mounted on the associated T1/E1 Voice Module.
  • Page 101 T1/E1 and Digital Voice Modules Passport 4400 Hardware Installation Manual DVEM Power Harness For Passport 4400 units containing one or two Digital Voice Expansion Modules, a DVEM power harness must be installed. The power harness provides additional power to the DVEM boards (see Figure 9-9). The DVEM power harness must be ordered separately –...

  • Page 102: Digital Voice Module (Dvm)

    Passport 4400 Hardware Installation Manual T1/E1 and Digital Voice Modules Digital Voice Module (DVM) The Digital Voice Module is a single in-line memory module (SIMM). It compresses 64 Kbps voice obtained from the T1/E1 line into low-speed channels, thereby optimizing the use of the available bandwidths. •...
  • Page 103 T1/E1 and Digital Voice Modules Passport 4400 Hardware Installation Manual Procedure 16: Removing a Digital Voice Module Unlatch the first Digital Voice Module from its mating connector in the T1 Voice Module, the E1 Voice Module, or the Digital Voice Expansion Module. To do that, press your thumbs against the latch springs at either end of the module, and with your forefingers turn the Digital Voice Module into the upright position.
  • Page 104 Passport 4400 Hardware Installation Manual T1/E1 and Digital Voice Modules 9-10...

  • Page 105: Power Supplies

    Power Supplies dc Power Supplies The dc power supply system allows the 4400 to be installed in a telephone company environment with the necessary dc power input being furnished by the telephone company to the input of the 4400. The -48 volts dc version of the 4400 power supply system is identical to the ac version except for the addition of a terminal power adapter that plugs into the line cord Electronic Industry Association (EIA) jack on back of the unit.

  • Page 106: Chassis Types

    Passport 4400 Hardware Installation Manual Power Supply Chassis types Three-slot Chassis (model 4430) The three-slot chassis uses a 135W ac power supply to provide power to the Ethernet Base Module and expansion modules. Note: The three-slot Passport 4400 uses ac power only. There is no option for dc power.

  • Page 107: Five-Slot Chassis (Model 4450)

    Power Supply Passport 4400 Hardware Installation Manual Five-slot Chassis (model 4450) The five-slot chassis uses a 160W power supply to provide power to the Ethernet Base Module and expansion modules. Both ac and dc models are available; the figure below shows an ac unit. Power Sharing Board Jumper J12...

  • Page 108: Five-Slot Chassis With Redundant Power Supply (Model 4450R)

    Passport 4400 Hardware Installation Manual Power Supply Five-slot Chassis with Redundant Power Supply (model 4450R) A Passport 4400 unit with the redundant power supply option contains a subassembly that houses extra power supplies. It provides an extra power supply in the event that one of the original four fails. Two indicator lights that monitor the power supplies are located at the top right side of the front bezel.
  • Page 109 Power Supply Passport 4400 Hardware Installation Manual Configuring the Power Supplies Note: The following information applies to five-slot Passport 4400 units only (models 4450, 4450R). Three-slot units (model 4430) do not need to be configured. The power supply at the bottom of the stack is called the master supply. All other supplies located above the master are called slave supplies.
  • Page 110 Passport 4400 Hardware Installation Manual Power Supply 10-6...

  • Page 111: Indicators

    Indicators This section covers all the indicators and their meaning. The indicators can be seen through a small window at the front of the unit. Indicators Figure 11-1. Location of Indicators on Passport 4400 Ethernet Base Module Interface Module Base Module Indicators Indicators Figure 11-2.

  • Page 112: T1/E1 Voice Module

    Passport 4400 Hardware Installation Manual Indicators T1/E1 Voice Module There are 13 indicators associated with the T1/E1 Voice Module -- six for the Digital Voice channels, and seven for the Voice Module. Digital Voice Channel T1/E1 Status Status Indicators Indicators Figure 11-3.

  • Page 113: T1/E1 Status Indicators

    Indicators Passport 4400 Hardware Installation Manual T1/E1 Status Indicators Table 11-3. T1 Operational States Indicator Function State Status System Status Initialization mode – see Table 11-4. Green Operational mode – see Table 11-4. Flashing green Download active. DSX-1 interface Interface not active. alarm status Flashing red Red alarm –...
  • Page 114 Passport 4400 Hardware Installation Manual Indicators Table 11-5. E1 Operational States Indicator Function State Status System Status Initialization mode – see Table 11-4. Green Operational mode – see Table 11-4. Flashing green Download active. E1 Line 1 Interface not active. interface alarm Flashing red IFAS (Frame Alignment Signal) loss.

  • Page 115: Digital Voice Expansion Module

    Indicators Passport 4400 Hardware Installation Manual Digital Voice Expansion Module There are 13 indicators associated with the Digital Voice Expansion Module, as shown in the figure entitled “Digital Voice Expansion Module Indicators.” Figure 11-4. Digital Voice Expansion Module Indicators Table 11-6. Description of Digital Voice Expansion Module Indicators Indicator State Status...

  • Page 116: Analog Voice Module And Universal Analog Voice Module

    Passport 4400 Hardware Installation Manual Indicators Analog Voice Module and Universal Analog Voice Module There are a total of six indicators associated with each voice/fax channel of both the Analog Voice Module and the Universal Analog Voice Module. The following figure shows and describes the functions of the indicators during normal operation.

  • Page 117: Cable Diagram Pin Assignments A

    Cable Diagram Pin Assignments Diagrams are shown in this section for cables used with the Passport 4400. Use the cable matrix to determine which cable must be used for the desired interface.
  • Page 118 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments Table A-1. Cable Selection for Ethernet Base Module and Data Modules Engineering Port Hardware Type CPC No. code Description Page No. A0668482 NTAU17AA To DTE, M-M manage- RJ45 RS232 ment port A0668483 NTAU18AA WAN RS232 cable to DCE(DB25 male)
  • Page 119 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual Table A-2. Cable Selection for Digital Voice Modules Engineering Port Hardware Type CPC No. code Description Page No. A0670357 NTML79AA modular straight cable A-17 DSX-1 for RJ48 straight use with T1 A0670698 NTMV09AA modular crossover cable...
  • Page 120 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments Pin 1 RJ-45 DB-25 Male Male Ring Indicator (RI) Ring Indicator (RI) Carrier Detect (CD) Receive Line Signal Detector (RLSD) Data Terminal Ready (DTR) Data Terminal Ready (DTR) Ground Ground Receive Data (RD) Receive Data (RD) Transmit Data (TD) Transmit Data (TD)
  • Page 121 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual DB-15 MD50 Male Male Receive Data A Receive Data A (RXDA) Receive Data B Receive Data B (RXDB) Transmit Data Clock A Transmit Signal Element Timing A (TSETA) Transmit Data Cloci B Transmit Signal Element Timing B (TSETB Receive Data Clock A Receive Signal Element Timing A (TSETA)
  • Page 122 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments MD50 34-Pin Male V.35 Female Receive Data A Send Data A (SD A) Receive Data B Send Data B (SD B) External Receive Data Clock A Serial Clock Transmit A (SCT A) External Receive Data Clock B Serial Clock Transmit B (SCT B) Receive Data Clock A...
  • Page 123 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual 34-Pin MD50 Male V.35 Male Receive Data A Receive Data A (RD A) Receive Data B Receive Data B (RD B) Transmit Data Clock A Serial Clock Transmit External A (SCT A) Transmit Data Clock B Serial Clock Transmit External B (SCT B Receive Data Clock A...
  • Page 124 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments MD50 25-Pin RS-232 Male Female Clear to Send Request to Send (RTS) Data Set Ready Data Terminal Ready (DTR) Carrier Detect Unassigned (UN) Request to Send Clear to Send (CTS) Unassigned Carrier Detect (CD) Data Terminal Ready Data Set Ready (DSR)
  • Page 125 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual MD50 25-Pin RS-232 Male Male Clear to Send Clear to Send (CTS) Data Set Ready Data Set Ready (DSR) Carrier Detect Carrier Detect (CD) Request to Send Request to Send (RTS) Unassigned Unassigned (UN A) Data Terminal Ready...
  • Page 126 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments MD50 15-Pin Male X.21 Female Receive Data Transmit Data A (TD A) Receive Data B Transmit Data B (TD B) Control A Internal Clocking A (IC A) Control B Internal Clocking B (IC B) Transmit Data A V11 Receive Data A (RD A) Transmit Data B V11...
  • Page 127 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual MD50 15-Pin Male X.21 Male Receive Data A Receive Data A Receive Data B Receive Data A Control A Clocking A Control B Clocking A Transmit Data A Transmit Data A (TD A) Transmit Data B Transmit Data B (TD B) Transmit Data Clock A...
  • Page 128 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments 37-Pin MD50 V.36 Female Male Receive Data A Receive Data B Receive Clock A Receive Clock B External Transmit Data Clock A External Transmit Data Clock B Transmit Data A Transmit Data B External Receive Data Clock A External Receive Data Clock B Clear to Send A...
  • Page 129 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual MD50 37-Pin Male V.36 Male Receive Data A Receive Data B Receive Clock A Receive Clock B External Transmit Data Clock A External Transmit Data Clock B Transmit Data Clock A Transmit Data Clock B Data Clock A Data Clock B...
  • Page 130 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments MD50 37-Pin Male V.36 Female Receive Data A Receive Data B Receive Clock A Receive Clock B External Transmit Data Clock A External Transmit Clock B Transmit Data A Transmit Data B External Receive Data Clock A External Receive Data Clock B Clear to Send A...
  • Page 131 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual 37-Pin V.36 Male MD50 Male Receive Data B (TD A) Receive Data B (TD B) Receive Clock A Receive Clock B External Transmit Data Clock A External Transmit Data Clock B Transmit Data A Transmit Data B External Clock A...
  • Page 132 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments DB-9 Connector DB-15 Connector (Male) (Female) Tip 1 (T1) Tip (T) Ring 1 (R1) Ring (R) Tip (T) Tip 1 (T1) Ring (R) Ring 1 (R1) To PBX To E1 or PSTN Voice Module Twisted Twisted...
  • Page 133 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual RJ48 RJ48 (Male) (Male) Ring (R) Ring 1 (R1) Tip (T) Tip 1 (T1) Ring 1 (R1) Ring (R) Tip 1 (T1) Tip (T) To T1 To DS-1 T1 Interface Voice Module Figure A-14.
  • Page 134 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments DB-9 Connector DB-15 Connector (Male) (Male) Tip 1 (T1) Tip (T) Ring 1 (R1) Ring (R) Tip (T) Tip 1 (T1) Ring (R) Ring 1 (R1) To PBX To E1 or PSTN Voice Module Twisted Twisted...
  • Page 135 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual RJ48 RJ48 (Male) (Male) Ring (R) Ring 1 (R1) Tip (T) Tip 1 (T1) Ring 1 (R1) Ring (R) Tip 1 (T1) Tip (T) To DS-1 To T1 T1 Interface Voice Module Figure A-16.
  • Page 136 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments Male Female Figure A-17. Coaxial Cable A-20...
  • Page 137 Cable Diagram Pin Assignments Passport 4400 Hardware Installation Manual RJ-45 RJ11 Connector Connector Ring Figure A-18. Cable Model No. NTMR38AA -- Modular Straight Cable A-21...
  • Page 138 Passport 4400 Hardware Installation Manual Cable Diagram Pin Assignments RJ-CX Lug End and Connector Wire Color Signal Battery (SB) SB, blue M, orange Mouth (M) R1, black Ring 1 (R1) Ring (R) R, red T, green Tip (Tip) T1, yellow Tip 1 (T1) Ear (E) E, brown...
  • Page 139 Index 56kbps CSU/DSU Interface Module grounding clips 1-11 agency compliances pin assignments Canadian Requirements CE Conformance Affidavit for digital services Connectors Agencies stacking BABT Digital Voice Expansion Module (DVEM) 11-5 indicators Agency compliances 10-3 power harness 1-11 56kbps CSU/DSU Interface Module Digital Voice Module (DVM) 1-17 Analog Voice Module...
  • Page 140 installing Interface Modules ports installing diagram ISDN Interface Module 1-13 Ethernet access ports agency compliances pin assignments S/T interface Frame Relay DCE pin assignments pin assignments straps interface modules U interface pin assignments pin assignments management port pin assignments Expansion modules Legacy Data Expansion Module (LEM) DIP switches installing...
  • Page 141 E1 Voice Module pin assignments 1-12 High-speed Data Module user’s responsibility ISDN S/T Interface Module T1 Voice Module (TVM) 1-15 ISDN U Interface Module agency compliances Legacy Data Expansion Module connecting 11-2 Legacy Data Module indicators 11-3 T1 CSU/DSU Serial Interface operational states T1 Voice Module pin assignments...
  • Page 142 Index-4...
  • Page 144 Passport 4400 Hardware Installation Manual Address comments to: Senior Manager, Technical Publications Northern Telcom MICOM Communications Corp. 4100 Los Angeles Ave. Simi Valley, CA 93063-3397 U.S.A. 1-805-583-8600 © 1998 Northern Telecom All rights reserved Information subject to change without notice Publication: 800-1951-20 Rev.

This manual is also suitable for:

Passport 4430acPassport 4450acPassport 4450acrPassport 4450dcPassport 4450dcr

Table of Contents
